Nano SeaCam
Operator's Manual
4033 Ruffin Road
San Diego, CA
T:
(858) 576-1261
92123- 1817 USA
F:
(858) 576-0219
®
Nano SeaCam
Record product serial number below as it appears on the nameplate.
Serial #
Connector Type
Pin-outs
● Ground = Pin ____
● PWR = Pin ____
● Video = Pin ____
www.deepsea.com
sales@deepsea.com
®
Original Instruction
REV 4/28/14
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Deep Sea Electronics Plc Nano SeaCam
-
Page 1: Recording Form For Product Serial Number
Nano SeaCam ® Operator’s Manual ® Nano SeaCam Record product serial number below as it appears on the nameplate. Serial # Connector Type Pin-outs ● Ground = Pin ____ ● PWR = Pin ____ ● Video = Pin ____ 4033 Ruffin Road www.deepsea.com... -
Page 2: Specification Overview
Nano SeaCam ® Operator’s Manual Specification Overview Standard Connector Mechanical Specifications Housing 6AI-4V Titanium MCBH4MP Port Optically Polished Sapphire Outer Diameter 25.0 mm (0.99 in) 1 = Ground Overall Length (w/o connector) 54.5 mm (2.15 in) 2 = Power 3 = Video Out Weight in Air 123.5 g (4.36 oz) -
Page 3: Table Of Contents
Nano SeaCam ® Operator’s Manual Table of Contents Recording Form for Product Serial Number Specification Overview Table of Contents Safety Symbols General Notes and Warnings Pre and Post Dive Inspection Operation Procedure Operation Instruction Flooding Repair Procedure Troubleshooting RMA Procedure for Repair... -
Page 4: Safety Symbols
General Notes & Warnings Pre and Post Dive Inspection The Nano SeaCam supports a variety of connectors and Rinse your Nano SeaCam in fresh water after use in depth ratings. If looking on the body near the lens one saltwater. -
Page 5: Operation Procedure
Nano SeaCam ® Operator’s Manual away from persons and valuable equipment NOTICE and make sure that the power is disconnected. See the Flooding Repair procedure for more DeepSea Power & Light cannot information. responsible for any damage incurred during emergency field repairs. Such repairs should... -
Page 6: Warranty Information
Nano SeaCam ® Operator’s Manual have been proved defective and does not include any DeepSea Power & Light other costs such as the cost of removal of the defective part, installation, labor, or consequential damages of any Attn: RMA ####...
