- Page 1 INSTRUCTION MANUAL SAFETINEX SAFETY LIGHT CURTAINS HAND PROTECTION, TYPE 2...
- Page 2 ESP - Este manual está disponible para su descargar desde nuestro sitio web en varios idiomas, incluyendo el español: PT - Este manual está disponível para descarregar a partir do nosso sítio Web em muitas línguas, incluindo o português: http://www.contrinex.com/download/#anchor_manuals Contrinex Industrial Electronics...
-
Page 3: Table Of Contents
Safeguarding function ..............6 Hazardous area ................6 AOPD detection capability ............6 Advantages of AOPDs .................7 Operating principle ................7 Certification of Safetinex products ............8 EUROPEAN SAFETY STANDARDS ......Types of safety standards applicable in the EU ........8 Examples of safety standards ..............9 An approach to European standards ...........9... - Page 4 TECHNICAL DOCUMENTATION ........Safetinex YBB for hand protection .............27 Advantages of the Safetinex range ............27 Scope of this technical documentation ..........28 Operating principle ................28 Self protected outputs ................28 Resolution (R) of an AOPD ..............29 LED status indicators .................30 Configurable functions ...............30 Test mode selection (YBB) ............30...
-
Page 5: Introduction
SAFETINEX SAFETY SYSTEMS The Safetinex product lines produced by Contrinex offer high quality safeguarding solutions for both personnel and machinery. Our special- ists in sensor technology have developed high-performance electro- sensitive protective equipment. -
Page 6: Safeguarding Function
Point of operation: detection of hands entering the defined hazard- ous area. The protective equipment immediately stops the machine or renders it harmless. The Safetinex YBB range is best suited for this type of application. In both cases, the primary function of the protective device is to stop the machine before the hazardous point is reached and to prevent un- intentional machine start-up or restart. -
Page 7: Advantages Of Aopds
(or transmitter) and a receiver. The protective field is the area enclosed by these two components, the emitted light beams form- ing a permanent, though invisible, shield between the two units. The Resolution (R) Receiver Emitter Protective field Operating distance (d) FIG. 2: OPERATING PRINCIPLE Contrinex Industrial Electronics... -
Page 8: Certification Of Safetinex Products
CERTIFICATION OF SAFETINEX PRODUCTS Safetinex products satisfy all the requirements of category 2, PL c, ac- cording to EN / ISO 13849 - 1:2006 (formerly EN 954-1) and Type 2 according to EN / IEC 61496 - 1 and - 2. -
Page 9: Examples Of Safety Standards
The European Union has chosen to regulate the production, installation and use of old, modified and new machines within the European Union territory by approaching the parties concerned separately, i.e. one legal framework has been created for users and another for manufacturers. Contrinex Industrial Electronics... -
Page 10: The User Side
Additionally, the Work Equipment Directive specifies what minimum regulations must be observed for safety purposes when work equip- ment is being used. The original text can be found on the relevant Eu- ropean Union website. Contrinex Industrial Electronics... -
Page 11: Machine Manufacturer Side
An official list of notified bodies responsible for assessing products in com- pliance with the Machinery Directive can also be found on the relevant European Union website. Contrinex Industrial Electronics... -
Page 12: North American Safety Standards
Information on both state plans and OSHA regulations may be obtained from their respective websites. OSHA uses national consensus standards to further define machine protection requirements in addition to subpart O. In 1910.212, it states that “The point of operation of machines whose operation exposes an Contrinex Industrial Electronics... -
Page 13: North American Standards For Safety Issues: Ul, Ansi And Csa
ANSI/UL standards. For instance, ANSI standards include ANSI B 11.19: Standard for per- formance of safeguarding devices and ANSI/RIA R15.06: Standard for robot safety. For more details on the ANSI Standards, please visit the ANSI website. Contrinex Industrial Electronics... -
Page 14: Canadian Standard Agencies
ISO is an international federation of national standardization bodies. ISO and IEC influence international standards through formal relationships. In the US, ANSI coordinates with ISO and IEC through technical advisory groups (TAG). Contrinex Industrial Electronics... -
Page 15: Risk Assessment
ANSI/RIA R15.06-1999, Safety Requirements for Industrial Robots and Robot Systems – ANSI B11.TR3, Risk Assessment and Risk Reduction – EN/ISO 14121, Principles of Risk Assessment. EN/ISO 14121 re- fers to additional standards, such as EN/ISO 13849-1 and EN/ISO 12100 Contrinex Industrial Electronics... - Page 16 It is important to document this procedure as evidence that the task has been fully carried out and to allow others to check it or use it for further improve- ments. Contrinex Industrial Electronics...
- Page 17 It is there- fore important to conduct regular inspections in order to detect defects that may lead to reduced safety, and to effect the necessary repairs before the level of risk exceeds the original assessment. Contrinex Industrial Electronics...
-
Page 18: Methods For Determination Of Risk Level
EN/ISO 13849-1 sets out a procedure for the selection and design of safety measures. The procedure contains the following 6 steps: 1. Identify the safety functions to be performed 2. Determine the required Performance Level 3. Design and technical realisation of the safety functions Contrinex Industrial Electronics... - Page 19 ) to an appropriate level, a safety system with performance level PL ≥ PL needs to be properly implemented. A corresponding average probability of dangerous failure per hour (PFH ) can be associated with each performance level : Contrinex Industrial Electronics...
-
Page 20: Specific Standards For Safety Distance Calculation
≤ PFH < 10 TABLE 4 : AVERAGE PROBABILITY OF DANGEROUS FAILURE PER HOUR All Safetinex Type 2 AOPDs fully comply to Performance Level c. For details, please consult the product data sheet. SPECIFIC STANDARDS FOR SAFETY DISTANCE CALCULATION EN/ISO 13855 EN/ISO 13855 gives details concerning the positioning of safeguards with respect to the approach speeds of parts of the human body. -
Page 21: Minimum Safety Distance Required
The following methodology, based on EN/ISO 13855, can be used to determine the proper minimum safety distance: Contrinex Industrial Electronics... -
Page 22: Minimum Safety Distance Calculation (Eu)
2. The total response time of the safety system : a. Response time of the AOPD b. Response time of the safety control unit c. Machine stopping time (effective stopping of the machine’s dangerous movement) d. Any additional response delay 3. Resolution of the AOPD Contrinex Industrial Electronics... - Page 23 In the case of horizontal positioning of the protective device (parallel approach) or if the angle between the protective field and the direction of entry is less than 30°, the applicable formula is: Contrinex Industrial Electronics...
-
Page 24: Minimum Safety Distance Calculation (Us & Canada)
ANSI/RIA R15.06-1999 – CSA/CAN Z142-02 – Code of Federal Regulations (OSHA) Subpart O, Volume 29 Part FIG. 6: MINIMUM SAFETY DISTANCE (US & 1910.217 (h) (9) (v) entitled “Machine Safeguarding” CANADA) PERPENDICULAR APPROACH PARALLEL APPROACH ANGULAR APPROACH Contrinex Industrial Electronics... -
Page 25: Other Countries
Union and the United States of America are determined by national law-making bodies. For the correct use and installation of Safetinex products outside the European Union and the United States of America please consult the relevant national standards and directives. -
Page 26: Acronyms
Mean Time To Dangerous Failure NFPA National Fire Protection Association Original Equipment Manufacturer OSHA Occupational Safety and Health Administration OSSD Output Signal Switching Device Programmable Electronic Systems Programmable Logic Controller Technical Specification TÜV Technischer Überwachungsverein Underwriters Laboratories Inc. Contrinex Industrial Electronics... -
Page 27: Technical Documentation
Operating distance up to 12 m – M12 Connector Safetinex light curtains, Type 2 and Performance Level PL c. Each ele- ment is mounted in a robust aluminum profile housing, equipped with two side mounting rails. The Safetinex product range is complemented by a range of acces- sories. -
Page 28: Scope Of This Technical Documentation
SCOPE OF THIS TECHNICAL DOCUMENTATION This section contains useful information for the selection, installation, operation and maintenance of Safetinex light curtains and access con- trol barriers. It is intended for skilled personnel with a knowledge of safety issues and electronic equipment. For safety compliance of your installation, please refer to the relevant standards and directives. -
Page 29: Resolution (R) Of An Aopd
FIG. 8: RESOLUTION R OF AN AOPD Safetinex YBB light curtains Type 2 have a resolution of 30 mm. De- tails and information required for ordering are set out on the ‘Available Models’... -
Page 30: Led Status Indicators
Table 5 below shows the test functions triggered by the pin connections on the sender unit. Contrinex Industrial Electronics... -
Page 31: Installation
Other basic safety installation rules include preventing access to the point of hazard through the correct positioning of the protective screen. Installation of Safetinex protective devices involves the following steps: – Calculation of the minimum safety distance –... -
Page 32: Positioning The Sender And Receiver Units
“L” shape, one vertical and one horizon- tal, are necessary. SAFE FIG. 11: L-SHAPED INSTALLATION OF THE LIGHT CURTAIN For practical details on L-shaped installations, please consult the rel- evant paragraph on page 35. Contrinex Industrial Electronics... -
Page 33: Distance From Reflective Surfaces
The longer the operating distance, the further away re- flective surfaces must be kept from the protective field. Reflective surface FIG. 12: DISTANCE BETWEEN REFLECTIVE SURFACE AND PROTECTIVE FIELD IS TOO SHORT; A REFLECTED BEAM UNINTENTIONALLY REACHES THE RECEIVER Contrinex Industrial Electronics... -
Page 34: Installation Of Multiple Systems
Installing several pairs of AOPDs close to each other may lead to optical crosstalk and result in failing to identify objects within the protective field (Fig. 14). Receiver Receiver Emitter Emitter FIG. 14: INTERFERENCE BETWEEN TWO PAIRS OF PROTECTIVE DEVICES Contrinex Industrial Electronics... -
Page 35: Mechanical Installation
The appropriate mounting devices must be used to fix the units. De- pending on the application and the available space, two different mounting options are available: Contrinex Industrial Electronics... - Page 36 To ensure firm alignment, the fixing points must be set in relation to the length of the device and as close as possible to the unit’s ends. FIG. 19 : T-NUT (REF. YXW-0003-000) FIG. 20 : USING T-NUT WITH M5 SCREW Contrinex Industrial Electronics...
-
Page 37: Connecting The Protective Device
ELECTROMAGNETIC COMPATIBILITY (EMC) In terms of immunity to electromagnetic fields, Safetinex protective de- vices fully comply with EN 55011/A2 and EN 61000-6-4 (electrostatic discharge, electrical and radio-frequency disturbances). Proximity to potential electromagnetic interference is acceptable within the limits of these standards. -
Page 38: Pin Assignment
Earth Earth TABLE 6: M12 PIN ASSIGNMENT Important note applicable to all Safetinex YBB models: The same power supply must be used for the safety relay and both AOPD units. If this is not possible and these devices are connected to galvanically separated power supplies, then the 0V contact of the AOPD units and the A2(-) contact of the safety relay must be bridged. -
Page 39: Safetinex Safety Relay Yrb-4Eml-31S
SAFETINEX SAFETY RELAY YRB-4EML-31S As a part of the Safetinex product line, the safety relay YRB-4EML- 31S can be used to connect YBB protective devices to the machine control system. The relay complies with the requirements of Category 4 / Performance Level e according to EN/ISO 13849-1. It can be used in applications up to Category 4 / Performance Level e according to EN/ ISO 13849-1 and SIL 3 according to EN 62061. -
Page 40: Connection Examples For Yrb-4Eml-31S Safety Relay
= 24 V FIG. 24: SEQUENCE OF RELAY SWITCHING OPERATION CONNECTION EXAMPLES FOR YRB-4EML-31S SAFETY RELAY Below are two typical examples for connecting a Safetinex AOPD, us- ing channel 1, to a Safetinex YRB-4EML-31S relay: 1 - For Manual Restart mode:... -
Page 41: Alignment Of Sender And Receiver Unit
Make sure the machine remains switched off. The alignment process is facilitated by the dedicated orange LED indi- cator on the sender unit. Figure 27 shows how the LED behaves during the alignment process. Contrinex Industrial Electronics... -
Page 42: Test Before The First Commissioning
TEST BEFORE THE FIRST COMMISSIONING Before connecting OSSD1 and OSSD2 to the machine control, per- form the “Daily functional test” as described in chapter “Testing and maintenance” below. This final test ensures that the protective device is operating properly. Contrinex Industrial Electronics... -
Page 43: Testing And Maintenance
Use a daily testing log file as printed on page 46 of this manual to make sure the test is carried out on a daily basis. FIG. 28: DAILY ROD TEST * Please note that, according to IEC 61496-2, the maximum rod speed must not exceed 1.6 m/s. Contrinex Industrial Electronics... -
Page 44: Troubleshooting
Ensure that OSSDs are OSSD2 neither shorted together, or OSSD short-circuit remain on in red nor connected to 0V or The sender’s LEDs are 24VDC. off, excluding the Power or device malfunction Return unit for revision. TABLE 7: TROUBLESHOOTING Contrinex Industrial Electronics... -
Page 45: Preventive Periodic Inspections
– Test the protective field: Perform the daily functional test as de- scribed above. If any of the above tests have failed, block the machine immediately to prevent its use and notify the supervisor. Contrinex Industrial Electronics... - Page 46 / fail pass / fail pass / fail pass / fail pass / fail pass / fail pass / fail pass / fail pass / fail pass / fail pass / fail TABLE 8: DAILY TESTING LOG FILE Contrinex Industrial Electronics...
-
Page 47: Available Models
1253 1283 YBB-30x2-1300-G012 1311 1382 1412 YBB-30x2-1400-G012 1440 1511 1541 YBB-30x2-1600-G012 1569 1640 1670 YBB-30x2-1700-G012 1698 1769 1799 YBB-30x2-1800-G012 1827 1898 1928 = S for sender / R for receiver / K for kit (sender + receiver) Contrinex Industrial Electronics... -
Page 48: Technical Data
– This instruction manual is part of the Safetinex light curtain. It must re- main accessible during its whole life cycle for anybody in charge of in- stallation, operation, maintenance, cleaning and safety control. - Page 49 – The log file presented in this manual must be used to document the regular testing of Safetinex products. Contrinex AG declines any re- sponsibility if the test procedure has not been carried out as prescribed in this instruction manual and fully documented in the log file. Testing ensures that the light curtain and the machine control system properly stop the machine.
-
Page 50: Ec Declaration Of Conformity
EC DECLARATION OF CONFORMITY Contrinex Industrial Electronics... - Page 51 Contrinex Industrial Electronics...
- Page 52 CONTRINEX HEADQUARTERS Industrial Electronic route du Paqui 5 - PO Box - CH 1720 Corminboeuf - Switzerland Tel: +41 26 460 46 46 - Fax: +41 26 460 46 40 Internet: www.contrinex.com - E-mail: info@contrinex.com www.contrinex.com © CONTRINEX AG 2017 INS_107/V1...
