Summary of Contents for Jungle Jim’s MTR
- Page 1 ASSEMBLY INSTRUCTIONS...
- Page 2 7 (x2) ITEM # PART NUMBER DESCRIPTION ATR-TH TRIMMER HOOK WELDMENT ATR-LN LOCKING NUT MTR-HBRACE HORIZONTAL BRACE MTR-UPPER V UPPER VERTICAL SUPPORT MTR-LOWER V LOWER VERTICAL SUPPORT ATR-CP COMPRESSION PIN ATR-WASH 3/8” SQUARE WASHER MTR-MW LOCKING POLE ASSEMBLY 3/8” – 16 x 2 ¼ ” FLAT HEAD SOCKET SCREW TRAILER MATE EXTENSION SPRING 5/16”...
- Page 3 (#13) for each support. Securely tighten all hardware from steps 1 & 2. Finally, put a trimmer in the MTR and slide the compression pin assembly down in the slot until it rests on top of the trimmer shaft. Remove the trimmer and slide compression pin assembly down another 1/16”...
