Summary of Contents for Sasem OnAir USB HDTV
- Page 2 Every software and firmware is protected under intellectual property right treaty, computer program preservation and copyright law and international copyright convention. You cannot copy and excerpt this manual without permission. Warrenty : 1 year ⓒ2003-2004 Sasem Co., Ltd. All right reserved. Made in Korea.
- Page 3 INFORMATION TO THE USER (Part 15.105(b)) INFORMATION TO THE USER This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 4 operate the equipment.”...
-
Page 5: Table Of Contents
Contents Introduction ............. 6 Specification ................. 6 Package Included ..............8 System Requirement ............9 Installation ............. 10 Installation Checklist ............10 Hardware Installation ............11 OnAir USB HDTV Device Driver Installation ....11 OnAir USB HDTV Application Software Installation ..14... -
Page 6: Introduction
OnAir USB HDTV Manual Introduction 1.1 Specification Digital & Analog TV Full HDTV of 1920 X 1080 (ATSC) Digital (ATSC) HDTV / Analog (NTSC) TV AC3 / AAC Audio Decoding output Recording & Playback Real-time or Schedule Recording Still Capture (JPEG or BMP File) - Page 7 Introduction Individual Channel Color Adjustment Digital Signal Strength Display Sleep Timer Remote Control (IR Model Only) * Time-Shifting ? While playing live Analog TV, the time shifting offers you ability to pause the live TV for pre-defined period of time. It provides by recording Live TV in real-time for pre-defined period of time while playing Live TV.
-
Page 8: Package Included
OnAir USB HDTV Manual 1.2 Package Included 3.USB Cable 1.USB HDTV 2.Remote 4.RF Antenna Controller (AAA Cable Battery included) 5.InstallationC 6.Installation 7.Adapter Manual If something excluded, please contact with our Customer support department. (+82-31-978-8660) -
Page 9: System Requirement
Introduction 1.3 System Requirement USB 2.0 port supported Desktop PC or Notebook (PCI / PCMCIA types of USB2.0) OS : MS Windows XP Service Pack 1 or above, MS Windows XP Media Center Edition (MCE 1.x) DirectX 9.0 Minimum system requirement (with DXVA support) ATI RADEON 7200 or Nvidia Geforce MX 440 or above... -
Page 10: Installation
OnAir USB HDTV Manual Installation 2.1 Installation Checklist 2.1.1 Windows XP Service Pack 1 Installation From the desktop menu of "My Computer", click the mouse’s right button to open the “Properties". Then, find out what the current operating system is running on your system. If your operation system is not "Microsoft Windows XP Service Pack 1"... -
Page 11: Hardware Installation
USB 2.0 device. 2.2 Hardware Installation OnAir USB HDTV is an external HDTV device that connected with personal computer or notebooks via USB2.0 port. Please plug in the power adaptor into hardware, and connect with personal computers or notebooks via USB cable. - Page 12 OnAir USB HDTV Manual 2.3.1 OnAir USB HDTV Device Driver Installation for Windows XP 1. This is a dialog box of choosing a language of installation program. Please choose languages either English or Korean, and press [OK] button continue. 2. This is a dialog box of the...
- Page 13 2. Installation 4. If you are ready to run the installation program, please click the [Next] button to continue. 5. The OnAir HDTV device driver installation completed. Please click the [Finish] button, and plug in the OnAir USB HDTV device into your system via USB2.0..
-
Page 14: Onair Usb Hdtv Application Software Installation
HDTV Application Software Installation The OnAir USB HDTV application software installation is provided based on application software version 2.2. The given installation CD with package includes the application software of OnAir USB HDTV. Please insert the provided installation CD into your system’s CD- ROM drive. - Page 15 2. Installation It is a dialog box of adding remote control program into “Start Program”. your convenience, recommend you to add the program in “Start Program” by clicking “Yes” button. It is a dialog box of adding Scheduler program into “Start Program”.
