- Page 1 ADIANCE HASSIS TACKING 10/100 BASE Installation & User Guide Model: R104-11...
- Page 2 Radiance Chassis Stacking Line Card R104-11 ____ 10/100Mbps Four-Port TX Switch This publication is protected by the copyright laws of the United States and other countries, with all rights reserved. No part of this publication may be reproduced, stored in a retrieval system, translated,...
-
Page 3: Table Of Contents
Metrobility Optical Systems, the Metrobility Optical Systems logo, NetBeacon and WebBeacon are trademarks of Metrobility Optical Systems, Inc. All others are trademarks of their respective owners. The information contained in this document is assumed to be correct and current. The manufacturer is not responsible for errors or omissions and reserves the right to change specifications at any time without notice. -
Page 4: Overview
This means the network administrator has one less piece of networking hard- ware to manage and monitor. The Radiance chassis stacking line card is designed to support a stack of up to four Metrobility chassis, thus enabling communication between the management card in each chassis. -
Page 5: Installation Guide
Installation Guide Follow the simple steps outlined in this section to install and start using the Radiance chassis stacking line card. NOTE: Electrostatic discharge precautions should be taken when handling any circuit board. Proper grounding is recommended (i.e., wear a wrist strap). - Page 6 When setting DIP switches on SW2, the OPEN position is when the lever of the switch is pushed up toward the word “OPEN.” The CLOSED position is when the lever is pushed down toward the board. On the rocker DIP switch (SW1), the OPEN position is when the “OPEN”...
- Page 7 (backpressure). When half-duplex flow control is activated, the Radiance card generates a jamming pattern to force a collision on a port if a buffer cannot be allocated for the port’s incoming packets. Half- duplex flow control is enabled by default (OPEN).
- Page 8 The table below displays sample port configurations and the DIP switch settings used to obtain them. The configuration column gives the auto- negotiation, speed and duplex options for each port. By default, all four ports are set to auto-negotiate. l l u —...
-
Page 9: Step 3: Install The Card
Install the Card The Radiance chassis stacking line card offers the ease of plug-and- play installation and is hot-swappable. The unit must be firmly secured to the chassis before network connections are made. Follow the simple steps outlined below to install the card. -
Page 10: Step 4: Connect To The Network
Connect to the Network To connect the Radiance chassis stacking line card to the network, insert the twisted-pair cables into the appropriate connectors. Be sure the card is secured to the chassis by tightening the thumbscrew before making network connections. -
Page 11: User Guide
Radiance chassis stacking line card. LED Indicators The Radiance chassis stacking line card provides several LEDs for the visible verification of unit status and proper functionality. These LEDs can assist in troubleshooting and with overall network diagnosis and management. There are separate link/speed and activity/duplex indicators for each port. -
Page 12: Topology Solutions
Topology Solutions Enterprise Switch F/O Links Twisted-pair Links Radiance R5000 Central Service Platform with R502-M Management Card, Radiance Chassis Stacking Line Card and Other Radiance Line Cards PC running Network Management Software 20km, 40km, or 100km sm fiber Managed Hub... -
Page 13: Chassis Stacking Example
Card Card Using a Radiance chassis stacking line card, up to four Metrobility chassis can be controlled as a single network device with one IP address. Stacking requires an R502-M management card in the master chassis. One of the ports on the chassis stacking line card must be connected to Port 2 of the R502-M. -
Page 14: Technical Specifications
Technical Specifications Network Connections Twisted-Pair Interface Connector __________________________________ Shielded RJ-45, 8-pin jack Impedance ________________________________________ 100 Ohms nominal Signal Level Output (differential) ________________ 0.95 to 1.05V (100Mbps) ___________________ 2.2 to 2.8V (10Mbps) Signal Level Input ________________________ 200mV minimum (100Mbps) __________________________________ 585mV (10Mbps) Supported Link Length _________________________________________ 100m Cable Type (10Mbps segments) ______________ Category 3, 4 or 5 UTP/STP (100Mbps segments) ______________ Category 5 or 5E UTP/STP... -
Page 15: Product Safety, Emc And Compliance Statements
Canadian Radio Frequency Interference Statement This Class A digital apparatus meets all requirements of the Canadian Interfer- ence-Causing Equipment Regulations. Cet appareil numérique de la classe A respecte toutes les exigences du Réglement sur le matériel brouilleur du Canada. Radiance Chassis Stacking Line Card... -
Page 16: Warranty And Servicing
Warranty and Servicing Three-Year Warranty for Radiance Chassis Stacking Line Card Metrobility Optical Systems, Inc. warrants that every Radiance stacking line card will be free from defects in material and workmanship for a period of THREE YEARS from the date of Metrobility shipment. This warranty covers the original user only and is not transferable. - Page 17 Radiance Chassis Stacking Line Card...
- Page 18 Product Manuals The most recent version of this manual is available online at http://www.metrobility.com/support/manuals.htm To obtain additional copies of this manual, contact your reseller, or call 1.877.526.2278 or 1.603.880.1833 Product Registration To register your product, go to http://www.metrobility.com/support/registration.asp 25 Manchester Street, Merrimack, NH 03054 USA tel: 1.603.880.1833 •...
