LIMITADOR DE VELOCIDAD DYNATECH/
DYNATECH OVERSPEED GOVERNOR/
LIMITEUR DE VITESSE DYNATECH/
GESCHWINDIGKEITSBEGRENZER
DYNATECH/
VEGA
INSTRUCCIONES DE USO Y MANUTENCIÓN/
INSTRUCTIONS FOR USE AND MAINTENANCE/
INSTRUCTIONS D'USAGE ET ENTRETIEN/
GEBRAUCHS- UND WARTUNGSANLEITUNG/

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VEGA and is the answer not in the manual?

Questions and answers

Related Manuals for Dynatech VEGA

Summary of Contents for Dynatech VEGA

  • Page 1 LIMITADOR DE VELOCIDAD DYNATECH/ DYNATECH OVERSPEED GOVERNOR/ LIMITEUR DE VITESSE DYNATECH/ GESCHWINDIGKEITSBEGRENZER DYNATECH/ VEGA INSTRUCCIONES DE USO Y MANUTENCIÓN/ INSTRUCTIONS FOR USE AND MAINTENANCE/ INSTRUCTIONS D’USAGE ET ENTRETIEN/ GEBRAUCHS- UND WARTUNGSANLEITUNG/...

  • Page 13: Table Of Contents

    Overspeed contact................7 Remote tripping mechanism (optional) ..........8 Remote reset device (Optional) ............10 Uncontrolled movement UCM device ..........10 VEGA LS OVERSPEED GOVERNOR ..........17 FIXING TO THE FLOOR................17 TECHNICAL FEATURES................18 TYPE OF ADJUSTMENT................19 INSTRUCTIONS OF USE AND MAINTENANCE.

  • Page 14: Introduction

    The VEGA overspeed governor covers a wide range of speeds and can be used with instant and progressive safety gears.

  • Page 15: Working Principles

    INSTRUCTIONS: VEGA Cod: DYN35.05 Date: 25-02-2013 Check: 05 3 WORKING PRINCIPLES. The governor is of the centrifugal type and is able to work either upwards or downwards. The governor is fixed directly to the floor in the machine room or in the upper part of the well, joined by the rope to its tensing pulley located in the pit.
  • Page 16 INSTRUCTIONS: VEGA Cod: DYN35.05 Date: 25-02-2013 Check: 05 The ends of the rope (2) are attached to the linkage anchoring (1) thorugh eyes.
  • Page 17 INSTRUCTIONS: VEGA Cod: DYN35.05 Date: 25-02-2013 Check: 05 The tension weight is secured to the guide rail by flanges. The rope must have enough tension (500 N on each side). In the event of tension loosening a rope slackening contact (1) connected to the installation...
  • Page 18 INSTRUCTIONS: VEGA Cod: DYN35.05 Date: 25-02-2013 Check: 05 Due to the weight of the masses, the contact is protected from knocks by the part to which it is attached, therefore, the sensor cannot be damaged. The tension weight assembly can be attached to both sides of the guide rail.

  • Page 19: Overspeed Contact

    INSTRUCTIONS: VEGA Cod: DYN35.05 Date: 25-02-2013 Check: 05 As indicated, if the tightness would be less than acceptable, the bar supporting the weight and the pulley would make contact with the sensor. 3.1 OVERSPEED CONTACT. The governor has a built-in overspeed contact.

  • Page 20: Remote Tripping Mechanism (Optional)

    INSTRUCTIONS: VEGA Cod: DYN35.05 Date: 25-02-2013 Check: 05 For rated speeds above 1 m/s, the overspeed switch must be triggered at a speed above the rated speed, bellow tripping speed of the governor. The contact (2) is shown in the right picture.
  • Page 21 INSTRUCTIONS: VEGA Cod: DYN35.05 Date: 25-02-2013 Check: 05 • Solenoid fed by 24 V DC (direct current). A current of 1,1 A must be provided. • Solenoid fed by 48 V DC (direct current). A current of 0,75 A must be provided.

  • Page 22: Remote Reset Device (Optional)

    3.4 UNCONTROLLED MOVEMENT UCM DEVICE As a result of application of the new lift standard EN-81-1:1998+ A3, the Vega governor is fitted with a system that can be used to prevent uncontrolled car movement (UCM). This system is called the Parking System.
  • Page 23 The pins therefore remain in the governor locking position. The figure shows a Vega speed governor fitted with the parking system. 3.4.1 PARKING SYSTEM CONTROL SENSOR: As can be seen in the figure above, the parking system is fitted with a control sensor.
  • Page 24 In the event of uncontrolled car movement, the governor and the parking system will transmit the force to the safety gear in order to stop the car. Dynatech currently offers 2 types of parking system. These systems are described below: •...
  • Page 25 INSTRUCTIONS: VEGA Cod: DYN35.05 Date: 25-02-2013 Check: 05 The distance of the governor may be shorter than that indicated, depending on the position of the locking part in the centrifugal system. Note: The Alfa parking system can be adapted to existing governors with no parking system.
  • Page 26 According to Point 9.11.7 of the Standard, uncontrolled movement must be detected by a switch. However, detecting uncontrolled movement using the Dynatech design is pointless, as the parking device remains activated when the car is at a standstill. (except in installations with door pre-opening and re- levelling).
  • Page 27 INSTRUCTIONS: VEGA Cod: DYN35.05 Date: 25-02-2013 Check: 05 Use in installations with re-levelling over 20 mm: in installations with re- levelling over 20 mm, certified switching must be used to activate the electric magnet during the re-levelling process because if it re-levels by more than 20 mm then the governor could lock and the safety gear engage.
  • Page 28 INSTRUCTIONS: VEGA Cod: DYN35.05 Date: 25-02-2013 Check: 05 3.4.5 TECHNICAL SPECIFICATIONS • Electric magnet: Coil with 100% operating factor Voltage (V) I (Alfa p.s.) (A) I (Beta p.s.) (A) 24 DC 0.26 0.46 48 DC 0.13 0.23 190 DC 0.05 0.10...

  • Page 29: Vega Ls Overspeed Governor

    This governor is DOWNWARDS ACTING ONLY and the performance speed range is: 0.40 – 0.70 m/s IMPORTANT NOTE: Customers asking for a VEGA LS, may know that it´s unidireccional. In order to know the right way, it must pay attention to to the arrow in the governor.

  • Page 30: Technical Features

    INSTRUCTIONS: VEGA Cod: DYN35.05 Date: 25-02-2013 Check: 05 plate. The rope (3) and its position with respect to the base plate can also be seen in the drawing. 5 TECHNICAL FEATURES. Machine: Overspeed governor Model: VEGA Manufacturing company: DYNATECH, DYNAMICS & TECHNOLOGY, S.L.

  • Page 31: Type Of Adjustment

    INSTRUCTIONS: VEGA Cod: DYN35.05 Date: 25-02-2013 Check: 05 It can be unidirectional or bidirectional An encoder can be assembled (VEGA PLUS) Safety gears with which it may be used: All safety gears with a tripping speed that can be reached by the overspeed governor.
  • Page 32 INSTRUCTIONS: VEGA Cod: DYN35.05 Date: 25-02-2013 Check: 05 For tripping speeds lower than 1 m/s, a low speed system is installed, where, as it is shown in the picture, the adjustment is made by means of a tensing screw that lengthen or shrinks the spring that is hooked to the...

  • Page 33: Instructions Of Use And Maintenance

    Dynatech will not be held responsible for any problem or accident caused by not observing the indications and advices described both in these instructions and in the EC Type examination certificate.
  • Page 34 INSTRUCTIONS: VEGA Cod: DYN35.05 Date: 25-02-2013 Check: 05 Front view:...
  • Page 35 INSTRUCTIONS: VEGA Cod: DYN35.05 Date: 25-02-2013 Check: 05 Side view: Bottom view:...
