Summary of Contents for QUARTA RADEX RD1706
- Page 1 RADIATION MONITOR RADEX RD1706 OPERATING MANUAL...
- Page 3 Radiation monitor RADEX RD1706, hereinafter referred to as device, is designed for detection and evaluation of the level of ionizing radiation hereinafter referred to as irradiation. The device evaluates radiation environment by the magnitude of the ambient equivalent of dose rate Н*(10) of gamma radiation (hereinafter referred as a dose rate) with...
-
Page 4: Table Of Contents
TABLE OF CONTENTS Precaution measure s........Physical configuration ....... Display format in monitoring and background modes ........Operating mode ......... Monitoring mode ........Menu mode ..........LEVELS ........BACKGROUND ..... SETUP ........SERVICE ......... Background mode ........Preparations for using ........ -
Page 5: Precaution Measure S
If the product wets, immediately switch off the device and apply to «QUARTA-RAD» Ltd. If a small amount of water has reached its surface or it was exposed to salty air it is necessary to switch off a product, to wipe it with dry fabric, to place it in a warm dry premise and to dry it before a complete evaporation of moisture from its internal. - Page 6 In order to prevent damages to the unit do not use it if a condensate has appeared. If it is so extract power batteries from unit and wait for a while till a condensate evaporates. It is possible to use the device after a complete vaporization of a condensate only.
-
Page 7: Physical Configuration
Physical configuration The unit is designed as a portable and handheld device with a self-contained power supply. 1 LCD 2 « . MENU » button and its function icon (on display). The button responds to five functions: «MENU» – responds in «Monitoring» and «Background» modes; «SELECT»... - Page 8 « » button and its function icon. The button has six functions: - switches on the device; - «RETURN» – sends you one level back in «Menu» mode; - «EXIT» - transfers you from «Menu» to «Monitoring» or «Background» modes; - «...
-
Page 9: Display Format In Monitoring And Background Modes
Display format in «Monitoring» and «Background» modes After activating the unit displays a screen of RD1706 with button icons and individual or manufacture settings. Location of 14 fields and possible icons are shown on two display pictures below. 1.Icon of battery charge: «... - Page 10 .Icon of « » button (page ). This field contains one of CURSOR the following icons: « » - switching on backlight in «Monitoring» and «Background» modes; « » - moving cursor and altering value of a threshold in «Menu» mode.
- Page 11 After a short cycle of observation the screen with read outs appears. 1 1 .Digital readings of a dose rate in μSv/h; 2 1 .Icon of the number observations performed: « » - corresponds to the short (half of the complete) cycle of observation - corresponds to one complete cycle of observation;...
-
Page 12: Operating Mode
Operating mode There are three operating modes in the unit: «Monitoring», «Background» and «Menu». The «Monitoring» mode is set automatically at start of unit's functioning. This mode gives estimation of a dose rate and indications output to the LCD. The time of a dose rate estimation varies from 24 sec when a dose rate is less than 3,5 μSv/h till 1 sec when a dose rate exceeds 72,0 μSv/h. -
Page 13: Monitoring Mode
Monitoring mode This mode gives the value of a dose rate displaying indications on the LCD. Every registered quantum is displayed on LCD as « » icon. Blinking frequency of « » icon is proportional to the strength of a radiation dose rate. -
Page 14: Menu Mode
Menu mode In «Menu» mode you can arrange the magnitude of a threshold signal, turn on/off alarm and vibra-call, enable «Background» mode, estimate the background radiation and also receive reference information. Switching to «Menu» mode ceases monitoring of a dose rate. In order to switch from «Monitoring»... -
Page 15: Levels
«LEVELS» section Exceeding of a threshold dose rate value which can be set in «LEVELS» section provokes to alarm signal actuation. A threshold signal should be switched on when it is necessary to receive alarm or vibra signals in case of a fixed radiation dose rate exceeding. - Page 16 To change the level of a threshold switch from «Monitoring» to «Menu» mode (screen 1) The main menu displays on the screen (screen 2...
- Page 17 Press « » button and the screen 3 will appear. SELECT A double-click on « » button (screens 4 and 5) moves the cursor « » to « 0,30 μSv/h ». Press « » button and the icon « » will be placed opposite to CHANGE «...
-
Page 18: Background
«BACKGROUND» section «Background» mode can be turned on in this section. It calculates an average value of a background dose rate. To activate «Background» mode switch from «Monitoring» mode to «Menu» mode (screen 1).Amain menu displays (screen 2). Press « »... - Page 20 Press « » button and wait till completion of the cycle of START «BACKGROUND» estimation (screen 13).Avalue in the second line is the evaluation of a dose rate in the second sighting point (screen 14). In order to receive accurate estimation of a background it is necessary to conduct similar observations in 5 sighting points (screen 15).
-
Page 22: Setup
«SETUP» section Two types of signal can be chosen in «SETUP» section: «AUDIO» and «VIBRA-CALL» which can be turned on/off by placing « » icon opposite to a correspondent choice. Example of activating a vibra signal instead of an audio one is demonstrated below. - Page 23 From this moment a vibra signal turns on if the value of a dose rate exceeds the installed threshold of alert when a threshold function is not turned off (page 1 ). A vibra signal starts functioning in a pulse-mode till the end of an observation cycle.
-
Page 24: Service
In «SERVICE» section the following is mentioned: phone number of an organization where a radiation monitor RADEX RD1706 can be acquired, phone number of the QUARTA-RAD Ltd. Company, which sells wholesale a radiation monitor RADEX RD1706; internet address where you can find news www.quarta-rad.ru,... -
Page 25: «Background» Mode
«Background» mode This mode is convenient for examining inside the buildings. In «Background» mode the estimation of the radiation dose rate is similar to the one in «Monitoring» mode (page 1 ), yet the display gives not just one but two indications. One stands for exceeding of a dose rate over background dose rate, the second is for a background dose rate. -
Page 26: Preparations For Using
Preparations for using Before actuating the device read the operation manual and functions of operating controls carefully (page ). Installation of power elements 1.Take off the cover of battery compartment 2.Install into the battery compartment one or two power elements size "... -
Page 27: Device Using
Device using Switching on the device To switch on the device press button (page ) and the screen «OFF» RD1706 will be displayed. « » The sequence of survey After switching on the device the examination of the radioactive environment starts. During the time of observations every registered quantum of radiation is accompanied by a displayed presentation «... - Page 28 Icons « »- corresponds to one complete cycle of observation; « »- corresponds to complete cycle of observation; « »- corresponds to three complete cycle of observation; « »- corresponds to four and more complete cycles of observation. The first results of observation is displayed as an average value of two short cycles, the second - as average value of the two complete cycles of observation, the third - as average value of three complete cycles of observation and each following result - as average value of four previous...
-
Page 29: Radiation Control In Quarters And Public Buildings
Radiation control in quarters and public buildings. According to modern ideas about danger of small doses of radiation, the defensive measures of ngabited buildings should be conducted if a dose rate of gamma radiation inside a building exceeds a dose rate outside for more than 0,20μSv/h The estimation of a dose rate outside (background) is carried out near to... -
Page 30: Marking And Sealing
Marking and Sealing On the frame of the device are marked: - trade mark of the manufacturer; - trade mark - RADEX. Conventional designation of the monitor - RD1706 appears on display at its turning on. The assembly number of the device is on the main menu screen. The device is not sealed up by the manufacturer. -
Page 31: Technical Service
Do not let smaller articles penetrate the device through a perforation. Maintenance and updating All repairs of the unit are made at the manufacturer'spremises QUARTA-RAD Ltd. Company.Address: Quarta-Rad Ltd., 2 Building, 3 Podol'skikh Kursantov, Moscow, 117545, Russia phone/fax +7 (495) 316- 9633, phone +7 (495) 723- 4064, e-mail: quarta@quarta-rad.ru... -
Page 32: Performance Data
SANITARY - EPIDEMIOLOGICAL OFFICE FOR CONDUCTING A DETAILED RADIATIVE EXAMINATION. Performance data The radioactivity monitor RADEX RD1706, evaluates radiation environment by the magnitude of the ambient equivalent of dose rate Н*(10) of gamma radiation with taking into account gamma radiation and the pollution of objects by sources of beta particles. -
Page 33: Technical Specifications
Technical specifications Range of dose rate indications, μSv/h ……………. 0 05 to 999 Range of registered energy: 1) gamma radiation, MeV …… ....0,1 to 1,25 2) X-ray radiation, MeV ………… ...…….. 0,03 to 3,0 3) beta radiation, MeV … ….……..from 0,25 to 3,5 Reproducibility of indications (at confidential probability 0.95) …………..….…. - Page 34 Memo ............................................................................................................................
