Replacing The Keyboard; Procedure - Dell Inspiron 7786 Service Manual

WARNING: Before working inside your computer, read the safety information that shipped with your computer and follow the
steps in Before working inside your
your computer. For more safety best practices, see the Regulatory Compliance home page at
regulatory_compliance.

Procedure

1 Align the screw holes on the keyboard with the screw holes on the palm-rest assembly.
2 Replace the five screws (M1.2x1.5) that secure the keyboard to palm-rest assembly.
3 Align the screws holes on the keyboard bracket with the screw holes on the keyboard.
4 Replace the 32 screws (M1.4x2) that secures the keyboard bracket to keybaord.
computer. After working inside your computer, follow the instructions in

Replacing the keyboard

www.dell.com/
39
After working inside
Replacing the keyboard 61
