Steelcraft 53010 Installation Instructions

PARTS LIST

1x FRONT BAR
1x TOP MOUNTING BRACKET
1x FRAME MOUNTING BRACKET PASSENGER SIDE
1x FRAME MOUNTING BRACKET DRIVER SIDE
4x 5/16 FLAT WASHERS
6x 7/16 X 1 ¼ HEX BOLTS
12x 7/16 FLAT WASHERS

INSTALLING FRAME MOUNTING BRACKETS

1. Using the factory existing bolts, (there should be two of these bolts preside) 5/16 x 5 hex
bolts, 5/16 hex nuts & 5/16 flat washers, provided in kit. Attach the mounting frame
brackets as per diagrams.

INSTALLING THE FRONT BAR

2. Line up the 3 holes on the lower portion of the front bar with the 3 holes on the frame
//mounting brackets (outer edge) using the 7/16 x 1 ¼ hex bolts, hex nuts & flat
washers to fasten the front bar to the mounting frame brackets. Once the front bar is
attached to the mounting brackets align the left and right side of the front bar to the
bumper.

INSTALLING THE TOP BRACKET

3. using the factory existing crews, ¼ x ¾ screws and ¼ hex nuts, attach top bracket
behind license plate.
4. Once you are satisfied that the left and right side are equal distances from the bumper
tighten all fasteners.
NOTE: IT IS ADVISABEL TO RE-CHECK ALL FASTENERS FOR TIGHTNESS AFTER ONE
WEEK.
INSTALLATION INSTRUCTIONS
FRONT BAR PART #
99-02 TOYOTA 4RUNNER 2/4WD
53010
2x 5/16 S 5 HEX BOLTS
2x 5/16 HEX NUTS
6x 7/16 HEX NUTS
