Summary of Contents for Jetboards KYMERA BODY BOARD
- Page 1 KYMERA BODY BOARD USER AND SAFETY MANUAL Please keep this manual in a safe and easily accessible place...
-
Page 2: Contact Info
There is no substitute for good judgement. Always operate within your limits. contact info: info@jetboards.mx Jetboards.mx... -
Page 3: Getting Started
USER AND SAFETY MANUAL - kymera GETTING STARTED Always - Wear a USCG approved type III life vest. - Inspect battery case, connectors, etc. for signs of damage. - Be aware of your surroundings, scan constantly for vessels, people, and other obstructions. - Maintain a safe visual distance from shore. -
Page 4: Read Before Operation
USER AND SAFETY MANUAL - kymera GETTING STARTED READ BEFORE OPERATION After unpacking all system components, inspect each for any signs of damage or defect, if any are found contact your representative before proceeding. Charging - Your battery will arrive partially charged - Battery level should be checked every 60 - Charge your battery fully before use days or more when possible to maximize... - Page 5 USER AND SAFETY MANUAL - kymera In a secure location away from all flammable materials locate an appropriate power outlet. Verify charger input voltage located on the top label. The AC voltage will be indicated by a red box next to either 90~130 or 200-260.
-
Page 6: Battery Storage
USER AND SAFETY MANUAL - kymera BATTERY STORAGE The battery should never be left fully charged when not in use for an extended period of time. If storing for more than (1) week make sure and discharge your battery to between 50%~53V. When charging to store the chager should be stopped when it reads aprox 55V. - Page 7 USER AND SAFETY MANUAL - kymera battery installation Open front hatch and insert Slide the battery back until the battery tail first into the tray battery sits flat in the tray With the power switch OFF, locate Rotate the battery locking bar to its power plug and insert into the full up right and locked position battery receptacle, making sure...
-
Page 8: Know Before You Go
USER AND SAFETY MANUAL - kymera know before you go It is the operator’s sole responsibility to know and follow any and all rules / regulations related to operation in any given water way. Each state / country and sometimes even county or specific water way can have their own regulaion so its critical to contact the proper authorities prior to operation. - Page 9 USER AND SAFETY MANUAL - kymera launching kymera - Adult supervision is required Ensure a USCG approved life vest is properly worn and secured before entering the water. Verify the hatches are secured and place the board in the water. Once in knee to waist deep water press up and down on the tail of the board repeatedly, flushing water through the pump clearing any sand or debris that may have entered.
- Page 10 USER AND SAFETY MANUAL - kymera from side to side and front to back. Also shifting more weight on a knee will react differently than just leaning. The learning curve can typically take from 5~20min but quickly becomes extremely intuitive, and soon it will feel as though simply thinking a direction will cause the deisred reaction.
- Page 11 KYMERA maintenance - Adult supervision is required. Properly cleaning and maintaining your Kymera body board is important to the longevity of the product. Do not ride Kymera in shallow water, or in water with high particulate (sand/dirt).
- Page 12 USER AND SAFETY MANUAL - kymera problems during use If for any reason you believe your battery may have become damaged, do not attempt to open or modify it in any way. Discontinue use, move it to a safe location if possible and contact your local Kymera representative for assistance.
- Page 13 USER AND SAFETY MANUAL - kymera Repeated, prolonged submersion may also result in water ingress through the throttle control cable. This may result in throttle malfunction or failure. If the board has been subjected to such conditions the board should be inspected and cleared of any water and dried completely before continuing operation.
