Cobra Garden Machinery GT3024V Owner's Manual

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

MODELS: GT3024V (GT-PS3035D)

Cobra Garden Machinery

Henton and Chattell Ltd., London Road, Nottingham NG2 3HW UK

www.cobragarden.co.uk

WARNING：

For your own safety please read this manual before attempting to operate your new unit.

Failure to follow instructions can result in serious personal injury. Spend a few moments

to familiarize yourself with your garden tool before each use. Keep this manual in a safe

place, so that the information is available at all times. If you give the equipment to any

other person, hand over these operating instructions and safety regulations as well.

Table of Contents

Need help?

Do you have a question about the GT3024V and is the answer not in the manual?

Questions and answers

Summary of Contents for Cobra Garden Machinery GT3024V

Page 1 MODELS: GT3024V (GT-PS3035D) Cobra Garden Machinery Henton and Chattell Ltd., London Road, Nottingham NG2 3HW UK www.cobragarden.co.uk WARNING： For your own safety please read this manual before attempting to operate your new unit. Failure to follow instructions can result in serious personal injury. Spend a few moments to familiarize yourself with your garden tool before each use.
Page 2: Table Of Contents
CONTENTS Safety symbols ................3 Safety precautions ..............3 General Safety ................4 Description of the grass trimmer ..........7 Technical Data ................7 ................8 Assembly ............ Starting and Operation ............13 Maintenance and Care…………………………………………...13 Troubleshooting…………………………………………………...14 Warranty……………………………………………………………14 Disposal .................. 15 EC-Declaration ................
Page 3: Safety Symbols
1. SYMBOLS Some of the following symbols used on your tool, please study them and learn their meaning, proper interpretation of these symbols will allow you to operate the tool more safely and effectively. Caution / Warning! Double insulation Read the Instruction manual! Keep bystanders away Wear hearing protection...
Page 4 2.2 ELECTRICAL SAFETY a) Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will reduce risk of electric shock. b）Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and refrigerators.
Page 5 b) Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be controlled with the switch is dangerous and must be repaired. c) Disconnect the plug from the power source and/or the battery pack from the power tool before making any adjustments, changing accessories, or storing power tools.
Page 6 electric shock. 2.6.2 Additional safety warnings 1. This tool is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
Page 7: Description Of The Grass Trimmer
Twist Lock – Handle Spool Rotating Lower Section Guard Rotated Cover Razor Blade – Line Trimmer Autofeed Cutting Head 4. TECHNICAL DATA Model: GT3024V Nominal voltage No-load speed n 0 8500/6000Rpm 2.7（3.5）kg Weight Cutting width 300 mm Cutting line diameter 1.6 mm...
Page 8: Assembly
5. ASSEMBLY WARNING: Switch off and remove the battery from machine before adjusting or cleaning. The head will continue to move for a fraction of a second after the trimmer is switched off. Do not touch the moving nylon line or the trimmer head. 5.1 FITTING THE BATTERY The battery is supplied from the factory partly charged.
Page 9 10. Do not use the charger in an environment where there are toxic fumes or flammable liquids. 11. Only use the charger indoors. Start charging the battery for a minimum of 5 hours before using the machine the first time. Thereafter the normal charging time is approximately 2 to 3 hours.
Page 10 Ensure the guard is positioned as shown in figure 3, then proceed to fix the screws in place as illustrated below in figure 4. 5.4 FITTING THE SPOOL To remove the spool and replace the nylon line: Firstly press the two tabs on the side of the trimmer head, figure 5.
Page 11 5.5 FITTING THE EDGING WHEEL The lawn edging wheel is simply push fitted into place, with a firm locking mechanism. 5.6 ADJUSTING THE HANDLE POSITION The middle support handle position may be adjusted by pulling the lever ‘F’ as illustrated in figure 7.
Page 12 5.7 CHANGING THE TRIMMER HEIGHT The height of the trimmer may be adjusted by turning the central tube lock anti-clockwise to allow the tube to be extended or shortened as required. Turn the lock clockwise to lock the position in place. 5.8 CHANGING THE TRIMMER HEAD POSITION The trimmer head angle may be adjusted by pressing the head rotation button, as shown in figure 12.
Page 13: Starting And Operation
6. STARTING AND OPERATING INSTRUCTIONS Step 1：Firstly press the power key until the “ECO” light is illuminated； Step 2：Press the slider switch in and then engage the handle trigger, the motor will operate at a low speed； Step 3： If you want to change from the low speed position to high speed position， press the “TURBO”...
Page 14: Troubleshooting
accumulate. 3. Store the trimmer in a secure, dry place out of the reach of children. Do not place other objects on top of the machine. 4. The battery should be stored between 0 ° C and 50 ° C. 8.
Page 15: Disposal
oils and grease or accessories. Damage or defects resulting from abuse, accidents or alterations, natural fading of painted or plated surfaces, sheet peeling and other natural deterioration. Any damage that occurs from the use of non-genuine Cobra parts will not be covered. We reserve the right to reject any claim where the purchase cannot be verified or when it is clear that the product was not maintained properly.
Page 16: Ec-Declaration
11. EC-DECLARATION OF CONFORMITY Cobra Garden Machinery, Henton & Chattell Ltd, We herewith declare, London Road, Nottingham NG2 3HW UK That the following machine complies with the appropriate basic safety and health requirements of the EC Directive based on its design and type, as brought into circulation by us.
