Zhengzhou Winsen Electronics Technology Co., Ltd
www.winsen-sensor.com
Electrochemical CO Module
（Model：ZE07-CO）
User's Manual
Version: 1.2
Valid from: 2014-11-10
Zhengzhou Winsen Electronics Technology Co., Ltd
Tel: 86-371-67169097
Fax: 86-371-60932988
Email: sales@winsensor.com
Leading gas sensing solutions supplier in China！
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Winsen ZE07-CO
Summary of Contents for Winsen ZE07-CO
- Page 1 Zhengzhou Winsen Electronics Technology Co., Ltd www.winsen-sensor.com Electrochemical CO Module （Model：ZE07-CO） User’s Manual Version: 1.2 Valid from: 2014-11-10 Zhengzhou Winsen Electronics Technology Co., Ltd Tel: 86-371-67169097 Fax: 86-371-60932988 Email: sales@winsensor.com Leading gas sensing solutions supplier in China！...
- Page 2 Statement This manual’s copyright belongs to Zhengzhou Winsen Electronics Technology Co., LTD. Without the written permission, any part of this manual shall not be copied, translated, stored in database or retrieval system, also can’t spread through electronic, copying, record ways.
-
Page 3: Product Description
Electrochemical CO Module ZE07-CO Product Description ZE07-CO is a general-purpose and miniaturization electrochemical carbon monoxide detection module. It utilizes electrochemical principle to detect CO in air which makes the module with high selectivity and stability. Built-in temperature sensor can do temperature compensation; and it has digital output and analog voltage output. It is a combination of mature electrochemical detection principle and sophisticated circuit design. - Page 4 Zhengzhou Winsen Electronics Technology Co., Ltd www.winsen-sensor.com Pin Description PIN15 Vin（Voltage input 5V-12V） PIN5、PIN14 PIN1 VOUT(Voltage output 3.0V) PIN3 Reserved PIN4 Reserved PIN7 UART (RXD) 0~3.0V Data input PIN8 UART(TXD) 0~3.0V Data output PIN9 Sensor analog signal PIN10 DAC 0.4V-2V (0 - full range)
- Page 5 Zhengzhou Winsen Electronics Technology Co., Ltd www.winsen-sensor.com Switch command to the question & answer mode, the command line format is as follows: Table 5 Byte 0 Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Byte6 Byte 7 Byte 8...
- Page 6 Zhengzhou Winsen Electronics Technology Co., Ltd www.winsen-sensor.com unsigned char j,tempq=0; i+=1; for(j=0;j<(ln-2);j++) tempq+=*i; i++; tempq=(~tempq)+1; return(tempq); Cautions 1. DO NOT insert or extract the sensor on the PCB board. 2. DO NOT change or move the electronic part on the module.
