Pamex Kapture KA-WR1S User Manual & Implementation Manual

Kapture series a multi-family door access control solution
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Pamex
Kapture Series
A Multi-Family Door Access Control Solution
User Manual & Implementation Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Kapture KA-WR1S and is the answer not in the manual?

Questions and answers

Summary of Contents for Pamex Kapture KA-WR1S

  • Page 1 Pamex Kapture Series A Multi-Family Door Access Control Solution User Manual & Implementation Guide...

  • Page 2: Table Of Contents

    Table of Contents Introduction Before Installation Check List Pamex MFSP Service Platform Hardware Installation Wall Reader - Kapture KA-WR1S, Kapture KA-WR1N Features Hardware Specifications Front View Back View Wiring Pigtail Rated note Basic Door Installation Basic Door Installation Wiring Solid-State Output...
  • Page 3 Hardware Specifications Product Photo Installation Guide Interconnected - KA-INP35S Features Hardware Specifications Product Photo Installation Guide Implementation Guide Concepts Construction Phase Lock Registration Phase Plan your area tree Build the area tree using MF-Admin Server Plan your programming cards Setup Wifi AP and Create Programming Cards Register Locks to MF-Admin Server Verify lock registration using Master Card Go-live Phase...
  • Page 4 Application Parameters System Parameters Mifare Card Specification Card Types Area Types Lock Real Time Events Default Severity of Alert Types FCC Statement NCC Statement...

  • Page 5: Introduction

    Introduction Pamex Kapture series is a total solution for multi-family door access control. It not only has several models of lock but also the browser based central management system (MF-Admin server). Figure 1 : Pamex Kapture System Architecture Overview Figure 1 shows the system architecture of Pamex Kapture solution, Below are the brief description of each components : 1.
  • Page 6 8. MFSP platform : MFSP (Multi-Family Service Platform) is a cloud service for all the MF-Admin Servers around the world. This platform is operated by Pamex. Connected your MF-Admin Server to MFSP is not required but we encourage you to do so.

  • Page 7: Before Installation

    Pamex MFSP Service Platform ● This section is for Pamex only. ● Before any Kapture installation, Pamex admin will have to create a project in MFSP in order to get the unique project code. ● A Kapture installation will need at least one Crypto card to activate all the locks.

  • Page 8: Hardware Installation

    ● UL294(US), FCC Certification (US) ● Remote configurable using MF-Admin server Hardware Specifications Mechanical (Dimensions) Kapture KA-WR1S : 5.51” (H) X 2.95” (W) X 1.27” (D) Kapture KA-WR1N : 7.45” (H) X 1.77” (W) X 1.28” (D) Electrical ● NFC reader ●...
  • Page 9 ● Input Voltage: 12/24 Volts DC, 25VDC Absolute Max. rating Operating Current: 30 mA typical, 150 mA max Output Ratings ● Main Relay: Form “C” 2 Amps @ 28 Volts max ● Auxiliary Relay: Form “C” 2 Amp @ 28 Volts max ●...

  • Page 10: Front View

    Front View Figure 3 : Kapture KA-WR1S Front, Kapture KA-WR1N Front...

  • Page 11: Back View

    Back View Figure 4: Kapture KA-WR1S Back, Kapture KA-WR1N Back...

  • Page 12: Wiring Pigtail Rated Note

    Wiring Pigtail Rated note Figure 5: Kapture KA-WR1S, Kapture KA-WR1N Wiring Pigtail Rated note...

  • Page 13: Basic Door Installation

    Basic Door Installation Figure 6: Kapture KA-WR1S(N) Basic Door Installation...

  • Page 14: Basic Door Installation Wiring

    Basic Door Installation Wiring Figure 7:Kapture KA-WR1S(N) Basic Door Installation Wiring...

  • Page 15: Solid-State Output

    Solid-State Output Figure 8 : Kapture KA-WR1S(N) Solid State Output...

  • Page 16: Surface Mounting

    Surface Mounting Figure 9 : Kapture KA-WR1S(N) Surface Mounting...

  • Page 17: Mounting To Single Gang Recessed Outlet Box

    Mounting to single gang recessed outlet box Figure 10 : Kapture KA-WR1S(N) MOUNTING TO SINGLE GANG RECESSED OUTLET...

  • Page 18: Dimensions

    Dimensions Figure 11 : Kapture KA-WR1S Front Figure 12: Kapture KA-WR1N Front...
  • Page 19 Back Figure 13: Kapture KA-WR1S Back...
  • Page 20 Figure 14: Kapture KA-WR1N Back...

  • Page 21: Installation Guide

    Installation Guide Kapture KA-WR1N 1) Screw the back plate to lock base with three 4mm*12mm self-tapping screws. See picture below. 2) Place the waterproof rubber on the back of the Wall Reader. See picture 1&2.
  • Page 22 3) Before fastened Wall Reader, please ensure the waterproof rubber is installed. Align the hole with the hook on the top of back plate. See picture 3, Push down the Wall Reader. See picture 4. Tighten up the Wall Reader with a 4mm*8mm screw. See picture 5.
  • Page 23 Kapture KA-WR1S 1) Screw the back plate to switch box with two 4mm*12mm self-tapping screws. See picture 1&2. 2) Place the waterproof rubber on the back of the Wall Reader. See picture 3&4. 3) Before fastened Wall Reader, please ensure the waterproof rubber is installed.
  • Page 24 Pull down the Wall Reader. See picture 6. Tiighten up the Wall Reader with one 4mm*8mm screw. See picture 7.

  • Page 25: Deadbolt - Ka-D7P1A (Auto)

    Deadbolt - KA-D7P1A (Auto) Features ● Easy installation with a Philips screwdriver ● Hidden(tamperproof) emergency mechanical key override & Tamperproof Detector ● Battery operated with over 1 year battery life ● Low battery warning ● ANSI/BHMA Grade 2 Certified ● IP55 Weatherproof suitable for external use ●...
  • Page 26 ● Dimension (W*H*D) : ○ Exterior lock body: 70 x 160 x 28 mm ○ Interior lock body: 75 x 204 x 30 mm ● Square Corner Faceplate : 1-1/8” x 2-3/4” ● Cylinder : 5-pin KW keyway standard, other options available ●...

  • Page 27: Product Photo

    Product Photo << Mark >>...

  • Page 28: Dimensions (內外機)

    Dimensions (內外機) <<Mark>>...

  • Page 29: Installation Guide

    Installation Guide...

  • Page 30: Deadbolt - Ka-D7P1S (Semi-Auto)

    Deadbolt - KA-D7P1S (Semi-Auto) Features ● Easy installation with a Philips screwdriver ● Hidden(tamperproof) emergency mechanical key override & Tamperproof Detector ● Battery operated with over 1 year battery life ● Low battery warning ● Door handles reversible by a ring-shaped switch ●...
  • Page 31 Mechanical Specification ● 3-Hour UL Fire-Rated, Grade 2 ANSI/BHMA certified ● Dimension (W*H*D) : ○ Exterior lock body: 70 x 160 x 28 mm ○ Interior lock body: 75 x 204 x 30 mm ● Square Corner Faceplate : 1-1/8”x 2-1/4” ●...

  • Page 32: Product Photo

    Product Photo << Mark >>...

  • Page 33: Dimensions (內外機)

    Dimensions (內外機) <<Mark>>...

  • Page 34: Installation Guide

    Installation Guide <<D1 Installation Guide>>...

  • Page 35: Leverset - Ka-Lnp5C

    Leverset - KA-LNP5C Features ● Easy installation with a Philips screwdriver ● Lever handing is field reversible in seconds; no tools required ● Hidden(tamperproof) emergency mechanical key override & Tamperproof Detector ● Battery operated(with over 1 year battery life) or Mains supply with 6V 2A power adapter selected by a DIP switch ●...
  • Page 36 ● Communication range – up to 100 ft. ● Data rate – 24M bps via Wi-Fi Mechanical Specification ● 3-Hour UL Fire-Rated, Grade 2 ANSI/BHMA certified ● Dimension (W*H*D) : ○ Exterior lock body: 70 x 160 x 28 mm ○...

  • Page 37: Product Photo

    Product Photo << Mark >>...

  • Page 38: Dimensions (內外機)

    Dimensions (內外機) <<Mark>>...

  • Page 39: Installation Guide

    Installation Guide...

  • Page 40: Interconnected - Ka-Inp35A

    Interconnected - KA-INP35A Features ● Easy installation with a Philips screwdriver ● Hidden(tamperproof) emergency mechanical key override & Tamperproof Detector ● Battery operated with over 1 year battery life ● Low battery warning ● ANSI/BHMA Grade 2 Certified ● IP55 Weatherproof suitable for external use ●...
  • Page 41 ● Dimension (W*H*D) : ○ Exterior lock body: 70 x 160 x 28 mm ○ Interior lock body: 75 x 204 x 30 mm ● Square Corner Faceplate : 1-1/8” x 2-3/4” ● Cylinder : 5-pin KW keyway standard, other options available ●...

  • Page 42: Product Photo

    Product Photo << Mark >>...

  • Page 43: Installation Guide

    Installation Guide...

  • Page 44: Interconnected - Ka-Inp35S

    Interconnected - KA-INP35S Features ● Easy installation with a Philips screwdriver ● Hidden(tamperproof) emergency mechanical key override & Tamperproof Detector ● Battery operated with over 1 year battery life ● Low battery warning ● Door handles reversible by a ring-shaped switch ●...
  • Page 45 Mechanical Specification ● 3-Hour UL Fire-Rated, Grade 2 ANSI/BHMA certified ● Dimension (W*H*D) : ○ Exterior lock body: 70 x 160 x 28 mm ○ Interior lock body: 75 x 204 x 30 mm ● Square Corner Faceplate : 1-1/8”x 2-1/4” ●...

  • Page 46: Product Photo

    Product Photo << Mark >>...

  • Page 47: Installation Guide

    Installation Guide...

  • Page 48: Implementation Guide

    In this guide, we will use the term Card or Key from time to time. Both term refers to the Mifare Card or Mifare key fob in issued by Pamex Kapture solution. MP100 is the only device you use to issue card/key. Note that sometimes you have to re-place (take card off the reader then place the card on the reader again) the card on the reader to successfully complete your card operation.

  • Page 49: Construction Phase

    Construction Phase Make sure you have Crypto Cards and Construction Cards on hand. Crypto Card and Construction Card are shipped from Pamex together with physical locks.(See Appendix : Card Types) In the scenario that wifi network and MF-Admin Server is not ready, and you have installed locks on the doors, you will need Construction Cards to unlock and open the door.

  • Page 50: Lock Registration Phase

    Lock Registration Phase MF-Admin Server is required to complete all the tasks in this phase. Please follow the MF-Admin Server & MP100 Installation Guide to install MF-Admin Server. MF-Admin Server is a web-based application with access controlled by login id and password.

  • Page 51: Plan Your Area Tree

    Plan your area tree Area tree is the topology of your property. Before you can register your physical locks and link the locks to their corresponding lock place, you have to build the area tree in MF-Admin Server. There are three types of areas : group, unit, public (See Appendix: Area Types for detail).

  • Page 52: Build The Area Tree Using Mf-Admin Server

    Build the area tree using MF-Admin Server Navigate to build area tree page. Property Management => Build Property For a brand new property, you will see only one node at beginning. Click and edit root area name. Click edit button on Root Area and select Add Public Area. Click the name text to edit public area name and lockplace name.
  • Page 53 Click menu button on Root Area and select Add Group. Click name text to edit group name. Click menu button on Group Area M and select “Add Lock Place”. Edit lockplace name. Click menu button on Group Area M and select “Add Unit”.
  • Page 54 Click name text to edit unit name and lockplace name. Keep adding unit from B to D Click Save To Server to save the area tree. Note that there are many ways to build an area tree as above. You may find other techniques in MF-Admin Server User Manual.

  • Page 55: Plan Your Programming Cards

    Plan your programming cards The area tree is now ready to be linked to physical locks. Pamex Kapture locks support WPA2 encryption to connect to the Wifi AP. When a lock is scanned by a programming card, the preferred Wifi AP SSIDs will be loaded into the lock from programming card.
  • Page 56 For SIMPLE project, AP1 and AP2 can be saved into one programming card. Programming card can be created using MF-Admin Server and you may create several cards with the same settings in order to programm locks in parallel by several workers.

  • Page 57: Setup Wifi Ap And Create Programming Cards

    Setup Wifi AP and Create Programming Cards Navigate to system parameters page. System Management => System Parameters Select Wifi AP Setting Click Add One to add wifi ap and click Save to save wifi ap. Navigate to create programming cards page. Property Management => Issue Programming Key...
  • Page 58 You will see there are two wifi aps you added previously. Check the checkbox on those wifi ap and click Issue Key . Place key/card on reader first.
  • Page 59 Click Read Key From Reader to get Key’s UID. The green light LED on Read should blink. If Read Key From Reader failed with three beep sounds and display following message, please re-place key/card and click Read Key From Reader again.

  • Page 60: Register Locks To Mf-Admin Server

    If read key successfully click Write Key/Card to issue programming key. Write Key/Card successfully with two beep sounds. Register Locks to MF-Admin Server Please bring a tablet or mobile phone with Chrome browser. Follow below steps to register a lock : A.
  • Page 61 D. Go to Room A E. Scan programming card to the lock Lockplace A. You will see the physical new lock connect to MF-Admin server. F. Link physical lock on Room A to lockplace. Click lock icon near Unit Area A. A pop-up window will show up listing all the locks not linked yet.

  • Page 62: Verify Lock Registration Using Master Card

    Verify lock registration using Master Card Master Card is granted unlimited access to any locks in the project. After locks are registered to MF-Admin server, they now only recognize Residential Cards plus Master Cards. To verify that all the locks are successfully registered and linked to the right lock places in the area tree, let’s first create the master card.
  • Page 63 Place key/card on reader first. Click Read Key From Reader to get Key’s UID.
  • Page 64 The green light LED on Read should blink. If Read Key From Reader failed with three beep sounds and display following message, please re-place key/card and click Read Key From Reader again. If read key successfully click Write Key/Card to issue master key.
  • Page 65 Write Key/Card successfully with two beep sounds. ● How to verify Master Card to a lock : Prepare a invalid Mifare Card X (You may issue an invalid card easily by assigning no area to the card). By default, a lock will report to MF-Admin Server and get the newly create card list from MF-Admin Server every 30 mins.
  • Page 66 ○ If lock A is still not opened, please unlink the lock and register/link again. Then repeat the verification steps. ○ If problem still exist, please contact your reseller for help. Please keep the Master Card safe and secure. Congratulations ! The system is ready and let’s go to Go-Live phase.

  • Page 67: Go-Live Phase

    Go-live Phase We will present several daily operations when the system goes live. Most of the daily work of an administrator or property owner should be card/key management. You have seen several card types in the previous sections: Crypto Card, Construction Card, Programming Card and Master Card.
  • Page 68 In Time Control Templates click Create button. Edit the template name, According to the document, the Guest Swimming Pool Period only open on 8:00 ~ 18:00 Sat, 8:00 ~ 18:00 Sun . Let’s edit the time control to meet the requirement and click Save to save time control setting.
  • Page 69 ● User Management You may maintain tenants, staffs and vendors information in User Management module. The information you entered here is only for look up purpose when issuing card which we will demo later. The benefit to create entries here is to save you some typing when issue cards/keys.
  • Page 70 Edit tenant information and click Create Tenant . The table below the input area will list all the tenants created : Please repeat the work and create tenant B, C, and D. ❖ Steps to create staffs Navigate to create staffs page. User Management => Staff Edit staff information and click Create Staff .
  • Page 71 The table below the input area will list all the staffs created : Follow the same process to create staff Ricky Chang. ❖ Steps to create vendors Navigate to create vendors page. User Management => Vendor Edit vendor information and click Create Vendor .
  • Page 72 It will display vendor list below the input area. Click Employee button on Actions filed to add employee. Edit employee information and click Create New Employee The employee list will be displayed at the bottom of this page. ● Key Template Key template probably is the most useful supporting features when issue many keys.
  • Page 73 allowed) ❖ Steps to create the key template Navigate to create key time control template page. Key Management => Key Template Select Create New Template. Edit Template Name and click Create...
  • Page 74 After clicking Create button it will display Area Control page. According to the requirement, Staffs can access Public Area P (24 hours allowed), Group Area M (24 hours allowed) . Let’s check the box on Public Area P and no need to edit time control because it’s 24 hours open by default. (Click the clock besides the checkbox can edit the time control on this area) Check the box on Group Area M also and no need to edit time control.
  • Page 75 Let’s create another key template for TENANTS. Click Create . Check the box on Public Area P and click its time control button . According to the requirement, Tenants can access Public Area P (6:00 ~ 21:00), Group Area M (24 hours allowed) . Let’s edit the Public Area P time control and click Save to save time control setting.
  • Page 76 Check the box on Group Area M , no need to edit time control this time because it’s 24 hours open by default. Click Save to save TENANTS key template. Navigate to key template management page. Key Management => Key Template You can see those key templates has been created by pull down the select list.

  • Page 77: Create Tenant Cards

    Create Tenant Cards In SIMPLE project, you should at least create 4 tenant cards (Card A~D) for Room A to D with below access control : Card A Public Area P (6:00 ~ 21:00), Group Area M (24 hours allowed), Unit A (24 hours allowed) Card B Public Area P (6:00 ~ 21:00), Group Area M (24 hours allowed), Unit B...
  • Page 78 Click Select Tenant and it will pop up a window to display all tenants you created in user management function. Select tenant kevin to issue key. Select tenant kevin will automatically bring his information back to the Basic Information tab. Select TENANTS key template and you will see TENANTS time control settings in Area Control page...
  • Page 79 According to the requirement, tenant Kevin can access Public Area P (6:00 ~ 21:00), Group Area M (24 hours allowed), Unit A (24 hours allowed) . We had already set up time control of Public Area P and Group Area M via tenant key template, so let’s check Unit A to grant access to Room A.
  • Page 80 At the Review & Issue Key page we can verify the information of tenant key including Basic Information , Unit Area & time control information, Public Area & time control information Group area & time control information Click Issue/Write Key to issue tenant key.
  • Page 81 Place key/card on reader first. Click Read Key From Reader to get Key’s UID.
  • Page 82 The green light LED on Read should blink. If Read Key From Reader failed with three beep sounds and display following message, please re-place key/card and click Read Key From Reader again. If read key successfully click Write Key/Card to issue master key.
  • Page 83 Write Key/Card successfully with two beep sounds. Repeat the similar process to create Tenant Cards for B,C and D.

  • Page 84: Create Staff Card

    Create Staff Card We will then create 2 staff cards in SIMPLE project. Again, you may use the STAFFS key template to complete this job. This time you can practice to choose the staff information from the staff users you created previously. Staff S1 Public Area P (24 hours allowed), Group Area M (24 hours allowed) Staff S2...
  • Page 85 Click Select Staff and it will pop up a window to display all staffs you created at user management. Select staff Peter to issue key. After selecting staff peter the Basic Information page will automatically attach staff’s information. Select STAFFS key template and you will see STAFFS time control settings in Area Control page.
  • Page 86 At the Review & Issue Key page we can verify the information of staff key including Basic Information , Unit Area & time control information, Public Area & time control information Group area & time control information Click Issue/Write Key to issue Peter staff key. Place key/card on reader first.
  • Page 87 Click Read Key From Reader to get Key’s UID. The green light LED on Read should blink. If Read Key From Reader failed with three beep sounds and display following message, please re-place key/card and click Read Key From Reader again.
  • Page 88 If read key successfully click Write Key/Card to issue staff key. Write Key/Card successfully with two beep sounds. Repeat the similar process to create S2 Staff Card.

  • Page 89: Create Vendor Card

    Create Vendor Card Create a vendor card for Vincent Chou, an employee of Dust Buster cleaning company. He will come to clean the swimming pool and the area around Room A~D at 8:00 - 12:00 on every Monday. So we will create a card for him to enter Lockplace P and Lockplace M with time control template : House Cleaning Period.
  • Page 90 Check the box on Public Area P and click time control button to edit. According to the requirement, Vendors can access at 8:00 - 12:00 on every Monday . Let’s use House Cleaning Period time control template we created before on Public Area P then click Save to save time control setting.
  • Page 91 Check the box on Group Area M and click time control button to edit.
  • Page 92 Use House Cleaning Period time control template we created before on Group Area M then click Save to save time control setting. At the Review & Issue Key page we can verify the information of vendor key including Basic Information , Unit Area & time control information, Public Area & time control information Group area &...
  • Page 93 Click Issue/Write Key to issue the vendor key. Place key/card on reader first.
  • Page 94 Click Read Key From Reader to get Key’s UID. The green light LED on Read should blink. If Read Key From Reader failed with three beep sounds and display following message, please re-place key/card and click Read Key From Reader again.
  • Page 95 If read key successfully click Write Key/Card to issue vendor key. Write Key/Card successfully with two beep sounds.

  • Page 96: Create Guest/Temp Card

    Create Guest/Temp Card Guest Card and Temp Card are almost the same. They serve the purpose to temporarily grant access to a visitor. The default expired date will be one day only. The one time pass attribute can be used to further restrict access to lockplace to only one time for all the lockplaces granted.
  • Page 97 Edit guest information. At Area Control page, Check the box on Public Area P and click edit time control button . Let’s assume guest August can access Public Area P on this weekend , edit time control settings and click Save to save time control setting.
  • Page 98 At the Review & Issue Key page we can verify the information of guest key including Basic Information , Unit Area & time control information, Public Area & time control information Group area & time control information Click Issue/Write Key to issue August guest key.
  • Page 99 Place key/card on reader first. Click Read Key From Reader to get Key’s UID.
  • Page 100 The green light LED on Read should blink. If Read Key From Reader failed with three beep sounds and display following message, please re-place key/card and click Read Key From Reader again. If read key successfully click Write Key/Card to issue guest key. Write Key/Card successfully with two beep sounds.

  • Page 101: Shutdown Public Area

    Shutdown Public Area The only public area we have in SIMPLE project is the swimming pool. Suppose you need to close the swimming pool in the winter or for maintenance purpose, it is not a good idea to re-issue all the cards to remove the swimming pool access right. MF-Admin server has two features: Area Time Control and Lock Scheduling which will help you to complete this task in a second without re-issuing any cards.
  • Page 102 Assume the area time control of swimming pool is only for Saturday and Sunday 24 hours . Let’s edit swimming pool time control to meet the requirement, click Save to save time control setting. You can see the lock on Public Area P turn to light green color which means there is a time control setting over this area .

  • Page 103: Lock Scheduling

    ● Lock Scheduling Lock scheduling has nothing to do with Mifare card. It can be used to control the schedule to lock/unlock a lock. In SIMPLE project case, we may use lock operation mode to control the locking status. Three modes are available for a lock (not an area): ❖...
  • Page 104 Click the lock icon in Public Area P . In Operation Mode dialog, select Private and click Save . The Public Area P lock icon color will turn to light green which means it is not normal setting .
  • Page 105 As you can see in the previous screenshots, there is also a time control table which you can set when operation mode is in normal mode. It is used to manage a public/group area where you like it to be passage mode for some period of time of a day in a weekly manner.

  • Page 106: Access Control Rule

    Access Control Rule It is time to elaborate how access rules works. All the locks will apply the access rule when scan a card. Below is the default access rule settings : You have to choose one of the three settings to apply to a combination of card types and area types.
  • Page 107 System Management => System Parameters According to the document, we would want to block all users including the staff to enter swimming pool in private mode. Find out the Staff field and edit NoPrivacy to No and click Save . Now, the swimming pool has been shut down completely except Master Key.

  • Page 108: Time Control - Add/Remove Holidays

    Time Control - Add/Remove Holidays Time control settings can be found in many places in the system and it is straightforward to use. There is only one thing to remind, the holiday. In addition to the settings for 7 days a week, you have another row (the bottom row) to set time control which is the holiday setting.
  • Page 109 Click the blank field to edit holiday assume that 2019/01/01 is a holiday. Click Save to save the holiday. ❖ Remove holiday Click X to remove holiday and click Save . The holiday setting takes precedence over weekly settings. It means if today is holiday and Monday, then the system will check holiday’s settings instead of Monday’s settings.

  • Page 110: Advanced Setup Guide

    Advanced Setup Guide Note : Do not try this section without assistance from reseller or Pamex. Changing any of the parameters in this section to unreasonable value might lead to strange system behavior. Lock Report Interval Lock report interval can be changed at the Lock Operation function.
  • Page 111 15 mins . Click Schedule Job to change the report interval setting. To save the battery’s life, Pamex Kapture smart lock is not always connected to MF-Admin Server. The lock will connect to the MF-Admin Server for every 1800 secs by default.

  • Page 112: Alert Settings

    prepare an invalid Mifare card (You may issue an invalid card easily by assigning no area to it). and scan to a lock will serve this purpose. Alert Settings When you login the MF-Admin Server, there are two icons showing the total number of new alerts at the navigation bar : In the Alert tab of the system parameters, you can see there are ten types of alert that will be generated in the system :...
  • Page 113 can be controlled by the parameter ALERT_SEVERITY_THRESHOLD parameter in the Misc tab of system parameters function.

  • Page 114: Appendix

    Appendix Lock UI Patterns (LED & Buzzer) Wall Reader Action Response (+ : sequential, & : parallel ) Green LED flash interchange 3 times + long Power On beep 1 time LED flash 3 times & beep 3 times Scan Invalid Card (進入Lock Out計算狀態) Scan Crypto Card Green...

  • Page 115: Leverset, Deadbolt

    進入Lock out計算 LED flash every 1 sec, stop flashing in 1 min (default) 狀態 Lock Out LED on for 3 minutes (default) <<Leverset, Deadbolt>>...

  • Page 116: Wifi Ap Specification And Settings

    Wifi AP Specification and Settings Wifi network is necessary for Pamex Kapture solution. The network setup is out of the scope of this manual. Please make sure your network is well configured with your system vendors. Pamex Kapture locks support most of the popular wifi APs in the market. Please make sure your Wifi AP has the features listed below : ●...

  • Page 117: Factory Default Settings - Wall Reader

    Factory default settings - Wall Reader Volume : 3 ( high ), 0~3 Locking Mode : 111, scan card enabled + touch enabled + auto lock enabled Auto Lock Interval : 5 secs Report Interval : 1800 secs Lockout settings : Lockout for 180 secs after 4 fail tries within 60 secs...

  • Page 118: Factory Default Settings - Deadbolt

    Factory default settings - Deadbolt Same as Wall Reader...

  • Page 119: Factory Default Settings - Leverset

    Factory default settings - Leverset Same as Wall Reader...

  • Page 120: Factory Default Settings - Interconnect

    Factory default settings - Interconnect Same as Wall Reader...

  • Page 121: Mf-Admin Server Parameters Default Settings

    MF-Admin Server Parameters default settings Application Parameters Please see MF-Admin Server User Manual. System Parameters Please see MF-Admin Server User Manual.

  • Page 122: Mifare Card Specification

    . The MIFARE® brand name covers proprietary solutions based upon various levels of the ISO/IEC 14443 Type A 13.56 contactless smart card standard. It incorporates DES/Triple-DES encryption standards, as well as an older proprietary encryption algorithm. Pamex Kapture supports only MIFARE DESFire EV1 /EV2 compatible cards/key fobs.

  • Page 123: Card Types

    Crypto Card : To recognize any other types of card, a lock has to read Crypto card. Crypto card is not issued from MF-Admin server. It should be provided by Pamex and is unique to your project. Construction Card : Before the wifi network is ready, the only way to unlock the door locks will be using the construction cards.
  • Page 124 Master Card is an unrestricted access card to any door locks in the project. It is created using MF-Admin server. Master Card is only valid to the locks which has registered to MF-Admin server.

  • Page 125: Area Types

    Area Types There are three types of area you may create in MF-Admin Server : Group Area : Group area is like a folder. It is used to group together the units and public areas in the same floor/building for example. Unit Area : An unit area represents an unit for one family.

  • Page 126: Lock Real Time Events

    Lock Real Time Events 1 : Lock Out 2 : Cylinder Cover Opened 3 : Invalid Key (Mifare Desfire Key) 4 : Single Pass Success...

  • Page 127: Default Severity Of Alert Types

    Default Severity of Alert Types Alert Name Severity Locking fail at auto-lock disabled mode Unlocking fail at auto-lock disabled mode Locking fail at auto-lock mode Battery Change Battery Low Firmware upgrade completed Invalid Key Lock Cover Open Dead Lock Lock Out...

  • Page 128: Fcc Statement

    FCC Statement FCC Statement: Kapture KA-WR1N, Kapture KA-WR1S complie with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) Kapture KA-WR1N, Kapture KA-WR1S may not cause harmful interference, and (2) Kapture KA-WR1N, Kapture KA-WR1S must accept any interference received, including interference that may cause undesired operation.

  • Page 129: Ncc Statement

    NCC Statement NCC Statement: Taiwan Regulatory Information(NCC) 低 功 電 電 機 第十二條 經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得擅自變更頻率、加 大功率或變更原設計之特性及功能。 第十四條 低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應立即停用 ，並改善至無干擾時方得繼續使用。 前項合法通信，指依電信法規定作業之無線電通信。 低功率射頻電機須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干擾。...

This manual is also suitable for:

Kapture ka-wr1n

Table of Contents
