Field Tuff FTF-48C3PT Owner's Manual

48” 3pt cultivator
Hide thumbs
1
2
3
4
5
6
7

Advertisement

Table of Contents

48" 3PT CULTIVATOR
OWNER'S MANUAL
WARNING:
Carefully read and understand all ASSEMBLY AND OPERATION
INSTRUCTIONS before operating. Failure to follow the safety rules and other
basic safety precautions may result in serious personal injury.
Item# FTF-48C3PT
03242016

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FTF-48C3PT and is the answer not in the manual?

Questions and answers

Summary of Contents for Field Tuff FTF-48C3PT

  • Page 1 48” 3PT CULTIVATOR OWNER’S MANUAL WARNING: Carefully read and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item# FTF-48C3PT 03242016...

  • Page 2: Intended Use

    Thank you very much for choosing this product! For future reference, please complete the owner’s record below: Model: FTF-48C3PT Purchase Date: _______________ Save the receipt, the warranty, and these instructions. It is important that you read the entire manual to become familiar with this product before you begin using it.

  • Page 3: Work Area

    WORK AREA • Keep work area clean, free of clutter, and well lit. Cluttered and dark work areas can cause accidents. • Keep children and bystanders away while operating a Cultivator. Distractions can cause you to lose control, so visitors should remain at a safe distance from the work area. •...
  • Page 4 ASSEMBLY Step #1: Assemble the two Extension Tubes (#16) to the Frame (#1), using two Hex Bolts (#14) and two Hex Lock Nuts (#6). Step #2: Assemble seven S-tines (#9) to the Frame (#1), using seven Hex Bolts (#7), seven S-tine Brackets (#8), and seven Hex Lock Nuts (#6).

  • Page 5: Maintenance

    Step #3: Attached two Long Support Brackets (#3) to the Frame (#1), using two Hex Bolts (#14) and two Hex Lock Nuts (#6). Step #4: Attach two Short Support Brackets (#4) to the Frame (#1), using two Hex Bolts (#15) and two Hex Lock Nuts (#6).

  • Page 6: Diagram & Parts List

    DIAGRAM & PARTS LIST Part # Description Qty. Part # Description Qty. Frame S-tine Hex Bolt M12*110 Shovel Long Support Bracket Bolt M10*35 Short Support Bracket Spring Washer Spacer Hex Nut M10 Hex Lock Nut M12 Hex Bolt M12*65 Hex Bolt M12*90 Hex Bolt M12*35 S-tine Bracket Extension Tube...

  • Page 7: Warranty

    WARRANTY One-year limited parts warranty. PO BOX 203 Miltona, MN 56354 Made in China Page of 7...
