- Page 1 User’s Manual: ABC-2 Series (SL) Revision 1.2 (August 23, 2005 Adjustable Bed Controller (ABC-2 Series) User’s Manual Elisync Technologies LLC.
-
Page 2: Revision 1.2 (August
User’s Manual: ABC-2 Series (SL) Revision 1.2 (August 23, 2005 LABELLING REQUIREMENTS (FCC Part 15.19 (a)(3)) This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operations. -
Page 3: Document History
User’s Manual: ABC-2 Series (SL) Revision 1.2 (August 23, 2005 DOCUMENT HISTORY REVISION DATE COMMENTS 2005.07.08 revision created 2005.07.12 UP/DOWN reversed 2005.08.23 FCC Information is added. Elisync Technologies LLC. -
Page 4: Table Of Contents
User’s Manual: ABC-2 Series (SL) Revision 1.2 (August 23, 2005 CONTENTS DOCUMENT HISTORY..................3 CONTENTS......................4 1. Introduction ....................5 1.1 Features ....................5 1.2 Systems Configuration................. 6 2. Hand Control....................7 2.1 Specification..................7 2.2 Photo...................... 7 2.3 Dimension....................8 3. -
Page 5: Introduction
1. Introduction 1.1 Features ABC-2 series adjustable bed controller is for adjust the bed to fit any position you like. With wireless hand control, you can raise your head and/or your feet to a position that most comfortable to you. -
Page 6: Systems Configuration
User’s Manual: ABC-2 Series (SL) Revision 1.2 (August 23, 2005 1.2 Systems Configuration Hand Control ABC-200HC-010 AC120V Max. 10M (30ft) PAIRING STATUS AC INPUT Adjustable Bed Controller Control Box ABC-200CB-010 HEAD FOOT BACK Actuator Actuator Massager Massager Elisync Technologies LLC. -
Page 7: Hand Control
User’s Manual: ABC-2 Series (SL) Revision 1.2 (August 23, 2005 2. Hand Control 2.1 Specification Item Specification Model ABC-200HC-010 Massage Mode: Manual / Wave Massage Function Massage Intensity: 5 steps Timer: 30min Radio Frequency 315MHz (FCC Part C 15.231) Radio Transmission Range Max. -
Page 8: Dimension
User’s Manual: ABC-2 Series (SL) Revision 1.2 (August 23, 2005 2.3 Dimension 64.7mm 22.0mm Elisync Technologies LLC. -
Page 9: Control Box
User’s Manual: ABC-2 Series (SL) Revision 1.2 (August 23, 2005 3. Control Box 3.1 Specification Item Specification Model ABC-200CB-010 2 Actuators: Head, Foot No. of Control Output 2 Massage Motors: Back, Leg Massage Mode: Manual / Wave Massage Function Massage Intensity: 5 steps... -
Page 10: Dimension
User’s Manual: ABC-2 Series (SL) Revision 1.2 (August 23, 2005 3.3 Dimension Elisync Technologies LLC. -10-... -
Page 11: Control Box - Details
User’s Manual: ABC-2 Series (SL) Revision 1.2 (August 23, 2005 4. Control Box - Details 4.1 Front View Layout 4.2 Rear View Layout 4.3 ACTUATOR Connectors PCB Header - MOLEX 5569-4pins, Right Angle/Dual Row Cable Receptacle - MOLEX 5557-4pins, Dual Row... -
Page 12: Massage Motor Connectors
User’s Manual: ABC-2 Series (SL) Revision 1.2 (August 23, 2005 4.4 MASSAGE MOTOR Connectors PCB Header - MOLEX 5569-4pins, Right Angle/Dual Row Cable Receptacle - MOLEX 5557-4pins, Dual Row PIN Assignment - Pin 1: MASSAGER - Pin 2: GND - Pin 3: NEUTRAL - Pin 4: N/C 4.5 AC INPUT Connector... -
Page 13: Status Led
User’s Manual: ABC-2 Series (SL) Revision 1.2 (August 23, 2005 4.7 STATUS LED GREEN LED - Power Status, Wireless Pairing Status 4.8 PAIRING Button For pairing between Hand Control and Control Box. 4.9 PCB Layout (Fuse, Header) Safety SWITCH Header... -
Page 14: System Setup Method
User’s Manual: ABC-2 Series (SL) Revision 1.2 (August 23, 2005 5. System Setup Method 5.1 Wireless PAIRING Setup 1) In control box, press and release the PAIRING button to go into pairing mode. The GREEN INDICATOR light will begin to flash in 0.2 second interval. -
Page 15: Hand Control Operation
User’s Manual: ABC-2 Series (SL) Revision 1.2 (August 23, 2005 6. Hand Control Operation 6.1 Bed Position HEAD UP/DOWN Button To raise the head of the bed, press and hold the HEAD- UP button. Release the button when you achieve the desired bed position. -
Page 16: Bed Position Save & Recall
User’s Manual: ABC-2 Series (SL) Revision 1.2 (August 23, 2005 6.2 Bed Position Save & Recall POS1 & POS2 Button (Position Recall) Press the POS1 button to recall the programmed bed position 1. The bed moves automatically until the head and foot position reached to the programmed Position 1 saved. -
Page 17: Massage Mode
User’s Manual: ABC-2 Series (SL) Revision 1.2 (August 23, 2005 6.3 Massage Mode WAVE Button Press the WAVE button to activate the ‘Wave Program 1’ with 30 minutes timer. Press the WAVE button 2 time to activate the ‘Wave Program 2’.
