- Page 1 Cab Control Operators Manual Cab Control 3400 Cab Control 2400 Cab Control 3600 Ft. Atkinson, Wisconsin USA nningen, The Netherland www.digi-star.com D3820-US Rev B June 21, 2013...
-
Page 2: Table Of Contents
Cab Control Table Of Contents BEFORE CHARGING BATTERY OR WELDING ........3 OPERATION ....................4 TURN ON INDICATOR ..............4 COMMUNICATE WITH DIFFERENT TRUCK ......... 4 SETTING UP INDICATOR ................. 5 SETTING UP THE CAB CONTROL ............6 INSTALLATION ..................7 CAB CONTROL MOUNTING ............ -
Page 3: Before Charging Battery Or Welding
Operators Manual BEFORE CHARGING BATTERY OR WELDING Important Precaution Disconnect all indicator leads before charging battery or welding. Damage may occur to indicator. Note: All illustrations are the EZ3600 Cab Control. Keys used in this document are in same general location on all models. If power supply low, recharge battery –... -
Page 4: Operation
Cab Control See page 7 for installation instructions. OPERATION Turn on Cab Control HELLO 1. Press No signal received, Cab Control display flashes NODATA and scale number (Example SCL 1). Nodata Signal received, display matches scale indicator and indicator is controlled by Cab Control. - Page 5 Operators Manual SETTING UP SCALE INDICATOR EZ scale indicator has internal radio installed that is assigned a scale number. Two indicators cannot operate using the same scale number. To set proper radio operation: 3. Press and hold a then press holding both for 3 seconds.
-
Page 6: Setting Up The Cab Control
Cab Control SETTING UP THE CAB CONTROL 1. Press 2. Press and hold then setup press . Continue to hold for 8 seconds. 3. SETUP and BUZZER will show on display followed by current setting. 4. Press toggles buzzer on/off then press to advance to autoff. -
Page 7: Installation
Operators Manual INSTALLATION Cab Control Mounting The Cab Control communicates with a scale indicator using an internal radio. For best results, place both indicator and Cab Control in locations not surrounded by metal. Glass does not block radio signals. NOTE: The Cab Control usually works fine if the scale indicator is mounted inside the truck cab and the Cab Control is mounted inside the loader at dashboard level. -
Page 8: Fcc Notifications
To comply with FCC regulations, this device may be used only with approved antennas. Contact Digi-Star Customer Support for additional information. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
