Model:
GL-200 waterproof gate lock
Feature:
Threaded conduit fitting
Stainless Steel Case
Built-in lock status sensor
Suitable for outdoor
Waterproof
Specifications:
Power supply
Power supply
Operation current
Operation current
Lock status sensor
Holding force
Operation temperature
Warranty
Weight
Sealing protection
Body Dimensions
Armature Dimensions
Casing
Accessories diagram:
2
3
5
1
1
Accessories:
Model
Type
Type
Quantity
1
Sexnut Bolt
2
Rubber Washer
3
Washer
Allenkey
4
5
Guide pins
6
Door spacer
7
Mounting screw
8
Mounting screw
Mounting screw
9
10
Mounting screw
ELECTROMAGNETIC GATE LOCK
INSTALLATION INSTRUCTIONS
GL-200
GL-200
DC-12V / DC-24V
DC-12V / DC-24V
450mA/12VDC 235 mA/24VDC
N.C. Output
(0.25A/30VDC)
600lbs(250kg)
-10
~
70
1 year
2.3kg
I 67
P
210 L (P:226) X 42 W X 28.5 D (mm)
185 L X 38 W X 12 D (mm)
Stainless Steel
9
10
8
7
6
4
GL-200
1
2
3
2
2
1
2
M4x30mm
2
M4x40mm
2
M4x35mm
M4x50mm
2
GL-200
GL-200P
Note
Switchable
Reed switch
Installation
A.Determine the type of gate(refer to FIg 1& Fig2 & FIg3)
Please make sure type of gate (please refer to fig.2&fig3)to ensure
the type of brackets required to install.
B.Prepare the gate post for mounting the gate lock and armature
Determine the desired location for mounting the gate lock and
armature on the gate post.Make sure there is space for wiring.
C.Mount the lock body
D.Mount the armature
If you are mounting the armature directly to the gate. You can refer
to the fig5 for drilling the armature mounting screw hole.
E.Verify proper alignment
Close the gate and verify the lock face and armature are making
full contact of the entire armature length. Adjustments may be
needed.
F.Connect the wires
Refer to Connection Diagram and Monitor Output for wiring.
G.Test the unit.
H. Insert the tamper caps into the mounting screw access holes of the
lock body.
This should be the last step of the installation,as once the tamper
caps are in place, it is difficult to remove.
Please read before installing
Specific mounting brackets may be
necessary to fit different types of gate.
BR-200GL
VER 15.08.25
BR-200GZ
Page 1
