O W N E R ' S
M A N U A L
Wheelchair Accessible Swing
#601
SERIES MODEL & ACCESSORIES
Contents
Site Selection Requirements ..................................... Page 5
Tools Required for Installation .................................. Page 5
Fastener Kit Identification ......................................... Page 6
Assembly Instructions ............................................ Page 7-14
Safety Instructions ..................................................... Page 15
Maintenance ....................................................... Page 16-17
Warranty ................................................................... Page 18
America's Finest Therapeutic Swings!
Advertisement
Table of Contents
Related Manuals for WhisperGLIDE Wheelchair Accessible Swing
Summary of Contents for WhisperGLIDE Wheelchair Accessible Swing
-
Page 1: Table Of Contents
O W N E R ’ S M A N U A L Wheelchair Accessible Swing #601 SERIES MODEL & ACCESSORIES Contents Introduction & Important Information ......Page 2 Swing Specifications & Parts Identification ....Page 3 Canopies, Cushions & Lap Bar ........Page 4 Site Selection Requirements ........ -
Page 2: Introduction & Important Information
For Additional Information P.O. Box 188, Mosinee, WI 54455 Check us out on our Website, or call us! email: swings@whisperglide.com 1-800-944-7737 1-715-457-0048 www.whisperglide.com FAX: • © April 2018, WhisperGLIDE Swing Co. Use Inside or Outside PA G E T W O... -
Page 3: Swing Specifications & Parts Identification
Gear Assembly Lock-Up Receptacle Safety Floor Handrail PRIMARY COMPONENTS The WhisperGLIDE Wheelchair Accessible Swing – Model 600 Materials Frame (legs, hangers, upper assembly); push-pull bar; safety handrail; seat castings Aluminum Support & pivot shafts; lock-up shafts; fasteners (nuts, bolts, screws) Stainless steel Platform;... -
Page 4: Canopies, Cushions & Lap Bar
Canopies & Cushions ® Pictured is a sample canopy and cushion from the WhisperGLIDE product line. WhisperGLIDE Primary Fabric Components Material Comment WhisperGLIDE Series 600 Fabric – Coffee Linen, Cypress Vinyl-coated polyester Flammability rating Woods, EarthBright, Fern Dance, Mocha Thyme, Sea Breeze,... -
Page 5: Site Selection Requirements
If your swing is placed adjacent to walkways, or access to all sides is not necessary, additional space requirements may be reduced. Wheelchair Accessible Swing: Ideal – 13-ft X 18-ft Two Bench Swing: Ideal –... -
Page 6: Fastener Kit Identification
Fastener Kit Identification The fastener kit contains labeled “subkits” for easy assembly of the swing. Also, you can use the actual size fastener codes, identified below, for cross-reference. 2-1/4" x 3/8" 1-1/2" x 3/8" 3-1/4" x 3/8" 5/8" x 3/16" 1"... -
Page 7: Assembly Instructions
Step One: Upper Frame Assembly The frame is contained in two identical boxes. One is labeled “OPEN ME FIRST”. Use hardware contained in the “Frame Assembly Kit” which is located in Box #2. 1. Place both sides of the upper frame upside down on the ground, deck, or patio where the swing will be located. - Page 8 Step Two: Leg Assembly The legs are contained in the longest box labeled Box #5. There are two left legs and two right legs. Use the hardware contained in the “Frame Assembly Kit” pack. 1. Note “Left” and “Right” labels on the legs and on the frame. Position a leg into the appropriate corner;...
- Page 9 Step Three: Swing Hanger Installation The swing hangers are contained in the second longest box and labeled Box #4. They connect the upper frame to the platform of the swing. There are two right hangers (these have lock-up shafts) and two left hangers (these do not have lock-up shafts).
- Page 10 Step Four: Wheelchair Platform Assembly The wheelchair platform assembly consists of the platform and the ramp and are contained in the boxes labeled Box #7, Box #8. Use hardware contained in 3 different sub-kit packets: Seat, Stabilizer Bars & Handrail Kit; Table Handrail Kit; Wheelchair Ramp Kit. The locknuts for the Table itself are already fastened to the imbedded bolts in the table.
- Page 11 Illustration for Step Four: Wheelchair Platform Assembly Wheelchair Platform with Ramp, Stop Bar, Gear Assembly and Stabilizer Bar Stabilizer Bar Stop Bar Gear Assembly Swing Floor Ramp PA G E E L E V E N...
- Page 12 Step Five: Seat Assembly with Stabilizer Bar The Seat Assembly parts are in Box #3. The seat backs & bottoms are the same. Use the hardware in “Seat, Stabilizer Bar & Safety Handrail kit”. 1. Attach each seat castings to the hangers using bolts (F) and nuts. The nuts should be on the inside of the swing.
- Page 13 Step Six: Wheelchair Therapeutic Handles The Wheelchair Therapeutic Handles (see page 2) are located in the small box labeled Wheelchair Therapeutic Handles. Note location of holes near the middle of the wheelchair-side hangers approximately half way up from the platform. The therapeutic handles are to be attached here. Install using the four 2-inch bolts and corresponding nuts in the fastener kit labeled “Therapeutic Handles”.
- Page 14 Step Eight: Anchor Swing / Lock-Up Receptacles Anchoring is one of the last steps of the installation process. The swing legs and lock-up receptacles must be secured to the surface. Use hardware contained in the “Anchoring Kit”. • Swing (leg) anchoring 1.
-
Page 15: Safety Instructions
® Safety Instructions for WhisperGLIDE Swings ® The Whisper GLIDE Swing is designed with user safety in mind. However, as with all mechanical equipment, there are potential hazards which could result in injury to persons, and/or structural damage to the equipment, if the swing is improperly used or improperly supervised. -
Page 16: Maintenance
® Maintenance of Your WhisperGLIDE Swing Maintenance & Cleaning General Check ALL fasteners at least once per year for tightness. Periodically check instruction labels that are on the swing. If any labels become detached, contact Whisper GLIDE Swing Company for replacements. - Page 17 ® Maintenance of Your WhisperGLIDE Swing Canopy & Cushion Care ® TEXTILENE LEISURETEX™ BASKETWEAVE, EARTHBRIGHT, COFFEE LINEN, CYPRESS WOODS, FABRIC NAMES: FABRIC NAMES: FERN DANCE, FOREST GREEN, SAHARA BEAUTY, MOCHA THYME, TERRA SIENNA SEA BREEZE, SIERRA MOUNTAIN, WINDSOR Common Dirt: Spot wash by sponging briskly with TRELLIS, WOODLAND GREEN a lukewarm solution of mild soap and water.
-
Page 18: Warranty
– Problems resulting from neglect by original purchaser – Unauthorized repairs made or attempted – Returns without prior authorization from the WhisperGLIDE customer service department – Damage due to situations including, but not limited to, falling objects, storm, earthquake, tornado, flood, ©...
