- Page 1 USER’S MANUAL 2 Zone Mixer Amplifier...
- Page 2 2 Zone Mixer Amplifier Pre caution The lightning flash with arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that maybe of sufficient magnitude to constitute a risk of electric shock to persons. 1.
-
Page 3: Product Introduction
2 Zone Mixer Amplifier Product Introduction 2 Zone Compact Mixer Amplifier are product use for commercial audio system. The product include built-in audio sources USB,SD card, FM tuner, Bluetooth and 1 auxiliary audio sources. It is designed in modern style with black front panel with standard rack mount kits, made in reliable quality for commercial applications, and delivers high level sound performance. -
Page 4: Front View
2 Zone Mixer Amplifier Front View -12 dB -6 dB 0 dB USB / FM / BLUETOOTH SD/MMC ZONE VOLUME MEMORY MODE BASS TREBLE MASTER POWER 1. Power ON / OFF switch 10. MP3/FM Player display 11. Volume control knob for MIC jack 6.35mm 2. - Page 5 2 Zone Mixer Amplifier Basic Instruction 1. Zone volume control Use zone volume knob to adjust the volume of zone1~2 separately. The amplifier distribute power to each zone randomly, the total power of loaded speaker should be less than the power of amplifier. 2.
- Page 6 2 Zone Mixer Amplifier Wiring and Connection Illustration BLUETOOTH Fuse ANTENNA TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK MADE IN CHINA DON’T EXPOSE THIS EQUIPMENT TO RAIN OR MOISTURE PLACE www.ampspk.net AUX INPUT 100V 100V 4-16ohm FM ANT Zone1 Speakers Zone2 Speakers PC / DVD / VCD...
- Page 7 2 Zone Mixer Amplifier Specification Model No. Model No. Rated Power 120W Built-in Audio USB, FM Tuner, Bluetooth Speaker Output 4-16 ohm, 70V, 100V Input Sensitivity Mic: 12mV/600Ω unbalanced 6.3mm jack input AUX1/2:220mV/10KΩ RCA Frequency Response 80~18KHz (+1dB, -1dB) S/N Ratio Mic: 66dB / AUX: 80dB Less than 0.1% at 1KHz, 1/3 rated power Protection...
- Page 8 Thanks for your purchase ! Please contact our dealer or our company if any information or assistance may needed. Dealer Due to continuous improvement, the product may be updated without notification.
