(73-1) AP619RL REMOTE CONTROL BUILT-IN ELECTRIC PUMP ENGLISH 4.875" X 7.25"
4.
Press "I" to switch ON. See Fig (4).
5.
When the airbed is fully inflated to the desired firmness, press "O" to switch OFF. See
Fig (5).
FIG (4)
6. Pat on the bed surface to adjust the foam.
NOTE: Leave the vacuum valve open to allow
the foam to re-shape itself, this may take up to
five minutes before initial use.
7. Close the foam vacuum valve. See Fig (6).
8. Lie down on the airbed to test the firmness.
9. If the sleeping surface is too hard, adjust the firmness by pressing and holding the
adjusting switch. Air will exit through the air passage. See Fig (7). Release the adjusting
switch when the desired firmness is achieved. If the airbed becomes too soft repeat
steps #4, #5, #8 and #9 as necessary.
IMPORTANT: Do not hold the adjusting switch for more than 30 continuous seconds, as
overheating will occur. Wait 10 minutes before using again to allow cooling.
10. Disconnect the AC line cord from the wall socket; place the line cord and the remote
control in the storage pocket. See Fig (8).
FIG (7)
IMPORTANT NOTE
Proper inflation of the airbed.
The ambient temperatures of air have an effect on the airbed internal pressure. At low
ambient temperature the air will contract within the airbed and the airbed will feel softer:
add air as necessary. At high ambient temperature the air within the airbed will expand
significantly and the airbed will become hard and may burst: release air to avoid damage
to the airbed or to soften the feel. Do not expose the airbed to extreme temperatures (hot
or cold).
Air inside of bed may expand and contract with varying temperature leading to reduce
pressure inside of the bed. If this occurs, simply add more air using the pump to achieve
desired firmness. If puncture occurs, please refer to instruction. Repair kit/patch is
enclosed.
Stretching is a natural characteristic of new vinyl. During initial use, the airbed may
become soft and require additional inflation to maintain desired firmness. This is normal for
the first few days of use.
Dimensions shown are approximate and will vary due to the vinyl temperature and the air
temperature.
In no event shall Intex, their authorized agents or employees be liable for damages
(such as pin holes) to the airbed caused by negligence, ordinary wear and tear,
abuse and carelessness, or external forces.
READ AND SAVE THESE INSTRUCTIONS
Page 3
07/14/2011
73-1
FIG (5)
FIG (6)
FIG (8)
(73-1) AP619RL REMOTE CONTROL BUILT-IN ELECTRIC PUMP ENGLISH 4.875" X 7.25"
DEFLATION
1. Unscrew the exhaust valve cap from the "2 in 1" valve.
See Fig (9).
2. Open the foam vacuum valve on the corner of
the sleeping surface of bed. See Fig (3).
3. Begin rolling the airbed from the foot of the airbed
towards the head of the airbed where the pump is
located, let the airbed stand with the valve open for a
while to let any remaining air to flow out of the valve.
See Fig (10). Make sure to screw the exhaust valve
cap back into the "2 in 1" valve. See Fig (1).
4. Place the line cord and the remote control in the
storage pocket.
INFLATION OPTION
1. If electrical power is not available then a conventional
foot or manually operated air pump can be connected
to the optional "2 in 1" valve for inflation.
2. Pull the valve cap out from the "2 in 1" valve and insert the
air hose of a conventional foot or manually operated air
pump. See Fig (11).
3. Start inflating with foot or hand pump, inflate to desired
firmness.
IMPORTANT
Inflate only with a low pressure inflator. Do not over inflate. Fill with cold air only.
STORAGE
1. Deflate the airbed following the "DEFLATION" instructions.
2. Make sure the airbed is clean and dry.
3. Lay bed flat with sleeping surface facing upwards and follow the folding steps on Figs (12 - 16).
Fold the airbed loosely and avoid sharp bends, corners and creases which can damage the airbed.
FIG (12)
INTEX
®
©2005 ®TM Intex Recreation Corp., Long Beach,
CA 90801-1440 USA
®™ Trademarks used in some countries
of the world by Intex Trading Ltd., under license
/ Hecho en China
Made in China/ Fabriqué en Chine
from Intex Marketing Ltd.
Electric Air Pump
Fast-Fill™
FIG (15)
4. Place the airbed inside the storage bag and store in a dry, cool storage location.
©2011 Intex Marketing Ltd. - Intex Development Co. Ltd. - Intex Trading Ltd. - Intex Recreation Corp.
All rights reserved/Tous droits réservés/Todos los derechos reservados/Alle Rechte vorbehalten.
Printed in China/Imprimé en Chine/Impreso en China/Gedruckt in China.
®™ Trademarks used in some countries of the world under license from/®™ Marques utilisées dans certains pays sous licence de/Marcas registradas
utilizadas en algunos países del mundo bajo licencia de/Warenzeichen verwendet in einigen Ländern der Welt in Lizenz von/Intex Marketing Ltd. to/à/a/an
Intex Trading Ltd., Intex Development Co. Ltd., G.P.O Box 28829, Hong Kong & Intex Recreation Corp., P.O. Box 1440, Long Beach, CA 90801
• Distributed in the European Union by/Distribué dans l'Union Européenne par/Distribuido en la unión Europea por/Vertrieb in der Europäischen Union
durch/Intex Trading B.V., P.O. Box nr. 1075 – 4700 BB Roosendaal – The Netherlands
READ AND SAVE THESE INSTRUCTIONS
Page 4
07/14/2011
73-1
FIG (9)
FIG (10)
FIG (11)
FIG (13)
FIG (14)
INTEX
®
©2005 ®TM Intex Recreation Corp Long Beach,
CA 90801-1440 USA
®™ Trademarks used in some countries of
the world by Intex Trading Ltd., under license
/ Hecho en China
Made in China/ Fabriqué en Chine
from Intex Marketing Ltd.
Electric Air Pump
Fast-Fill™
FIG (16)
Consumer Service 1-800-234-6839
