TRUCK STORAGE SOLUTIONS
SECURING YOUR REPUTATION
ATTENTION: PLEASE READ AND UNDERSTAND ALL INSTRUCTIONS AND WARNINGS
BEFORE ASSEMBLING, INSTALLING OR USING THIS PRODUCT.
MODELS
350-X-01, 351-X-01, 352-X-01, 354-X-01, 357-X-01, 358-X-01, 359-X-01, 360-X-01
Note:
X represents the color code for your model: 3 = White | 5 = Black
NOTICE
Use specific aluminum upfit components when installing WEATHER GUARD®
products to aluminum truck beds. Follow additional instructions if mounting
to an aluminum truck bed. There may be left over components depending on
upfit.
Any modification or unintended use of this product shall immediately void all
manufacturers warranties. Manufacturer disclaims all liability for injuries to
persons or property resulting from any modification to, or unintended use of
this product.
CAUTION
Transfer tank bottom must be fully supported by the floor of the truck bed so
as not to cause flexing of the tank which could cause stress cracks and leak-
age of the tank. To keep debris out of your eyes when checking the underside
of the vehicle, or when drilling, always wear protective eyewear.
©2015 KNAACK LLC
INSTALLATION MANUAL
STEEL & ALUMINUM SIDE BOX WITH
PACK RAT
®
®
TRANSFER TANKS
DRAWER UNITS
Danger of explosion. Do not use this product for storing or transporting flam-
mables, explosives, hazardous materials, or hazardous waste, such as contain-
ers of gasoline, solvents, gun powder, dynamite, propane tanks, acetylene
tanks and cutting torches. This product is only intended and safe for use in
storing and transporting small tools, equipment and other similar materials.
Any modifications made to, or unintended use of this product, could create a
hazardous condition that can cause death, serious personal injury or property
damage.
WARNING
Prior to drilling, so as not to cut or puncture fuel tanks, fuel lines, electric
wires, etc., check under vehicle for locations. All floor mounting bolts near the
gas tank area should be installed from the underside of the vehicle, to guard
against the gas tank being punctured in the event of a collision. This would
mean not using Blind Fastener in this area. Holes drilled in this area should be
3/8".
Advertisement
Table of Contents
Summary of Contents for Weather Guard 350-3-01
- Page 1 X represents the color code for your model: 3 = White | 5 = Black NOTICE DANGER Use specific aluminum upfit components when installing WEATHER GUARD® Danger of explosion. Do not use this product for storing or transporting flam- products to aluminum truck beds. Follow additional instructions if mounting mables, explosives, hazardous materials, or hazardous waste, such as contain- to an aluminum truck bed.
- Page 2 DANGER Use of flammables in this transfer tank may cause an explosion, resulting in serious bodily injury, death, or property damage. To avoid such risk: DO NOT use this transfer tank to transport, transfer or store flammables, such as gasoline. DO NOT use this transfer tank as an auxiliary fuel tank by connecting it to an existing fuel system.
- Page 3 INSTALLATION INSTRUCTIONS Note: If your truck bed is constructed of aluminum, use zinc rich primer to coat drilled holes. Installing the Transfer Tank STEP 1 Note: • When installing model 352 Transfer Tank with a 27" tool box in a full size short bed pickup, the Tank will need to Install drain plug into drain hole.
