Summary of Contents for Martin EVO

  • Page 1 ® Return Roller Go to EVO Return Roller web page ® Operator’s Manual M3796...
  • Page 2 Important MARTIN ENGINEERING HEREBY DISCLAIMS ANY LIABILITY FOR: DAMAGE DUE TO CONTAMINATION OF THE MATERIAL; USER’S FAILURE TO INSPECT, MAINTAIN AND TAKE REASONABLE CARE OF THE EQUIPMENT; INJURIES OR DAMAGE RESULTING FROM USE OR APPLICATION OF THIS PRODUCT CONTRARY TO INSTRUCTIONS AND SPECIFICATIONS CONTAINED HEREIN.

  • Page 3: Table Of Contents

    ® Installing EVO Return Roller ........... 4 After Installing Return Roller .
  • Page 4 ® Part Numbers for EVO Return Roller ....... . . 12 ®...

  • Page 5: Introduction

    Introduction General ® The EVO Return Roller is a pivoting track-mounted return idler that allows for safe, quick, and simple one-sided servicability and roll replacement. The track-mounted design reduces the risk of injury and allows replacement of the roll in a matter of seconds.
  • Page 6 WARNING Remove all tools from the installation area and conveyor belt before turning on the conveyor. Failure to do so can cause serious injury to personnel or damage to the belt and conveyor. ® Martin Engineering M3796-05/12 Return Roller...

  • Page 7: Before Installing Return Roller

    ® 2. Remove EVO Return Roller assembly from shipping container. 3. If anything is missing contact Martin Engineering or a representative. WARNING Before installing equipment, turn off and lock out/ tag out all energy sources to the conveyor and conveyor accessories according to ANSI standards.

  • Page 8: Installing Return Roller

    Installing Return Roller ® Installing EVO Return Roller 90° 1. Remove existing return idler and mounting brackets. 2. Mark holes for hanger tubes opposite of each other and perpendicular to belt. 3. Drill or torch holes into stringer. A. Cap Screw, Washers, and Nut (2 used) B.
  • Page 9 10. Slide roll assembly (H) on rotating weldment (G). Make sure handle (J) is located on operator side of conveyor. 11. Insert snap lock pin (E) into rotating weldment to secure roll assembly. 12. Rotate roll assembly into position and lower handle (J). ® Martin Engineering M3796-05/12 Return Roller...
  • Page 10 13. Loosen nuts (K) and adjust cap screws (L) to hold roll assembly perpendicular to belt. 14. Tighten nuts (K). 15. Raise entire assembly up into belt 1 inch and tighten all cap screws and nuts. ® Martin Engineering M3796-05/12 Return Roller...

  • Page 11: After Installing Return Roller

    ANSI standards. Failure to do so could result in serious injury or death. 4. Make sure all fasteners are tight. Tighten if necessary. ® Martin Engineering M3796-05/12 Return Roller...

  • Page 12: Weekly Maintenance

    2. Make sure all fasteners are tight. Tighten if necessary. 3. Lubricate pivot bearings as necessary. 4. Wipe all labels clean. If labels are not readable, contact Martin Engineering or a representative for replacements. 5. Remove equipment from service if there is any indication it is not functioning properly.

  • Page 13: Part Numbers

    Part Numbers ® This section provides part numbers for the EVO Return Roller Assemblies. Please reference part numbers when ordering parts. ® ® Return Return Roll Assembly: 24 to 72 in. (600 to 1800-mm) belts: Roller Assembly P/N UCRR-007000-XXX. ®...
  • Page 14 Return Roller, P/N UCRR-007000-XXX* (Sheet 1 of 2) ® *First XX indicates belt width in inches; Next X indicates stringer type: E = EVO Stringer, S = Standard Stringer; Add an F to end of part number for frame only (no roller included).
  • Page 15 23 (NS) Label Kit UCRR-007070 24 (NS) Hardware Kit Table I 25 (NS) Operator’s Manual M3796 **XX indicates belt width in inches. ® Figure 1. EVO Return Roller, P/N UCRR-007000-XXX (Sheet 2 of 2) ® Martin Engineering M3796-05/12 Return Roller...
  • Page 16 ® Table I. Part Numbers for EVO Return Roller Part Number Item 2 UCRR-007000-24X 34743-03 UCRR-007000-36X 34743-01 UCRR-007000-42X 34743-01 UCRR-007000-48X 34743-01 UCRR-007000-54X 34743-01 UCRR-007000-60X 34743-02 UCRR-007000-72X 34743-02 Part Number Item 11 Item 25 UCRR-007000-XXE UCRR-007060-E UCRR-007050-E UCRR-007000-XXS UCRR-007060-S UCRR-007050-S ®...

  • Page 17: Conveyor Products Warning Label, P/N 23395

    Label P/N 23395 Figure 2. Conveyor Products Warning Label, P/N 23395 ADVERTENCIA WARNING Pinch point! ¡ Usted se puede pellizcar! Label P/N 30528 Figure 3. Pinch Point Warning Label, P/N 30528 ® Martin Engineering M3796-05/12 Return Roller...

  • Page 18: Evo ® Return Roller Dimensions

    Dim. A (132) ® Stinger 29.50 (749) Ø6.00 (152) 3.00 (76) Dim. B ® Figure 4. EVO Return Roller Dimensions Dim. A Dim. B Part Number in. (mm) in. (mm) UCRR-007000-24X 36 (914) 29 (737) UCRR-007000-36X 48 (1219) 37 (940)
  • Page 19 Any product, process, or technology described here may be the subject of intellectual property rights reserved by Martin Engineering Company. Trademarks or service marks designated with the ® symbol are registered with the U.S. Patent and Trademark Office and may be proprietary in one or more countries or regions. Other trademarks and service marks belonging to Martin Engineering Company in the United States and/or other countries or regions may be designated with the “TM”...
  • Page 20 Martin Engineering USA One Martin Place Neponset, IL 61345-9766 USA 800 544 2947 or 309 852 2384 Fax 800 814 1553 www.martin-eng.com Form No. M3796-05/12 © Martin Engineering Company 2011, 2012...
