When disconnecting charger, disconnect AC cord, remove clamp from vehicle chassis, and then remove clamp
from battery terminal.
Using the Engine Start Function
1. Set up the battery charger and connect to the battery following steps 1 through 2 in the "Charging the
Battery" section.
2. Press the engine start button. The LCD screen will display the following*:
The digital display shows the countdown.* The battery charge gauge will indicate the battery's current
charge status. The engine start icon, clamp icons and battery icon light solid, and the bars on the battery
icon will change from empty to solid (bottom to top) repeatedly and the arrow icons will gradually and
repeatedly move downward to the battery icon.
*The countdown will commence from "90" to "0".
3. When "00" is reached, a beep will sound, engine start icon (
start.
4. Crank the engine using manufacturer's guidelines, typically in 3 to 5 second bursts. The digital display
shows "5 sec." indicating a 5-second countdown.
5. After cranking, the unit will automatically adjust the charging current to 2A for 5 minutes and then revert to
charging mode. To stop charging, press the charge button.
IMPORTANT: The function requires a resting/cooling period between attempts. Wait 4 to 5 minutes before a
second attempt at starting the engine, if needed.
When disconnecting charger, disconnect AC cord, remove clamp from vehicle chassis, and then remove clamp
from battery terminal.

TROUBLESHOOTING

Unit Not Charging
• Make sure all connections are secure.
• Check that the charger is properly connected to a live 120 volt AC outlet.
• If the battery to be charged has fallen below 2 volts, the battery cannot be recharged with these chargers.
CARE AND MAINTENANCE
Storage
• Store the unit in a clean, dry, cool place when not in use.
• Clean the unit casing and cords (as necessary) with a dry (or slightly damp) cloth. Ensure that unit is
completely disconnected from battery and power source before cleaning.
• To maintain the operating condition and maximize the life of the charger cords, always coil them loosely for
storage. Do not wrap them around the unit or crimp them with a tight band.
ACCESSORIES
Recommended accessories for use with this unit may be available from the manufacturer. If you need assistance
regarding accessories, please contact the manufacturer at 1-877-571-2391.
WARNING: The use of any accessory not recommended for use with this appliance could be hazardous.

SERVICE INFORMATION

Whether you need technical advice, repair, or genuine factory replacement parts, contact the manufacturer at
1-877-571-2391.
BC15_25_40BD_ManualENSP_010515.indd 12-13
) will begin flashing. The vehicle is ready to
12
ONE YEAR LIMITED WARRANTY
The manufacturer warrants this product against defects in materials and workmanship for a period of ONE (1)
YEAR from the date of retail purchase by the original end-user purchaser ("Warranty Period").
If there is a defect and a valid claim is received within the Warranty Period, the defective product can be
replaced or repaired in the following ways: (1) Return the product to the manufacturer for repair or replacement
at manufacturer's option. Proof of purchase may be required by manufacturer. (2) Return the product to the
retailer where product was purchased for an exchange (provided that the store is a participating retailer).
Returns to retailer should be made within the time period of the retailer's return policy for exchanges only
(usually 30 to 90 days after the sale). Proof of purchase may be required. Please check with the retailer for their
specific return policy regarding returns that are beyond the time set for exchanges.
This warranty does not apply to accessories, bulbs, fuses and batteries; defects resulting from normal wear and
tear, accidents; damages sustained during shipping; alterations; unauthorized use or repair; neglect, misuse,
abuse; and failure to follow instructions for care and maintenance for the product.
This warranty gives you, the original retail purchaser, specific legal rights and you may have other rights which
vary from state to state or province to province.
Please complete the Product Registration Card and return within 30 days from purchase of the product to:
Baccus Global LLC, 595 S. Federal Highway, Suite 210, Boca Raton, FL 33432. Baccus Global LLC, toll-free
number: 1-877-571-2391.

SPECIFICATIONS

BC15BD BC25BD
Input: 120VAC, 60Hz, 270W 120VAC, 60Hz, 450W
Output: 12VDC, 15A 12VDC, 25A
40A engine start 75A engine start
(ON: 5 seconds, OFF: 5 (ON: 5 seconds, OFF: 5
minutes) minutes)
Imported by Baccus Global LLC, 595 S. Federal Highway, Suite 210, Boca Raton, FL 33432
www.Baccusglobal.com 1-877-571-2391
BC40BD
120VAC, 60Hz, 740W
12VDC, 40A
110A engine start
(ON: 5 seconds, OFF: 5
minutes)
