ZiLOG Wireless Zdots Quick Start Manual

Development kit
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Introduction
This Quick Start Guide provides instructions to use Zilog's Wireless Zdots
Computer (SBC) with the Demo project
sample project in which the communication of a PC to a web page is wireless, it is run by
Zdots SBC. The
WLANDemo.zdsproj
software suite. This Demo project can only be used on Wireless Zdots SBC. Do not use
this Demo project on Zilog's eZ80Acclaim!
used as the starting point for your application development.
Figure 1. Wireless Zdots
Wireless Zdots
Computer Development Kit
Quick Start Guide
WLANDemo.zdsproj
is used along with standard Zilog TCP/IP (ZTP)
Copyright ©2010 by Zilog
www.zilog.com
®
Single Board
.
WLANDemo.zdsproj
®
development kit. This project can also be
®
SBC Development Kit
®
, Inc. All rights reserved.
QS007504-0410
®
Single Board
is a

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Wireless Zdots and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for ZiLOG Wireless Zdots

  • Page 1 Zdots SBC. The is used along with standard Zilog TCP/IP (ZTP) WLANDemo.zdsproj software suite. This Demo project can only be used on Wireless Zdots SBC. Do not use ® this Demo project on Zilog’s eZ80Acclaim! development kit. This project can also be used as the starting point for your application development.
  • Page 2 Wireless Zdots Single Board Computer Development Kit Wireless Module RS-232 Adapter Prototype Area ZDI Interface Wireless Development kit Base Board ® Figure 2. Wireless Zdots SBC and Base Board eZ80F91 NOR Flash On-Board Antenna SRAM RS-232/PWR MII Input/Output Input/Output ®...

  • Page 3: Kit Contents

    Single Board Computer Development Kit. Hardware The hardware included in this kit are: • eZ80AcclaimPlus! Wireless Zdots SBC • eZ80AcclaimPlus! Wireless Zdots SBC Development Kit Base Board • RS-232 Adapter • USB Smart Cable • 5 V DC Power Supply •...

  • Page 4: Software And Documentation (On Cd-Rom)

    The software included in this kit are: ® • Zilog Developer Studio II (ZDS II)-eZ80 Acclaim! • Zilog TCP/IP Stack (ZTP) ZDS - Object Code Notes: 1. For latest revision, visit www.zilog.com. 2. For procedure to download the ZTP software, see Downloading the ZTP Software on page 18.

  • Page 5: Installing The Zdsii Software And Kit Documentation

    CD-ROM drive to your hard disk using Windows Explorer or read the documen- tation directly from the CD-ROM itself. ® For customer service and technical support, Zilog recommends you to create an account on http://support.zilog.com. Installing the USB Smart Cable Follow the steps below for installing the USB Smart Cable and associated driver software.

  • Page 6: Windows Xp

    Follow the steps below to install the USB Smart Cable for Windows XP: 1. Connect the Zilog USB device to the Host PC. The Found New Hardware Wizard should activate automatically after connecting the Zilog USB device for the first time;...

  • Page 7: Hardware Setup

    Follow the steps below to install the USB Smart Cable for Windows 98SE: 1. Connect the Zilog USB device to the Host PC. The Add New Hardware Wizard should activate automatically after connecting the Zilog USB device for the first time.
  • Page 8 Note: Pin 1 is indicated by the square solder on the solder side. 3. Connect the USB Smart cable (or any Zilog Debug tool) to the 6-pins ZDI interface on the Wireless Base Board on your development PC. See Connecting the USB Smart Cable to the Development Board on page 9.

  • Page 9: Configuring The Hyperterminal Application

    ® Wireless Zdots Single Board Computer Development Kit Connecting the USB Smart Cable to the Development Board Caution: The power to the development board must be disconnected or turned OFF before connecting or disconnecting the USB Smart Cable. Attach one end of the six-conductor ribbon cable (included) to the USB Smart Cable six-...

  • Page 10: How To Execute Wlan Demo Application

    How to Execute WLAN Demo Application Running the RAM-Based WLAN Demo Project using the ZDS II Toolset Follow the steps below to execute the WLAN Demo project in the Zilog Developer Studio II (ZDS II) development environment: Note: The following procedures reference the located in the WLANDemo.zdsproj...
  • Page 11 . The default location of ZTP_X.Y.Z_Lib_ZDS <ZTP Installed Dir> is C:\Program Files\ZiLOG. 4. Select Build  Set Active Configuration to open the Select Configuration dialog box, and select the RAM configuration. 5. From the Project menu in ZDS II, select Settings. The Project Settings dialog box appears.
  • Page 12 10.20.2.39 Ethernet HTTPD ready TELNET ready[ZTP ]> For more details on shell commands, refer to Zilog TCP/IP Software Suite Programmer’s Guide (RM0041). SSID and WEPKEY are provided by the wireless router. In this demo NET- Note: GEAR and 378E919303657C6DBCA9B29A5E key are used. See...

  • Page 13: Web Server Demonstration

    4. In FLASH and COPY_TO_RAM configurations the SSID and WEP key can be set through the shell command. For more details, configwlan refer to Zilog TCP/IP Software Suite Programmer’s Guide (RM0041). ® 5. The Zdots WLAN solution cannot be configured to work as an Access Point.
  • Page 14 ® Wireless Zdots Single Board Computer Development Kit Figure 8. Website Browsing You can use Telnet client from a PC to browse the eZ80 WLAN Zdots SBC and access its shell prompt through the wireless connection. QS007504-0410 Page 14 of 19...

  • Page 15: Configuring The Router

    ® Wireless Zdots Single Board Computer Development Kit Configuring the Router The following steps below in configuring the router is set with SSID equal to ‘NETGEAR’ and the generated keys: Note: These steps are based on LINKSYS WRT54G Router. 1. Disable the wireless connection on your laptop/PC.
  • Page 16 ® Wireless Zdots Single Board Computer Development Kit Figure 9. Basic Wireless Settings 8. Click Save Settings. Then click Continue if settings are successful. 9. Select Wireless  Wireless Security. Ensure that WEP is selected on the Security Mode: field as displayed in...
  • Page 17 ® Wireless Zdots Single Board Computer Development Kit Figure 10. Wireless Security 10. Click Save Settings. Then click Continue if settings are successful. 11. You can now try to connect using the specified SSID and Key 1. 12. You can now run your project. See: “How to Execute WLAN Demo Application”...

  • Page 18: Downloading The Ztp Software

    Key Number found on the Registration Card that is included on the kit. Then click on the Register button. 3. Locate and find eZ80F91WF01ZCOG and click on the corresponding Updates Available link. 4. Click on Zilog TCP/IP Stack (ZTP) ZDS - Object Code to download ZTP X.Y.Z object package; that is, file. ZTP_X.Y.Z_Lib_ZDS.exe 5.

  • Page 19: Life Support Policy

    Zdots are trademarks or registered trade- marks of Zilog, Inc. All other product or service names are the property of their respective owners. QS007504-0410...
