KDM2410M
Installation Guide

Advertisement

loading

Summary of Contents for Kedacom KDM2410M

  • Page 1 KDM2410M Installation Guide...
  • Page 2 Trademarks ™ Kedacom™, TrueSens™ and are registered trademarks of Suzhou Keda Technology Co., Ltd. in China and various other countries. All other trademarks mentioned in this document are the property of their respective holders. Suzhou Keda Technology Co., Ltd. 131 Jinshan Road...
  • Page 3 The Mobile NVR can connect to PTZ cameras and control them. The Mobile NVR can be controlled by Kedacom Video Management System (VMS), which is a comprehensive platform for managing cameras, NVRs, encoders, and decoders.
  • Page 4 The following table helps you read the indicators on the front panel. Description Indicator State A 3G or 4G connection is established. 3G signal bar No 3G or 4G connection is established. The Mobile NVR is powered on. Power The Mobile NVR is powered off. The Mobile NVR is connected to a VMS.
  • Page 5 2.2 Inserting a Disk On the front panel, you can insert one disk. To insert a disk: Slide the slider right to unlock the protection mask. Take out the key from the key slot. 3. Insert the key into the disk lock and turn the key clockwise to unlock the disk slider. 4.
  • Page 6 Pull out the hard disk tray from the disk slot and unscrew the cover of the hard disk tray. 7. Put the disk into the hard disk tray and screw it. 8. Put the hard disk tray back to the disk slot. Slide the disk slider right to lock the hard disk tray.
  • Page 7 2.4 Pins [Aviation Plugs] PWR-PTZ 1+2+3+4 Red CAR_IN+ Red VCC_PTZ 6+7+8+9 Black CAR_IN- Black GND_PTZ Yellow ACC CAR: Requiring 16 AWG cables or cables with a greater VCC: Requiring 18 AWG cables or cables with a diameter (for example 14 AWG) greater diameter (for example 16 AWG) ACC: Requiring 22 AWG cables or cables with a greater...
  • Page 8 Installing the Mobile NVR 1 Preparations 1 .1 System Specifications Ensure that the specifications of the Mobile NVR are complied with. For example, the operating temperature for the NVR must be within the range of -40°C to 70°C. For the physical specifications of the Mobile NVR, see chapter "Physical Specifications." 1 .2 Equipment Cleanliness The following table provides the mapping between the particle diameter range and number of particles per cubic meter.
  • Page 9 To power on the Mobile NVR, turn on your car engine. To power off the Mobile NVR, shut your car engine off. For details on how to use the Mobile NVR, see the user guide inlcuded in the KEDACOM Document and Utility CD.
  • Page 10 3. Wear a grounding wrist strap to replace the old battery with the new one. Replacement During replacement, do not mix up the anode and cathode. Contact the local authorized Kedacom agent if you encounter any problem when replacing the battery. Disposal Dispose of used batteries according to local laws or regulations.
  • Page 11 Physical Specifications The following table provides the physical specifications of the Mobile NVR. Power 9-36 V Power consumption 15 W (HDD not included) Operating temperature -40℃ to 70℃ Operating humidity 10% to 85% (non-condensing) Elevation -60 m-5000 m Size(height x width x depth) 60 mm x 188.4 mm x 252 mm Weight 2.45 kg (HDD not included)
  • Page 12 This page is intentionally left blank.

  • Page 13: What Is Not Covered By This Warranty

    Kedacom hardware. Manufacturers, suppliers, or publishers, other than Kedacom, may provide their own warranties to you but Kedacom, in so far as permitted by law, provides their products "AS IS". Software distributed by Kedacom with or without the Kedacom brand (including, but not limited to system software) is not covered by this warranty.

  • Page 14: How To Obtain Warranty Service

    If during the Warranty Period, you submit a valid claim to Kedacom or an authorized Kedacom agent, Kedacom will, at its option, (i) repair the Kedacom Product using new or previously used parts that are equivalent to new in performance and reliability, or (ii) exchange the Kedacom Product for a refund of your purchase price.
  • Page 16 中国: 江苏省苏州市高新区金山路131号(215011) Tel: +86-512-68418188 Fax: 86-512-68412699 Suzhou Keda Technology Co.,Ltd. Singapore: 627A Aljunied Road, #09-07, BizTech Centre, Singapore 389842 Tel: +65-6842-5700 Fax: +65-6842-5900 05.03.800425 V1 20160826...
