INSTALLATION, OPERATION & MAINTENANCE MANUAL
Horizontal Split Case Centrifugal Pumps
IMPORTANT!
Read all instructions in this manual before operating pump.
product changes may occur. As such Crane Pumps & Systems reserves the right to
A Crane Co. Company
420 Third Street
Piqua, Ohio 45356
Phone: (937) 778-8947
Fax: (937) 773-7157
www.cranepumps.com
Series: 5060
Single Stage, Double Suction
As a result of Crane Pumps & Systems, Inc., constant product improvement program,
change product without prior written noti¿ cation.
83 West Drive, Bramton
Ontario, Canada L6T 2J6
Phone: (905) 457-6223
Fax: (905) 457-2650
®
Form No. 120021-Rev. E
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Deming 5061
Summary of Contents for Deming 5061
- Page 1 ® INSTALLATION, OPERATION & MAINTENANCE MANUAL Horizontal Split Case Centrifugal Pumps Series: 5060 Single Stage, Double Suction IMPORTANT! Read all instructions in this manual before operating pump. As a result of Crane Pumps & Systems, Inc., constant product improvement program, product changes may occur.
-
Page 2: Table Of Contents
CROSS-SECTIONS & PARTS LIST ..........13 - 14 WARRANTY & RETURNED GOODS ..........15 Other brand and product names are trademarks or registered trademarks of their respective holders. Deming® is a registered trademark of Crane Pumps & Systems, Inc. 1996, 12/06 Alteration Rights Reserved... -
Page 3: Safety First
SAFETY FIRST! Please Read This Before Installing Or Operating Pump. WARNING ! Do not wear loose clothing that may This information is provided for SAFETY and to PREVENT become entangled in moving parts. EQUIPMENT PROBLEMS. To help recognize this information, observe the following symbols: WARNING ! Keep clear of suction and discharge openings. -
Page 4: General Information
À exible to some extent and, therefore, must not be SERVICE CENTERS: relied upon to maintain the factory alignment. Preliminary For the location of the nearest Deming Service Center, alignment is necessary after the complete unit has been check your Deming representative or Crane Pumps &... - Page 5 4. FLEXIBLE COUPLING ALIGNMENT A À exible coupling should not be used to compensate for misalignment of the pump and driver shafts. The purpose of the À exible coupling is to compensate for temperature ANGULAR changes and to permit end movement of the shafts without MISALIGNMENT interference with each other, while transmitting power from the driver to the pump.
- Page 6 Figure 3 It is recommended that the motor and pump be dowelled WARNING - Coupling guards must be used to to the vertical mounting frame when the correct alignment avoid serious injury to operating personnel. has been established. Use Loctite on all dowel pins. 5.
- Page 7 Figure 4...
-
Page 8: Impeller
7. LUBRICATION Both suction and discharge pipes must be supported Grease Lubricated Bearings independently near the pump, so that when piping is Grease lubricated bearings are prelubricated at the connected to the pump, no strain will be transmitted to the factory before shipment. -
Page 9: Operation
C - OPERATION Priming by Vacuum Pump When neither of the above methods of priming are practical, 1. PRIMING the pump may be primed by the use of a vacuum pump to exhaust the air from the pump casing and suction line. A Install pet cock (248) on top of casing as shown. -
Page 10: Maintenance
Recommended wear ring clearances are as follows: The following lubricants are recommended at the operating Model C.I. or Bz. Stainless Steel temperature indicated. See Figure 5 for correct oil levels. 5061 .009/.014 .019/.024 5062 .011/.016 .021/.026 0°F - 150°F, - S.A.E. #10 Wt. Non-detergent oil 5063 .013/.018... -
Page 11: Lock Nut
Pull off bearing housings (31) and (33) and bearings 9. Place bearing assemblies onto shaft. Press only on the inner bearing race if required. (16) and (18). Note: On oil lubricated pumps shaft 10. On grease lubricated pumps, place the lock washer collar (68) will also be removed. -
Page 12: Locating Trouble
6. CONVERSION OF GREASE TO OIL 4. Pump Works For A While Then Quits LUBRICATION a. Air leaks in suction piping (or Oil to Grease Lubrication) b. Obstruction in pump or piping c. Suction lift too high Follow steps 8 through 11 of the Disassembly and d. -
Page 13: Cross-Sections & Parts List
FIG. 5060 SERIES HORIZONTAL - GREASE LUBRICATED ITEM No. DESCRIPTION ITEM No. DESCRIPTION Cap Screws Lower Half Casing Shaft Sleeve Gasket ITEM No. DESCRIPTION Upper Half Casing DeÀ ector Pipe Plug Impeller Bearing Cap (inboard) Pipe Plug Pump Shaft Bearing Cap (outboard) Cap Screws Casing Ring Coupling Key... - Page 14 FIG. 5060 SERIES HORIZONTAL - OIL LUBRICATED ITEM No. DESCRIPTION ITEM No. DESCRIPTION Pipe Plug Lower Half Casing DeÀ ector ITEM No. DESCRIPTION Upper Half Casing Bearing Cap (inboard) Vent Impeller Bearing Cap (outboard) Pipe Plug Pump Shaft Coupling Key Cap Screws Casing Ring Lip Seal...
