- Page 1 CLEMENTS Duplex Adaptors SUC89660 SUC89661 User Manual Manual No. SUC 89660 081 Issue 10...
- Page 2 CLEMENTS Safety Thank you for purchasing this Clements Duplex Adaptor. For your safety it is imperative that this unit only be operated by authorised personnel in accordance with the instructions as described in this manual. Operated in this way, the Duplex Adaptor will provide years of service.
-
Page 3: Table Of Contents
CLEMENTS Contents Specifications ..........Transportation and Storage ......Installation and Operation ......Spares Parts………………………………....Troubleshooting………………………………………. Cleaning ............Disassembly ............ Warranty ............Contents... -
Page 4: Specifications
CLEMENTS Intended Use Connect two pieces of medical gas equipment to a single medical gas terminal unit. Specifications Vacuum Range 0 to -100 kPa, 0 to -750 mmHg 0 to 35 Litres of Free Air Per Minute Flow Rate Lever... -
Page 5: Transportation And Storage
CLEMENTS Transportation and Storage Environmental conditions for transportation and storage are shown in the following table. Parameter Minimum Maximum Temperature 10ºC 40ºC Humidity 60% RH 95% RH Barometric Pressure 700 mBar 1060 mBar Warning Symbols Legend The warning symbols marked on the equipment and their meanings are shown as follows. -
Page 6: Installation And Operation
CLEMENTS Description The Clements Duplex Adaptor allows the connection of two pieces of equipment to a single wall terminal unit. Clements Duplex Adaptors are available to connect to most types of wall outlet. Item Description SUC 89660 Duplex Suction Adaptor without Lever, Ring Index... -
Page 7: Spares Parts
CLEMENTS Spare Parts SUC 89771 Ring Index Connector Kit for Wall Suction Products ( Handwheel, 1/8 BSP Threaded Nipple, O-Ring) SUC 89240 019 Puritan Bennett Connector with 1/8 BSP Thread SUC 89240 074 BS MKIV Connector with 1/8 BSP Thread... -
Page 8: Troubleshooting
CLEMENTS Troubleshooting Fault Check Rectify No Vacuum / Flow On / Off Lever Ensure turned on Wall outlet blocked Refer to engineering dept. Body blocked Strip and clean Troubleshooting... -
Page 9: Cleaning
CLEMENTS Cleaning Cleaning Clean using a pH neutral disinfectant for wiping or immersion cleaning. Flush after immersion using distilled water and dry before reassembly of unit. Cleaning Procedure Tools and Materials Required Allen key set, imperial • Vacuum grease •... -
Page 10: Disassembly
CLEMENTS Disassembly Procedure Remove unit from wall. Remove the hand wheel by inserting an allen key into the brass nipple in the centre of the hand wheel. Make sure the allen key is pushed home into the brass nipple before unscrewing. - Page 11 CLEMENTS Notes...
- Page 12 CLEMENTS Notes...
- Page 13 CLEMENTS Notes...
-
Page 14: Warranty
CLEMENTS Warranty BMDi TUTA Healthcare Pty Limited ("BMDi TUTA Healthcare") warrants that this product is free from defects in workmanship and materials for a period of 12 months from the date of shipment by BMDi TUTA Healthcare or its authorised agent to the purchaser. Subject to the... - Page 15 CLEMENTS • any modifications of the product which were not authorised in writing by BMDi TUTA Healthcare; • any contamination or leakages caused or induced by the purchaser; and • inadequate or improper maintenance of the product. This warranty does not cover normal wear and tear.
