ATS-TN SkyAngel 911FD User Manual

DEVICE CHARGING:

For the first time of use, please fully charge the unit for at least 2~3 hours
Using the USB charger or using docking station to charge
• Place the device on the docking station.
• Connect the Micro USB side of the cable to the docking station port and connect
the other end of the cable to the designated AC power source (USB/AC adaptor).

SWITCHING THE DEVICE ON AND OFF:

• To turn on the device: press the side power button for 1 second, all the LEDs
will flash rapidly. Device can be also turned on automatically by charging via
USB or put it into the docking station.
• To turn off the device: press and hold the side button and SOS button together
for 1 second until the LEDs off.

WATERPROOF:

Your SkyAngel 911FD is 100% waterproof and can be worn in the shower or even
submerged under water for brief periods of time. Do not submerge for longs periods of
time.
PLEASE NOTE: Do not remove the back cover at any time; this will break the
waterproof seal. Also, removing the back cover voids any and all warranties.

LOCATING/STATUS:

To receive a text message with a GoogleMaps link to the current location of the device
send a text to the phone number associated with the device. The body of the text should
be 'LOC'. To receive a text message with the device status such as programmed
numbers and battery status send a text to the phone number associated with the
device. The body of the text should be 'STATUS'.

GPS LOCATING:

The precision that 911 will be able to locate the unit can range from several feet to
hundreds of feet. This unit has full two-way voice communication and that should be the
primary method to direct assistance to the user.
User's Guide for the SkyAngel911FD Friends
