Summary of Contents for Level Pro NC30-10
- Page 1 INSTRUCTION MANUAL industrial electronics NC SERIES | Thru-Wall Level Switch Read carefully the instructions published in this manual before the fi rst use of the sensor. Keep the manual at a safe place. The manufacturer reserves the right to implement changes without prior notice...
-
Page 2: Table Of Contents
CONTENTS Product description ......................2 Features of variants .....................2 Technical specifications ....................2 Dimension drawings ....................3 Recommended range of application ................4 Unsuitable range of application...................4 Procedure for put sensor into operation ..............4 1. Installation .......................4 2. Electrical connection....................5 3. Sensor settings ......................6 Status signalization......................7 Order code........................8 Correct specification examples..................8 Accessories .........................8... -
Page 3: Product Description
EaTurES OF variaNTS Prismatic (refracted) electrode, shape-adapted to be attached NC30-10 to the gauging pipe or other tube. The fixing of the sensor onto a pipe is provided by plastic straps. •... -
Page 4: Dimension Drawings
Sensitive spot for setting cable Electrode Variant "C" with connector NC30-10 NC30-11 Magnetic pen PM–8 ECOmmENdEd raNgE OF aPPliCaTiON Detection of various types of liquids - water, disel, oil, cooling liquids, water solutions, some types of solvents. It is suitable for glass or plastic gauge-pipes, vessels, plastic... -
Page 5: Recommended Range Of Application
FOr PuT SENSOr iNTO OPEraTiON 1. i NSTallaTiON a) The sensor type NC30-10, which is intended to point level detection on plastic or glass and gauge-tubes. The sensor is fixed to the gauge pipe or tube by means of two plastic straps (2.5 mm width). -
Page 6: Electrical Connection
2. E lECTriCal CONNECTiON a) The type of sensor NC30-11-S Positive pole (+U) of power supply is connected through a load (relay) to brown wire or pin connector No. 1, negative pole is connected to while wire or pin connector No.3. Connection scheme of sensor with “S“... -
Page 7: Sensor Settings
3. S ENSOr SETTiNgS The setting is done by placing of magnetic pen PM-8 to sensitive spot located on the front of the sensor. Short time attaching (up to 2 sec.) Sensitive spot of the magnetic pen to the sensitive spot makes the sensor open. -
Page 8: Status Signalization
Mode C (normally closed) Put the level of the measured medium in the state below the lower edge of the sensor in the tank or in the gauge-pipe. Attach the magnetic pen PM-8 on the sensitive spot for minimum 4 seconds. -
Page 9: Order Code
rdEr COdE NC30 – – – cable Length of cable in meters (variant “A“) P – PNP (open collector) Type of output: S – 2-wire electronic switch A – cable outlet (+ Spec. the length of the cable) Electric connection: C –... - Page 10 Warranty, Returns and Limitations WARRANTY Icon Process Controls Ltd warrants to the original purchaser of its products that such products will be free from defects in material and workmanship under normal use and service in accordance with instructions furnished by Icon Process Controls Ltd for a period of one years from the date of sale of such products. Icon Process Controls Ltd obligation under this warranty is solely and exclusively limited to the repair or replacement, at Icon Process Controls Ltd option, of the products or components, which Icon Process Controls Ltd examination determines to its satisfaction to be defective in material or workmanship within the warranty period.
- Page 11 ICON Corrosion-Free Liquid Process Instrumentation Equipment PROCESS CONTROLS Flow Level Pressure Temperature...
