- Page 1 ASSEMBLY INSTRUCTIONS Workbench With 1 Door and 3 Drawers TSK7513/TSK7513-L CAUTION: Read all instructions and safety tips before using this product.
-
Page 2: Parts List
PARTS LIST Part Description Quantity Part Description Quantity Left Door Left Side Shelf Right Side Back Bottom Leg Leveler Assembly Left Support Left Slide Right Support Right Slide Drawer... -
Page 3: Hardware Contents
HARDWARE CONTENTS Part Description Quantity Part Description Quantity Bolts ST4.8x10 mm 12+2 Plastic Pin a 12+2pcs b 4pcs CAUTION 1.Before assembling parts,please check the parts quantity according to the PARTS LIST. 2.Carefully unpack and spread out all parts in a large uncluttered area. 3.Familiarize yourself with all parts and compare them with the drawing below to make sure none are missing.Read all assembly instructions before beginning. - Page 4 ※ Step 1 a X4...
- Page 5 ※ Step 2 a X4...
- Page 6 ※ Step 3 a X4...
- Page 7 ※ Step 4...
- Page 8 ※ Step 5 Flick the plastic clips on the inside slide to detach the inside slide from the outside slide. Right outside slide Right inside slide Left outside Left inside slide slide...
- Page 9 ※ Step 6...
- Page 10 ※ Step 7 b X4...
