TECHNICAL DETAILS
For full technical details on all our products,
please visit our website
www.arcadebathrooms.com
F
www.arcadebathrooms.com
Beautifully
Traditional
Arcade single lever bidet mixer
with pop up waste
INSTALLATION INSTRUCTIONS
ARC13, ARC13 CHR
www.arcadebathrooms.com
1
Advertisement
Summary of Contents for Arcade ARC13
- Page 1 Beautifully Traditional Arcade single lever bidet mixer TECHNICAL DETAILS ARC13, ARC13 CHR with pop up waste For full technical details on all our products, please visit our website www.arcadebathrooms.com INSTALLATION INSTRUCTIONS www.arcadebathrooms.com www.arcadebathrooms.com...
-
Page 2: Installation Instructions
Beautifully Arcade single lever bidet mixer ARC13, ARC13 CHR Traditional with pop up waste INSTALLATION INSTRUCTIONS DIMENSIONS Please read these instructions carefully and keep in a safe place for further reference. General Installation Requirement The installation must comply with regulations of the Local Water Authority as contained in their bylaws. - Page 3 Beautifully Arcade single lever bidet mixer ARC13, ARC13 CHR Traditional with pop up waste INSTALLATION INSTRUCTIONS First shut off your water heating system, then with your mains stop cock closed, open the lowest cold and hot taps in the house and allow to run until the cold storage tank and pipes are empty (the hot storage cylinder always remains full).
-
Page 4: Maintenance
Beautifully Arcade single lever bidet mixer ARC13, ARC13 CHR Traditional with pop up waste MAINTENANCE FILTER CLEANING Taps are supplied with two different filters : low pressure Flow Straigteners Note : Remember to turn off the water supply before commencing any maintenance. - Page 5 Beautifully Arcade single lever bidet mixer ARC13, ARC13 CHR Traditional with pop up waste FILTER NOZZLES Flow Straightener Filter and Neoperl Aerator Filter The taps are supplied with factory fitted Flow Straightener filters for low pressure water systems. If the water pressure is high ( above 1 bar ), replace the flow straightener filter with the high pressure Neoperl aerator filter.
