  • Page 1 USER REFERENCE & TUTORIAL MANUAL TARGA 3000...
  • Page 2 ® TARGA 3000 User Reference & Tutorial Manual ® For Windows NT Systems Pinnacle Systems, Inc. 280 N. Bernardo Avenue Mountain View, CA 94043 June 2000 © Copyright 1993 - 2000 Pinnacle Systems, Inc. P/N 136001001 Rev. B...
  • Page 3 Patents The TARGA 3000 card is protected under one or more of the following U.S. Patents: 5,229,852; 5,561,472; 5,327,243; 5,951, 625. Trademarks Pinnacle Systems and the Pinnacle Systems logo are registered trademarks of Pinnacle Systems, Inc. TARGA is a registered trademark of Pinnacle Systems, Inc.

  • Page 4: Table Of Contents

    CHAPTER 1 — BASIC CONCEPTS AND TIPS ..............About Video Formats ........................About Video Sources ........................Hardware vs. Software Playback ....................System Performance Considerations When Using TARGA 3000..........Calculating Disk Storage......................Square vs. Non-Square Pixels ..................... Displaying Serial Digital Clips On A Computer Screen ............
  • Page 5 Input Source ........................Video Format Compression....................Enable Overlay ........................DV Audio Format......................TARGA Settings Playback Tab.................... Scrub Field Dominance ..................... Playback Overlay Usage ....................Genlock Source ......................... System Performance Description ..................TARGA Settings MPEG Export Tab ................... MPEG OutPut Type ......................OutPut Bite Rate........................
  • Page 6 Using The TARGA 3000 Effects Panel For Transitions And Filters........Picker Area ........................Scrub Effect Area ......................Length, Time, and Description Area ................. Effect Parameters Area...................... Effects Percent Area ......................Setup Button ........................CHAPTER 3 — CONFIGURING AND USING DEVICE CONTROL .........
  • Page 7 Record Video Option......................Record Audio Option......................Record Your Video ........................Playback And Save Clip ......................Lesson 2: Making Videos......................Previewing Your Video ......................Compiling Videos ........................Saving Your Capture Settings....................CHAPTER 5 — USING TITLEDEKO ..................About TitleDeko......................... How Titles Are Created ......................Opening TitleDeko........................
  • Page 8 Resizing ..........................Rotating ..........................Skewing ..........................Using And Modifying Looks And Styles ................Editing Looks ........................Detail And Attribute Controls .................... Accessing The Style Window..................... Creating Your Own Styles....................Making Backgrounds ......................Using Replace Background Window.................. Pinnacle Systems TARGA 3000...
  • Page 9 Lesson 2: Enhancing The Text Of A Title ................Lesson 3: Rolling A Title ......................Lesson 4: Creating A Scrollable Crawl Title ................APPENDIX A — TARGA 3000 FX GUIDE..............TARGA 3000 Effects Factory ..................How Effects Are Stored....................The Difference Between Filters And Transitions............
  • Page 10 Dbl Squeeze Right Example................. Fade Right Example ..................... Blink Tall Example....................Squeeze S......................... Fly Out 001 Example.................... APPENDIX B — TROUBLESHOOTING & CONTACTING PINNACLE SYSTEMS........TARGA 3000 Troubleshooting ..................General Problems ....................... IRQ Problems ......................Monitor Problems ....................... Pinnacle Systems TARGA 3000...
  • Page 11 Playback Problems ..................... Pinnacle Systems Customer Satisfaction Center ............Troubleshooting Questionnaire .................. Contacting Pinnacle Systems ..................APPENDIX C — TARGA 3000 TECHNICAL SPECIFICATIONS ......Technical Specifications....................TARGA 3000 Card Only.................... TARGA 3000 Pro Analog Breakout Box Only............TARGA 3000 Pro Digital Breakout Box Only ............

  • Page 12: Official Notices And Warranties

    Legal Stuff FCC DECLARATION OF CONFORMITY (TARGA 3000 PCI SERIES) This equipment has been tested and found to comply with the limits for a Class A only digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 13: Ce Declaration Of Conformity

    Manufacturer's Address: 280 N. Bernardo Avenue Mountain View, CA 94043 Type of Equipment: PCI Display Card (PC Platform) Model Name: TARGA 3000 Tested By: EMCE Engineering, Inc. 44370 S. Grimmer Blvd. Fremont, CA 94538-6309 USA Manufacturer's Test Engineer: Bill Stutz I, the undersigned, hereby declare that the equipment specified above conforms to the above Directive and Standard.

  • Page 14: Limitation Of Liabilities

    End User License Agreement, do not install, copy, or use the PRODUCT, and promptly return the entire unused PRODUCT to your place of purchase for a full refund. In Pinnacle Systems TARGA 3000...
  • Page 15 copying, addition, by installing, or otherwise using subscription updates that you have received as part of the PRODUCT (‘’UPDATES’’), you agree to be bound by the additional license terms that accompany such UPDATES. If you do not agree to the additional license terms that accompany such UPDATES, you may not install, copy, or use such UPDATES.

  • Page 16: Introduction

    Note: MPEG-2 capture and editing is not available in the 1.0 software release of TARGA 3000. MPEG-2 export is available. MPEG-2 capture and editing is an integral part of the TARGA 3000 system, and will be provided free of charge in an upcoming software release.
  • Page 17 Premiere editing application which features intuitive 3 point editing, dual source and program windows, and a wide range of plug-ins and other creative tools. In addition, the TARGA 3000 package includes DV 1394 and frame accurate machine control via Pipeline Digital’s ProVTR plug-in for Adobe Premiere.

  • Page 18: Using This Manual

    Adobe Premiere. Appendix A: TARGA 3000 FX Guide -- Contains a description of how to use each part of the TARGA 3000 Effects Factory interface, and also has examples of how to make effects. Pinnacle Systems TARGA 3000...
  • Page 19 Appendix B: Troubleshooting -- Contains troubleshooting and contacting Pinnacle Systems Technical Support information. Appendix C: Technical Specifications -- Gives the technical specifications for the TARGA 3000. Introduction...

  • Page 20: Chapter 1: Basic Concepts And Tips

    This Chapter contains the following sections: • About Video Formats • About Video Sources • Hardware vs. Software Playback • System Performance Considerations When Using TARGA 3000 • Calculating Disk Storage • Square vs. Non-Square Pixels • About TARGA 3000 Audio •...

  • Page 21: About Video Formats

    In the NTSC format, there are a total of 525 lines. Not all of these lines are part of the image. Some contain synchronization and other information. The TARGA 3000 digitizes CCIR 601 at 720 x 486 for NTSC, and 720 x 576 for PAL.

  • Page 22: About Video Sources

    The TARGA 3000 card with the TARGA Pro Analog Breakout Box accepts analog input in the form of S-Video (Y/C), Composite Video, and Component (YUV) video. The TARGA 3000 with the TARGA Pro Digital Breakout Box only accepts serial digital input.

  • Page 23: Hardware Vs. Software Playback

    Note: Any file created (compressed) on a TARGA 3000 installed PC, but played on a PC which does not have a card similar to TARGA, will retain its “full frame” capability, but may not retain the guaranteed “full motion”...

  • Page 24: System Performance Considerations When Using Targa 3000

    10,000 or better rpm ultra-2 wide drives, or a SCSI 160M, is essential in order for you to achieve the necessary data rates for optimal results. Note: For a list of Authorized Value Added Resellers and certified TARGA 3000 system configurations, see the Customer Support section of the Pinnacle Systems web site at: http://www.pinnaclesys.com...

  • Page 25: Calculating Disk Storage

    Calculating Disk Storage To determine how many minutes of video you can store per gigabyte (GByte) of disk space, you can use the following chart as a quick reference: KByte = 1,000 MByte* = 1,000,000 (as disk manufacturers define it) GByte = 1,000,000,000 __________________ KBytes...
  • Page 26 29.97 frames per second x 720 pixels wide x 486 pixels high x 2 bytes per pixel = 20,974,205 total bytes per second Two bytes per pixel comes from the fact that TARGA 3000 supports a compression that uses YUV 4:2:2 video. For every four pixels of video there is 4 bytes of Y, 2 bytes of U, and 2 bytes of V which is a total of eight bytes for every four pixels, or two bytes per pixel.

  • Page 27: Square Vs. Non-Square Pixels

    Some video products, such as the TARGA 3000, utilize resolutions with non-square pixels. As mentioned previously, the resolution of NTSC for TARGA 3000 is 720 x 480. On a video monitor, the video signal displays more pixels in the horizontal direction than in the vertical direction for a given length.

  • Page 28: Effects, Transitions, And Titles

    Note: The TARGA 3000 always works in native CCIR 601. No distortion will occur if TARGA 3000 effects, transitions, and titles are used. Also, no distortion will occur if the effects, transitions, and titles used are CCIR 601 compatible.

  • Page 29: About Targa 3000 Audio

    About TARGA 3000 Audio The audio rate that is supported by TARGA 3000 is 48 kHz, 16 bit, stereo. The TARGA 3000, when used with Adobe Premiere, will also support 44.1 kHz and 32 kHz via the sample rate conversion feature (which should always be set to “Best”) found in Adobe Premiere.

  • Page 30: Reliable And Non-Reliable Media Or Constructs

    Reliable And Non-Reliable Media Or Constructs The TARGA 3000 card streams a wide range of media and constructs in real time without dropping frames. Such media and timeline constructs are considered real-time reliable. There are some types of media and constructs though that will cause the TARGA to drop frames.

  • Page 31: Non-Reliable Real-Time Media

    The following is a list of non-reliable real-time media for TARGA 3000: • Video -- AVI video files compressed by compressors other than TARGA 3000, such as Cinepak. Video files in non-AVI format, such as .MOV files (QuickTime videos). Video files in frame sizes that are not in full-frame sizes of NTSC 720 x 486 or PAL 720 x 576, and at the NTSC frame rate of 29.97 fps or at the PAL frame rate of 25 fps.

  • Page 32: Answers To Frequently Asked Questions

    Pinnacle Technical Support. 1. What are the best drives for use with the TARGA 3000? How do I configure them? Why and when do I need a SCSI card or disk array? Which SCSI card is best for use with the TARGA 3000? The important things to remember are to use equipment that is Ultra-2-Wide or Ultra 160 SCSI that does 10,000 rpm or better and is Audio-Video (AV) rated.
  • Page 33 At this time only Adobe Premiere 5.1c or greater, and in:sync corporation’s Speed Razor are supported by TARGA 3000. 7. Will I use my VGA display for the desktop functions of the TARGA 3000? Yes, your computer will still need a S-VGA card. A list of certified TARGA 3000 system configurations can be found at the Customer Support section of the Pinnacle Systems web site at: http://www.pinnaclesys.com...
  • Page 34 The primary criteria for evaluating digital components of your system is their ability to keep pace with the stream of data, both video and audio. TARGA 3000 has a NTSC full frame resolution at 720 x 480 pixels, for a total of 307,200 pixels. At 30 frames per second, that’s 9,216,000 pixels per second.
  • Page 35 A list of Authorized Value Added Resellers and certified TARGA 3000 system configurations can be found at the Customer Support section of the Pinnacle Systems web site at: http://www.pinnaclesys.com...
  • Page 36 (S-VHS and Hi-8) with S-Video connections, or component (broadcast quality) video equipment with a TARGA 3000 card. Be aware that generation loss will degrade video digitizing performance. Do not record tape-to-tape and then use second generation video to digitize to your computer hard disk.
  • Page 37 Chapter 1: Basic Concepts And Tips...

  • Page 38: Chapter 2: Targa Specific Control Panels Within Adobe Premiere

    Chapter 2: TARGA Specific Control Panels Within Adobe Premiere Contents This Chapter contains the following sections: • About The TARGA Specific Control Panels • TARGA Settings Panel • TARGA Performance Monitor • TARGA Peak Meter • TARGA 3000 Effects (Transitions/Filters) Panel Pinnacle Systems TARGA 3000...

  • Page 39: About The Targa Specific Control Panels

    Premiere will remain set within Premiere until you change them. TARGA Settings Panel The TARGA Settings Panel allows you to make adjustments to the TARGA 3000 card for various aspects of the input video and audio data stream coming into the TARGA card, and the video and audio stream being output from the card.

  • Page 40: Targa Settings Capture Tab

    Input Source -- Source of the signal input coming to the card. The choices given are either Breakout Box or IEEE-1394. Pinnacle Systems TARGA 3000...

  • Page 41: Video Format Compression

    It has a data rate of about 76 GBytes per hour. Enable Overlay -- Sets the TARGA 3000 card to support overlay via the PCI Bus and your VGA card. Overlay is the process of combining a video stream with your VGA signal to produce video in a window on your desktop monitor.

  • Page 42: Targa Settings Playback Tab

    — When selected allows you to select the field that will be displayed during a Scrub Fields scrub. You may choose to scrub field 1 (odd field) or field 2 (even field). Pinnacle Systems TARGA 3000...

  • Page 43: Playback Overlay Usage

    Breakout Box. System Performance Description -- Tells the TARGA 3000 card the number of real-time playback streams that can be sustained by the host system. This allows the TARGA 3000 card to determine if the video is real-time playable. —...

  • Page 44: Targa Settings Mpeg Export Tab

    TARGA Settings MPEG Export Tab The MPEG Export settings for TARGA 3000 allow you to export compositions to an MPEG-2 file format. MPEG Output Type -- Allows you to select the MPEG-2 file format to which compositions are to be exported. Your choices are either an MPEG-2 Elementary Stream or MPEG-2 Program Stream file format.

  • Page 45: Gop (Group Of Pictures)

    10 minutes per CD. GOP (Group Of Pictures) -- GOP within TARGA 3000 allows for two choices: • DVD Standard -- Use if DVD is going to be the format used. A GOP size (length) of 15 and an “M”...

  • Page 46: Targa Settings File Version Tab

    TARGA Settings File Version Tab The information in the File Version Tab is primarily used by technical support personnel for troubleshooting purposes. This area identifies the TARGA 3000 components that are on your system, and includes the version number of each component.

  • Page 47: Targa Settings Pro Analog Breakout Box Tab (Video Input)

    Since all video inputs on the Breakout Box are active simultaneously, you need to set the TARGA 3000 card for the video input format that is to be used. The choices given for the Pro Analog Breakout Box are: •...

  • Page 48: Video Input Controls

    You can alter the values by moving each slider via the mouse or typing a new value into the data field. TARGA 3000 remembers the settings, even after you close and reopen Adobe Premiere, until you change them. (The settings made are saved in a registry file in the Windows NT directory.) If you change values, they change only for the active video input selection...

  • Page 49: Signal Generator

    The TARGA 3000 Input Controls can then be used to “match” the TARGA 3000 generated color bars to the bars displayed by the external signal generator.

  • Page 50: Targa Settings Pro Analog Breakout Box Tab (Video Output)

    TARGA 3000 remembers the settings, even after you close and reopen Adobe Premiere, until you change them. (The settings made are saved in a registry file in the Windows NT directory.) Note that you can use the “Save”...
  • Page 51 — In a video waveform this is how far the whitest whites are from the blackest Contrast blacks. If the peak white is far away from the peak black, the image is said to have high contrast. If the peaks are close together, the image will have low contrast (i.e., the image will look “washed out”).

  • Page 52: Signal Generator

    The TARGA 3000 Input Controls can then be used to “match” the TARGA 3000 generated color bars to the bars displayed by the external signal generator.

  • Page 53: Targa Settings Pro Analog Breakout Box Tab (Audio Input)

    Since all audio inputs on the Breakout Box are active simultaneously, you need to set the TARGA 3000 card for the audio input format that is to be used. The choices given for the Pro Analog Breakout Box are: •...

  • Page 54: Gang Left And Right Controls

    Then make adjustments to the “Audio Output” subtab. — The left audio channel. For TARGA 3000 an analog audio feed of +4 dBu (balanced), Left or -10 dBu (unbalanced), with a gain of 0 dB will produce a digital audio file with a level of -18 dBFS.

  • Page 55: Targa Settings Pro Analog Breakout Box Tab (Audio Output)

    TARGA 3000 remembers the settings, even after you close and reopen Adobe Premiere, until you change them. (The settings made are saved in a registry file in the Windows NT directory.) Note that you can use the “Save”...

  • Page 56: Gang Left And Right Controls

    You should set the audio output for the maximum output gain possible without causing distortion. — The left audio channel. For TARGA 3000, when the gain is set to 0 dB, a digital Left audio file with a nominal level of -18 dBFS will output to +4 dBu on the analog outputs.

  • Page 57: Targa Performance Monitor Panel (Performance Tab)

    TARGA Performance Monitor Panel (Performance Tab) The “Performance” tab within the TARGA Performance Monitor Panel displays how many video and audio frames are played back in the timeline of your video-editing application compared to the number of frames dropped. The percentage given is for the number of frames dropped.

  • Page 58: Targa Performance Monitor Panel (Warnings Tab)

    (or right) two frames turn red when the audio signal is so strong that it “pegs” the meter. Click on the top frames to reset them, then adjust the gain controls on the Video Output subtab of the TARGA Settings Panel. Pinnacle Systems TARGA 3000...

  • Page 59: Targa Effects Panel (Transitions And Filters Picker)

    TARGA 3000 provides a number of additional transitions and filters. These transitions have been specially enhanced for acceleration when used with the TARGA 3000 card. The TARGA 3000 Transitions can be selected from within the transition selection panel of your video-editing application (e.g., Adobe Premiere).

  • Page 60: Using The Targa 3000 Effects Panel For Transitions And Filters

    Using the TARGA 3000 Effects Panels For Transitions And Filters The TARGA 3000 Effects Panel for TARGA Transitions and Filters is divided into sections for easy use, and the controls within each section are used as follows: Picker Area Scrub Control...

  • Page 61: Length, Time, And Description Area

    Click this button to play the entire effect. The result can be seen on Play Entire Effect the output monitor. Click this button to scrub the selected effect forward one Scrub Forward One Frame frame. The result can be seen on the output monitor. Click this button to scrub to the end of the selected effect.

  • Page 62: Effects Percent Area

    (e.g., Basics Tab). Each effect is a *.pky file, and the software will scan the C:\TARGA Files\Pinnacle Systems\TARGA 3000\ (Tab Name) in search of *.pky effect files. If for any reason the contents of a tab name directory get changed (e.g., you want to add some effects that are from the Pinnacle Systems web site), you merely have to hit “Setup”...
  • Page 63 Chapter 2: TARGA Specific Control Panels Within Adobe Premiere...

  • Page 64: Chapter 3 - Configuring And Using Device Control

    Chapter 3: Configuring And Using Device Control Contents This Chapter contains the following sections: • TARGA 3000 Device Control • Configuring Device Control • DV 1394 Device Control • Serial Port Device Control • Configuring ProVTR • ProVTR Technical Support...

  • Page 65: Targa 3000 Device Control

    TARGA 3000 Device Control The TARGA 3000 software is designed to provide device control within your video-editing application for video equipment (camcorders, VTR’s, etc) that is device control compatible. Device control is useful to query information from a video input device like time code, or to control functions on an input device such as play, pause, rewind, etc.

  • Page 66: Dv 1394 Device Control

    Movie Capture window of Adobe Premiere. DV 1394 Device Control TARGA 3000 supports the following functions with DV 1394 device control: Note: Even though the software supports the functions listed, the DV Device you have may or may not support all of the functions listed.

  • Page 67: About Dv Time Code

    About DV Time Code DV devices use a Drop Frame (DF) time code (NTSC only). A DF time code cannot be set to a specific default (i.e., new tapes always begin at 00:00:00:00). Nevertheless, this is exact and returns clear values for single frames. When working with DV material, select “Drop-frame time code”...

  • Page 68: Serial Port Device Control

    Premiere User Manual information on this topic in the Adobe Premiere manual. Serial Port Device Control ™ When TARGA 3000 was installed on your computer, a plug-in called Pipeline ProVTR ® manufactured by Pipeline Digital , was installed by the TARGA software into the “plug-ins”...

  • Page 69: Configuring Provtr

    Configuring ProVTR Configuration settings must be made within the ProVTR software before you can begin using device control for your specific deck. Once this is done, TARGA 3000 saves the parameters set for subsequent editing sessions. To configure ProVTR: From within Movie Capture of your video-editing application, select File Menu »...

  • Page 70: Vtr And Port Control

    Select the protocol from the Protocol drop-down list that matches your deck. The Protocol default is Sony RS-422, which matches the type of cable shipped with TARGA 3000. However, you may also choose Sony RS-232 (9.6K or 19.2K), Sony VISCA, Panasonic RS-232, or Addenda RS-4/L.

  • Page 71: Time Control

    Note: An RS-422 cable is supplied with TARGA 3000. If you want to use RS-232 instead, order the appropriate cable from Pipeline. Information on ordering from Pipeline Digital, the manufacturer of ProVTR, can be found at http://www.thepipe.com Additional information on using RS-232 can be...

  • Page 72: Digitize Adjustments

    Digitize Adjustments time code for frame-counting purposes. — TARGA 3000 requires a large time code offset. Additional -23 Frame Time Code Offset This option is designed to make time code calibration very easy for you. The value this option gives when enabled (checked) for time code calibration is valid for most VTRs. Refer to your video-editing application’s user guide for more information on calibrating time code...

  • Page 73: Provtr Technical Support

    correct connection is established, the following ProVTR splash screen will appear followed by ProVTR software controls for the VTR. (Refer to the Troubleshooting section of the ProVTR User Guide if device control is not established.) ProVTR Technical Support For technical support with ProVTR, refer to the Customer Support section of the Pinnacle Systems web site at: http://www.pinnaclesys.com Chapter 3: Configuring And Using Device Control...

  • Page 74: Chapter 4: Basic Targa 3000 Tutorial With Adobe Premiere

    Chapter 4: Basic TARGA 3000 Tutorial With Adobe Premiere Contents This Chapter contains the following sections: • Tutorial Introduction • Before You Begin This Tutorial • Lesson 1: Capturing Video • Lesson 2: Making Videos Pinnacle Systems TARGA 3000...

  • Page 75: Tutorial Introduction

    Tutorial Introduction This tutorial will guide you through the first use of your TARGA 3000 with Adobe ™ ® Premiere and Windows NT . For this tutorial it is assumed that you have a working knowledge of Windows NT and Adobe Premiere, that you are using NTSC equipment, and that you have a video and audio-editing software application (such as Adobe Premiere 5.1) already installed.

  • Page 76: Before You Begin This Tutorial

    Installation Guide.” For this tutorial, make sure you have configured your system as follows: — The Breakout Box that you are using should be connected to the TARGA 3000 card. — An active video source (e.g., VCR, video camera, or DVD player) should be connected to the video and audio inputs of the Breakout Box connected to the card.

  • Page 77: Lesson 1: Capturing Video

    — Launch Adobe Premiere (Start » Programs » Adobe » Premiere 5.1). Set Adobe Premiere Project Settings Before you can capture video with the TARGA 3000, various project settings need to be made within Adobe Premiere so that the TARGA 3000 “knows” what to do. The settings are for: •...
  • Page 78 During the TARGA 3000 software installation process, several TARGA project settings were installed into the Adobe Premiere settings directory. You can access these settings for either NTSC or PAL configurations by clicking the “Load” button on the General Settings Window.
  • Page 79 — Select the options as follows: • Compressor: Choose TARGA 3000 RGB, TARGA 3000 YUV, or TARGA 3000 DV25 • Frame Size: 720 h 486 v • Frame Rate: 29.97 • Quality: 100% The 4:3 Aspect setting (image size contrast) should be unchecked. Select the appropriate data format (i.e., compressor) for your input source device.
  • Page 80 Make sure that the audio rate conversion is set to “best,” and the audio rate /format for capture is 48 kHz/16 bit. — From the pull-down within the New Project Settings dialog window select KEYFRAME AND RENDERING OPTIONS Pinnacle Systems TARGA 3000...
  • Page 81 Keep it selected. When selected, a dialog window will appear after video capture displaying the number of frames dropped (if any) during the capture process. Next you need to set how the TARGA 3000 compresses and controls images. This is done by way of the TARGA Settings dialog window.

  • Page 82: Set Adobe Premiere Targa Settings

    Set Adobe Premiere TARGA Settings Once all the Project Settings have been made, you need to set how the TARGA 3000 compresses and controls images. This is done by way of the TARGA Settings dialog window. A detailed explanation of this panel and the selections that can be made in it can be found in “Chapter 2: TARGA Specific Control Panels Within Adobe...
  • Page 83 — From the pull down, select the video format that your input VIDEO INPUT SOURCE device is sending to the breakout box. If you have a TARGA 3000 Pro Analog Breakout Box, your choices are • Composite • REF •...
  • Page 84 B-Y color components. • R-Y Offset -- Adjustments made here cause a change in the DC level of the R-Y input, which will increase or decrease the balance of color in the R-Y color components. Pinnacle Systems TARGA 3000...
  • Page 85 • Brightness -- This is the amount of overall luminance perceived. Brightness is the intensity of the video level and refers to how much light is emitted by the display. This control slider affects all video output formats. Chapter 4: Basic TARGA 3000 Tutorial With Adobe...
  • Page 86 — Again, once video is seen on your output monitor, experiment with the slider controls to see the effects on the picture quality. When you're done experimenting with the sliders, click on the “Reset” button to move all of the sliders back to their factor default values. Pinnacle Systems TARGA 3000...
  • Page 87 — From the pull down, select the audio format that your input AUDIO INPUT SOURCE device is sending to the breakout box. If you have a TARGA 3000 Pro Analog Breakout Box, your choices are • Balanced (XLR) • Unbalanced (RCA) —The...

  • Page 88: Set Adobe Premiere Scratch Disk Preferences

    Your video needs to be recorded onto the fastest drive available to achieve the best quality video capture and playback, and with TARGA 3000 this will be the drive array configured into your system for video and audio. In Adobe Premiere incoming video, audio, and temporary files are recorded to your Scratch Disks.

  • Page 89: Optional: Using Device Control

    TARGA 3000. — Once you have selected the type of device control you want to use, and if necessary, configured the device control type, click to close the Scratch Disks/Device Control dialog. Chapter 4: Basic TARGA 3000 Tutorial With Adobe...

  • Page 90: Capturing Video

    (checked). Record Audio Option — A option is located in the menu. If you want to have RECORD AUDIO MOVIE CAPTURE audio with your video make sure that this option is enabled (checked). Pinnacle Systems TARGA 3000...

  • Page 91: Record Your Video

    Escape (Esc) key to stop. A “Clip Window” will appear. Playback and Save Clip —Click the play icon at the bottom of the Clip Window. The TARGA 3000 will playback the video at full size to the video monitor. Note that if playback overlay is enabled, the video can be played in the Clip Window.

  • Page 92: Lesson 2: Making Videos

    LESSON 2: MAKING VIDEOS Videos made in Adobe Premiere with TARGA 3000 are created from captured video clips. To begin making a video, you must first assemble the clips you wish to use into a Project file. The Project Window displays the clips in the Project file while you perform the various tasks of making your video.
  • Page 93 — Repeat this step with the second clip, but place the clip on Track “B,” and leave a short overlap with the clip on Track “A.” The Timeline Window should then look similar to this: Chapter 4: Basic TARGA 3000 Tutorial With Adobe...
  • Page 94 — You place a transition the same way you place a video clip, by “grabbing” it with the hand cursor. Drag (click and hold) the TARGA 3000 Transition icon to the overlap of the two video clips, on the track marked “Transitions.” Notice how, before the mouse button is released, the transition automatically sizes itself to fit the overlap.
  • Page 95 — For now, click to highlight the TARGA 3000 transition called “Wipe R To L.” You can use the “scrub slider” on the TARGA Effects Panel, or any of the play selected effect controls, to see the effect. Experiment to see how some of the other TARGA transitions work by clicking to highlight them, and then using the scrub slider or play effect controls to see the effect.
  • Page 96 Select a filter and then close the panel. Important: You cannot use a TARGA 3000 Filter as a transition by selecting a filter on the Transition track within Adobe Premiere. Instead, you can apply a filter directly to a clip on Video Track “A” or “B.”...

  • Page 97: Previewing Your Video

    Previewing Your Video The TARGA 3000 system works in real time, so in most instances you won't want to preview your video. If for some reason you need to preview however, do the following: — First stretch the Work Area bar (blue bar) at the top of the Timeline Window to the end of the final clip in your video.

  • Page 98: Saving Your Capture Settings

    Project Settings can be saved as follows: — Open the Project Settings dialog window by pulling down the PROJECT MENU scrolling to the submenu, and selecting . A dialog window similar SETTINGS GENERAL to the one below will be displayed: Pinnacle Systems TARGA 3000...
  • Page 99 — Click to close the Project Setting dialog window. — Save and close the Project window. You can use the saved Project settings to make TARGA 3000 videos in the future by pulling down the menu to the submenu, selecting...
  • Page 100 This concludes the tutorial. Anyone interested in a more comprehensive understanding of Adobe Premiere should consult the Adobe Premiere User’s Guide and Tutorial accompanying the Premiere software. Also available from Adobe is the “Classroom in a Book Series,” which includes a CD with several step by step tutorials. Pinnacle Systems TARGA 3000...
  • Page 101 Chapter 4: Basic TARGA 3000 Tutorial With Adobe...

  • Page 102: Chapter 5: Using Titledeko

    Deselecting Text And Objects • Formatting Text And Objects • Applying “Looks” To Text And Objects • Justifying Text • Layers • Tools And Selection Handles • Using And Modifying Looks And Styles • Making Backgrounds Pinnacle Systems TARGA 3000...

  • Page 103: About Titledeko

    About TitleDeko TitleDeko is a plug-in program that has been built into TARGA 3000, and is designed to work with Adobe Premiere and the TARGA 3000 card. As an integrated title editor program, TitleDeko allows you to quickly and easily create professional quality titles and graphics.

  • Page 104: Opening From The Premiere Main Menu Bar

    In the Project window, double-click the title icon of an existing TitleDeko title. CAUTION: Once TitleDeko is open, do NOT click on its icon in the Windows Taskbar and do NOT type Alt+Tab to switch applications. These actions will disconnect TitleDeko from Adobe Premiere. Pinnacle Systems TARGA 3000...

  • Page 105: The Titledeko User Interface

    The TitleDeko User Interface TitleDeko is a separate application with its own user interface that offers menus, windows and toolbars. TitleDeko windows follow standard Windows conventions so you can open, close, move and resize them. Also, TitleDeko provides for the following: •...

  • Page 106: Tool Functions

    Typographical characteristics can be manipulated by using the following: • Fonts • Look Browser • Edit Look -- Before you can change typographical characteristics, select the text you want to Fonts change. Click the drop-down list arrows to choose a typeface and its size. Pinnacle Systems TARGA 3000...

  • Page 107: Look Browser

    To preview the typeface before you select it, click the Typeface Browser button and then choose the face you want from the browser window. To make text bold, italic and/or underline, click the respective button. -- Click the Look Browser button to display a window that contains all the Look Browser preset looks.

  • Page 108: Alignment Browser Tools

    -- Click to insert an image from your hard disk or other media. Pictures are Insert Picture treated like other objects in that you can move, scale and size them. You cannot, however, skew or rotate a picture. Pinnacle Systems TARGA 3000...

  • Page 109: Replace Background

    -- Allows you to make adjustments to the color, opacity and other Replace Background details of the background. Additional Menu Commands The additional Menu Commands for TitleDeko are given below. -- From the main menu bar, select Transform > Coarse or Fine to change the Coarse / Fine increments used in cursor movement.

  • Page 110: Clear Selected Text And Select All

    Note: If you click on the red dashed line indicating the video-safe area, a similar looking box appears. However, this box is larger and surrounds the entire image. You have selected the image area, not the text. Pinnacle Systems TARGA 3000...

  • Page 111: Deselecting Text And Objects

    To select a single word or object: • Double-click the word or object. A selection border with handles appears around the word or object. • Use the arrow keys to move the cursor to the beginning or end of the word, then hold Shift and press the right or left arrow.

  • Page 112: Formatting Text And Objects

    To change text to bold, italic and/or underline: • Select the text to be changed. For bold, italic and underline, click the corresponding button in the Editor Menu bar, or use the shortcuts (Ctrl+B), (Ctrl+I) and (Ctrl+U). Pinnacle Systems TARGA 3000...

  • Page 113: Applying "Looks" To Text And Objects

    Applying “Looks” To Text And Objects One of TitleDeko’s most powerful features is its library of preset looks. Looks include color, texture and transparency attributes that are applied to the face, edge and shadow of objects. With a click of the mouse you can instantly change the appearance of an object from glowing purple neon to blue metallic.

  • Page 114: Justification Buttons

    Hold down the Ctrl key, and press one of the numbers on the numeric keypad to quickly justify text (and objects). Notice that the position of the marker in the grid button changes as do the Horizontal and Vertical Justification buttons. Pinnacle Systems TARGA 3000...

  • Page 115: Full Horizontal, Full Vertical And Spread Justification

    Full Horizontal, Full Vertical And Spread Justification Full horizontal justification makes the text flush or even with both the left and right sides of the text field box, except for the last line of text which remains left justified. Full verti- cal justification makes the text flush or even with both the top and bottom of the text field box.

  • Page 116: Kerning

    -- Click the Kerning/Leading button and select the text, then use the cursor Leading Tool to drag one of the handles above or below the text block. Moving The Move cursor indicates moving is enabled. It appears anywhere on the selection box except at the handles. Pinnacle Systems TARGA 3000...

  • Page 117: Resizing

    Resizing Corner handles control height and width together; middle handles on the right or left control width only; middle handles on the top or bottom control height only. Hold down Ctrl while dragging a corner handle during scaling to constrain the aspect ratio. In the following example, the word in the center has not been changed.

  • Page 118: Editing Looks

    Most of the Detail and Attribute (face, edge, and shadow) controls are obvious, so the following does not explain those in depth. In addition a small preview window in the lower left corner shows your adjustments, which makes it easy for you to experiment. Face Control Edge Control Shadow Control Pinnacle Systems TARGA 3000...
  • Page 119 Face, edge and shadow details have several items in common: • Choice of solid or gradient colors. These operate the same was as described later in this chapter in the section on Backgrounds. • A Blur slider, which varies the fuzziness of the face, edge or shadow detail. You can adjust the slider, or type in a precise number.

  • Page 120: Accessing The Style Window

    (no underlying video is visible), or semi-opaque (allowing the video to show through the color background). TitleDeko also allows the option of importing a picture to use as the background. Using Replace Background Window You control all aspects of the background with the Replace Background window. Pinnacle Systems TARGA 3000...

  • Page 121: Transparent Backgrounds

    -- Select “Background is transparent” to create a transparent Transparent Backgrounds title with no background. This is the default choice for Background. Note: When you import your title with a transparent background into Adobe Premiere, place it on the Video 2 track in the timeline. Premiere automatically applies a Black Alpha Matte to the title. -- To use a solid color as a background, select “Background is a Solid Color Backgrounds solid color.”...

  • Page 122: Picture Backgrounds

    Color button. The Color Picker appears. Except for opacity, the choices in this screen are self-explanatory and conform to Windows Color Picker standards. The following illustrations show that, as you adjust the Opacity slider down from 100%, the background becomes increasingly transparent. Pinnacle Systems TARGA 3000...
  • Page 123 Chapter 5: Using TitleDeko...

  • Page 124: Chapter 6 - Basic Titledeko Tutorial With Adobe Premiere

    This Chapter contains the following sections: • Tutorial Introduction • Lesson 1: Creating A Basic Title • Lesson 2: Enhancing The Text Of A Title • Lesson 3: Rolling A Title • Lesson 4: Creating A Scrollable Crawl Title Pinnacle Systems TARGA 3000...

  • Page 125: Tutorial Introduction

    Before You Begin This Tutorial Turn on all the hardware in your configuration. Make sure that your video output monitor is connected to the outputs of the Breakout Box connected to the TARGA 3000 card, and that the output monitor is powered and working.

  • Page 126: Lesson 1: Creating A Basic Title

    Set Adobe Premiere TARGA Settings Once all the Project Settings have been made for your system, you need to set how the TARGA 3000 compresses and controls images. This is done by way of the TARGA Settings dialog window. —From capture settings within the “New Project Settings” dialog window, click on the button.

  • Page 127: Set Adobe Premiere Scratch Disk Preferences

    Your video needs to be recorded onto the fastest drive available to achieve the best quality video capture and playback, and with TARGA 3000 this will be the drive array configured into your system for video and audio. In Adobe Premiere incoming video, audio, and temporary files are recorded to your Scratch Disks.
  • Page 128 — Type the words: “TARGA 3000” and then select all of the title text by pressing <Ctrl>+<A> on your keyboard. A selection box will appear around all of the text. Once the text is selected, you can apply one of the 24 preset styles provided by TitleDeko to the text.
  • Page 129 — Experiment with shrinking and enlarging the text. You can proportionally shrink or enlarge selected text by typing a new value into or clicking the arrow buttons of the font size indicator within the TitleDeko window. You can also proportionally shrink or enlarge text by enabling the Move/Resize tool button.
  • Page 130 — Scrub the Video 2 Timeline track, or click the play button on the Adobe Premiere Preview Window to see the title text on your output monitor. — Proceed to “Lesson 2: Enhancing The Text Of A Title.” Pinnacle Systems TARGA 3000...

  • Page 131: Lesson 2: Enhancing The Text Of A Title

    Lesson 2: Enhancing The Text Of A Title This lesson shows how to reposition, rotate, and skew a title. The lesson then shows how to add a shape behind the title and add a style to that shape. — The project icon of the title created in Lesson 1 should be on the Video 2 track in the Timeline Window of Adobe Premiere.
  • Page 132 — Scrub the Video 2 Timeline track, or click the play button on the Adobe Premiere Preview Window to see the enhanced title on your output monitor. — Delete the title icon from the Timeline track and proceed to “Lesson 3: Rolling A Title.” Pinnacle Systems TARGA 3000...

  • Page 133: Lesson 3: Rolling A Title

    The TitleDeko text entry window will open and a text I-Beam cursor will be displayed in that window. — Type the words: “TARGA 3000: First In Its Class. First In Video.” and then select all of the title text by pressing <Ctrl>+<A> on your keyboard. A selection box will appear around all of the text.
  • Page 134 Preview Window to see the enhanced title on your output monitor. You may want to experiment with various duration/speed settings until you are satisfied with the title roll. — Proceed to “Lesson 4: Creating A Scrollable Crawl.” Pinnacle Systems TARGA 3000...

  • Page 135: Lesson 4: Creating A Scrollable Crawl Title

    Lesson 4: Creating A Scrollable Crawl Title This lesson shows how to create a scrollable crawl with a title, which causes the title to crawl horizontally from the left of the screen toward the right. Also shown is how to set the time duration (trim) and speed of the title crawl.
  • Page 136 — Save the title as an Adobe Premiere project file. You may want to place the title file in front of the video file you created in “Chapter 4: Basic TARGA 3000 Tutorial With Adobe Premiere,” and experiment with producing a video with titles.
  • Page 137 Chapter 6: Basic TitleDeko Tutorial With Adobe Premiere...

  • Page 138: Appendix A: Targa 3000 Fx Guide

    The first part of this guide provides a description of TARGA 3000 effects and how to use each part of the interface. The second part of the guide walks through the construction of a number of typical effects as examples on using the editor.

  • Page 139: The Difference Between Filters And Transitions

    The Difference Between Filters And Transitions Transitions and filters are treated in very similar ways in the TARGA 3000. A transition is an effect that combines two video input sources, and a filter is an effect that modifies just a single input source. The output of a transition is a video frame while the output of a filter is a video frame and a key signal that indicates how it should be keyed over elements beneath it in the timeline.

  • Page 140: Layout Of The Effects Factory

    -- This area allows you to play and step through an effect and see the overlay. • Parameter Pages -- This area allows you to set the specific parameters of each effect. • Keyframer -- This area allows you to control the way effects evolve over time. Pinnacle Systems TARGA 3000...

  • Page 141: Tree Builder

    Although at first this may seem complicated, this mode of operation is one of the features that makes the TARGA 3000 a powerful creative tool; it is drawn more from the core technology of compositing systems than from traditional editing systems.

  • Page 142: Node Types

    In addition there is an “Empty” node which indicates that there is “space” to attach an additional node at this point. This is because the number of inputs to the two effects primitives is fixed by the hardware and does not change. Pinnacle Systems TARGA 3000...

  • Page 143: Editing Trees

    • Paste -- paste previously copied node to this location • Insert ...New Transform • Insert ...New Compositor • Replace with ...New Transform • Replace with ...New Compositor • Save sub-tree -- saves the effect underneath this node as a separate effect Appendix A: TARGA 3000 Effects Guide...
  • Page 144 Input A; however, if you are programming a transition, you can also choose Timeline Input B by right clicking on the timeline input node. • Insert Effect -- Allows you to nest effects by making the source to the current effect be the output of an existing effect. Pinnacle Systems TARGA 3000...

  • Page 145: Saving Effects

    • File Name -- Files should be saved as .pky files and stored in the appropriate subdirectory of the TARGA 3000 folder in your program files directory. • Description -- This is a free text area to describe the effect. When an effect is selected in the Picker, this description is displayed underneath the Transport (Scrub) Controls.

  • Page 146: Transport (Scrub) Controls

    Picker. This allows you to choose an alternative effect to edit from within the FX editor interface. Transform When you select a Transform node, you will see the following interface in the Parameter Page. Pinnacle Systems TARGA 3000...

  • Page 147: Shape

    This allows you to zoom in or out of the wireframe image. You will always see the blue rectangle which defines the viewable screen. Appendix A: TARGA 3000 Effects Guide...
  • Page 148 A number of graphics are provided with the TARGA 3000 which provide a variety of different types of soft edges. The soft edged graphic must be set as the second input to the transform processor and chosen as the key source in order for softness to become active.

  • Page 149: Color

    Color Color correction in the TARGA 3000 is performed via a “Look-up Table.” This is also known as curve based color correction. A graph represents the way in which input color values are translated into output color values. The color corrector allows you to perform fine adjustments to the colors of the image. The curve defines the input to output transfer function of the color components.
  • Page 150 • Clip and Gain -- Modify the clip and gain on the curve via sliders which will appear below the drop down box. • Contrast and Brightness -- Modify contrast and brightness of component via sliders. Pinnacle Systems TARGA 3000...

  • Page 151: Softness And The Graphic Input

    There are a number of different type of softness graphics that are shipped with the TARGA 3000 which appear in the graphics directory. Additional graphics can be added by using setup to add additional directories. These graphics can be used in creative ways to add sophisticated borders or other types of effect.

  • Page 152: Compositor

    Note: To see a larger viewport hold down the Z key and pull the grid with the mouse in the center of the viewport. This allows you to zoom in or out of the wireframe image. You will always see the blue rectangle which defines the viewable screen. Pinnacle Systems TARGA 3000...

  • Page 153: Mixer

    The Mixer provides some controls on how the images are layered together. Input 1 is layered over 2, which is layered over 3, which is then layered over the background (in the case of a filter). Appendix A: TARGA 3000 Effects Guide...
  • Page 154 -- Allows you to apply a tint to the image. The color of the tint is defined by the matte Tint color. -- Applies a monochrome tint to the image. Monochrome -- Reverses the image in the horizontal axis. Mirror -- Reverses the image in the vertical axis. Invert Pinnacle Systems TARGA 3000...

  • Page 155: Chroma Keyer

    Note that chroma keying is a fine art and it is hard to get perfect results. The TARGA 3000 chroma keyer can pull a good key off clean well-lit footage, but will be unable to perform perfect keys if the input is challenging. In cases where the key is too complex for the hardware keyer, we recommend you use the Primatte Keyer in the Commotion Pro package that accompanies some versions of the TARGA 3000.
  • Page 156 Typically you will start with gain to try to get a fully keyed background, and then adjust offset to work the edges. -- Allows you to remove specific spill colors from the Foreground Matte Removal foreground if needed. Pinnacle Systems TARGA 3000...

  • Page 157: Keyframer

    Keyframes are set independently for each node. When you select a node in the tree, then the keyframes for that node will appear as the larger circles in the timeline. Keyframes that are associated with other nodes in the tree appear as the smaller diamonds above the circles. Appendix A: TARGA 3000 Effects Guide...
  • Page 158 — Use the Add and Delete keyframes buttons to explicitly add and remove keyframes at specific positions. -- A number of different interpolation types are available in the drop Interpolation Types down list above the timeline. These can be set on a per keyframe basis. Pinnacle Systems TARGA 3000...

  • Page 159: Effects Factory Examples

    Effects Factory Examples This section provides a brief explanation of some pre-created effects that are provided with the TARGA 3000 along with explanations of how some parameters can be changed within these effects. Wipes Wipes have a set of hard-edged 2 or 4 sided 2D moves.

  • Page 160: Squeeze

    The function of each node is as follows: -- Mixes Foreground A which has passed through a transform with Background Compositor B which has done the same. -- Motion path of Foreground A. Transform -- Motion path of Background B. Transform Pinnacle Systems TARGA 3000...

  • Page 161: Fade Right Example

    -- Mixes Foreground A which passes through a number of transforms with Compositor Background B, which undergoes similar processing. -- The shape page performs the 2D squeeze of the Foreground A. Transform -- The shape page performs the 2D squeeze on the Background B. Transform Appendix A: TARGA 3000 Effects Guide...

  • Page 162: Squeeze S

    -- Adds softness to the edges of the input video by using the softness graphic Transform applied to the second input of the transform. -- Creates a soft edged border. Use the matte color in this node to change the Transform color of the border. Pinnacle Systems TARGA 3000...
  • Page 163 Appendix A: TARGA 3000 Effects Guide...

  • Page 164: Appendix B: Troubleshooting & Contacting Pinnacle Systems

    BIOS program and disable PCI Parity Checking. — Take out the TARGA 3000 card and try to boot. If the computer still will not boot, check that the processor card and all other cards are securely in place, and that all connections are good.
  • Page 165 You have a SCSI boot drive (internal) and an A/V drive (external). Your data rates are not acceptable and occasionally the system freezes and lockups. — Your problem is probably related to SCSI Termination. You should always use an active terminator on the end of your SCSI chain. Another problem in this scenario is that you may have placed your SCSI card in the middle of your SCSI chain.

  • Page 166: Irq Problems

    Remove any peripheral cards except for your VGA card, your SCSI controller card and your TARGA 3000. If this solves the speed issue then you can add back your other cards being careful to “manually”...

  • Page 167: Monitor Problems

    5. Check the cables. Make sure they are plugged into both the Pro Analog or Pro Digital Breakout Box and monitor. 6. Use the TARGA 3000 installation CD-ROM to uninstall the TARGA software and then reboot, reinstall the TARGA software, and reboot again.

  • Page 168: Video Capture Problems

    Video Capture Problems Capture not working 1. Reboot the system. 2. Place the TARGA 3000 card into a different slot. 3. Exit your video-making application and run the TARGA Tester program. The TARGA Tester program is found at the following path: »...

  • Page 169: Audio Problems

    4. Verify that audio was captured. 5. Check for possible IRQ conflicts in your system. 6. Check the audio output settings for the TARGA 3000. (For example, the settings could be set to RCA instead of XLR). You record audio in mono, but when you play back there doesn’t seem to be any audio.

  • Page 170: Playback Problems

    2. Make sure the TARGA software is correctly installed. 3. Reinstall the video-editing software because it may have become corrupted. 4. If other video clips captured with the TARGA 3000 play back correctly, the file could have become corrupted or fragmented. Delete and recapture the clip.

  • Page 171: Pinnacle Systems Customer Satisfaction Center

    Pinnacle Systems Customer Satisfaction Center You can contact the Pinnacle Systems Customer Satisfaction Center (next page) for additional help. Before contacting the Customer Satisfaction Center, please complete the Troubleshooting Questionnaire below and have the answers ready before you contact us. On-line services are available 24 hours per day.

  • Page 172: Contacting Pinnacle Systems

    (317) 576-7770 Worldwide: (317) 594-2900 Telephone Contact Sales Information: (800) 522-8783 within United States and Canada Technical Support: (317) 577-8788 Note: This information is subject to change. Check www.pinnaclesys.com on the web for the latest contact information. Pinnacle Systems TARGA 3000...
  • Page 173 Appendix B: Troubleshooting & Contacting Pinnacle Systems...

  • Page 174: Appendix C: Targa 3000 Technical Specifications

    Appendix C: TARGA 3000 Technical Specifications Technical Specifications The specifications for the TARGA 3000 are divided into three sections within this Appendix: • TARGA 3000 Card Only • Pro Analog Breakout Box Only • Pro Digital Breakout Box Only TARGA 3000 Card Only General Card Size ........12.3"...
  • Page 175 Compression/Decompression Standard..........DV25 or MPEG2 DV 1394 Connector ........200mVp-p, 6-pin and 4-pin IEEE-1394 16/12 bit Resolution........Input Source ........4:1:1 for NTSC sources and 4:2:0 for PAL sources Appendix C: TARGA 3000 Technical Specifications...

  • Page 176: Targa 3000 Pro Analog Breakout Box Only

    TARGA 3000 Pro Analog Breakout Box Only General Width -- 12.0" ( 19.0" w/rack mount bracket) Height -- 3.5" Depth -- 3.8" Weight -- 2.5 lb. (1.0 Kg.) Power Supply -- Power is suppled from T3000 digital tether cable Input Current...
  • Page 177 -- Output gain offset & saturation control 1.0 V p-p, 75 Ω, BNC +/- 350mVp-p, 75 Ω, BNC +/- 350mVp-p, 75 Ω, BNC * Levels are based on NTSC 100% white, 75% fully saturated bars. Appendix C: TARGA 3000 Technical Specifications...
  • Page 178 -- 24 bit DAC resolution Unbalanced Outputs -- Channel 1 (left) 1 x RCA, -10 dBu nominal -- Channel 2 (right) 1 x RCA, -10 dBu nominal -- Headroom 28 dBu above nominal -- 24 bit DAC resolution Pinnacle Systems TARGA 3000...

  • Page 179: Targa 3000 Pro Digital Breakout Box Only

    TARGA 3000 Pro Digital Breakout Box Only General Width -- 2.2" Height -- 3.7" Depth -- 0.9" Weight -- 2.5 oz. (0.34 Kg.) Power Supply -- Power is suppled from T3000 digital tether cable -- 1.8 watts typical Ambient Temperature -- Operating at 0 to 40°...
  • Page 180 -- 48 kHz Resolution -- 20 bits/sample SDI Embedded Audio Output Standards Conformance -- SMPTE 272M Number Of Channels -- 8 channels in 2 groups; 4 AES/EBU audio pairs Frequency -- 48 kHz Resolution -- 20 bits/sample Pinnacle Systems TARGA 3000...
  • Page 181 Appendix C: TARGA 3000 Technical Specifications...

  • Page 182: Index

    Compiling Movies 82 Component (Effects) 135 Component (YUV) video 7 B-Y Gain 34, 36, 69, 71 Composite 32 B-Y Offset 34, 69 Composite Video 7 Background Colors (TitleDeko) 107 Compositor 126, 127, 128 Backgrounds (TitleDeko) 105, 106 Pinnacle Systems TARGA 3000...
  • Page 183 Compositor (Effects) 137 Device Control Tips (DV 1394) 51 Compression 21 Digitize Adjustments 57 Compression/Decompression 160 Digitizer 67 Compressor 64 Disk Array 17 Configuring Device Control 49, 50 Disk Storage 5, 10 Configuring ProVTR 49, 54 Drop Frame Time Code 52 Connector 159 Drop frames 153 Construction Window 80, 81...
  • Page 184 Keyframe Settings 62, 111 Gradient Backgrounds (TitleDeko) 106 Keyframer 125, 142 Gradient wipe, Premiere 15 Graphic Image Files 15 Graphic Input (Effects) 136 Graphics 15, 16 Latency 20 Graphics Input (Effects) 127 Group Of Pictures 30 Pinnacle Systems TARGA 3000...
  • Page 185 Layer Mixing 127 MPEG Output Type 29 Layers (TitleDeko) 87, 100 MPEG-2 Capture 1 Leading (TitleDeko) 101 MPEG-2 Editing 1 Left Audio Channel. 39 MPEG-2 Export 1 Length Area (Effects Panel) 46 MPEG-2 Format 1, 30 License Agreement xi MPEG2 ES 29 Limitation Of Liabilities xi MPEG2 PS 29 Limited Warranty xi...
  • Page 186 Project File 77 ScH Phase 37, 71 Project Settings 83 Scratch Disk Preferences 73, 112 Project Window 77, 78 Scrub Control Area (Effects Panel) 45 ProVTR 2, 3, 53 Scrub Field Dominance 27 ProVTR Technical Support 49, 58 Pinnacle Systems TARGA 3000...
  • Page 187 TARGA 3000 Effects Panel 23 Settings (Performance Monitor) 42 TARGA 3000 Filters 81 Setup Button (Effects Panel) 47 TARGA 3000 Pro Analog Breakout Box 161 Shape (Effects) 132 TARGA 3000 Pro Digital Breakout Box 164 Sharpness 36, 71 TARGA 3000 Transition 80...
  • Page 188 Tree Builder 125 Troubleshooting 3, 149, 156 Warnings (Performance Monitor) 43 Troubleshooting Questionnaire 156, 157 Warranty Disclaimer xi TrueType Fonts 2 Windows NT 60 Truevision Technical Support 61 Wipes (Effects) 144 Tutorial 60, 110 Typographical Characteristics (TitleDeko) 91 Pinnacle Systems TARGA 3000...
  • Page 189 YUV 32, 67 YUV 4:2:2 26 Index...

Table of Contents
