NHD AS LS-300 User Manual

Multifunctional electric wheelchair
Hide thumbs Also See for LS-300:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Service Manual
User`s
Manual
LS - 300
Multifunctional Electric Wheelchair
Juni 2018
Revision Sheet

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LS-300 and is the answer not in the manual?

Questions and answers

Related Manuals for NHD AS LS-300

Summary of Contents for NHD AS LS-300

  • Page 1 User`s Manual LS - 300 Multifunctional Electric Wheelchair Juni 2018 Revision Sheet...
  • Page 2 Release No. Date Revision Description Rev. 1 15.06.18 Rev. 2 20.06.18 Guideline for transportation in a vehicle Feedback from Dahl Engineering – Mounting must be included Rev. 3 26.06.18 Page ii User`s Manual LS-300...

  • Page 3: Table Of Contents

    Disinfection ..................................29 Re-use of the wheelchair .............................. 29 Maintenance ............................. 30 Replacing the batteries ..............................30 Repair / maintenance plan ............................31 Transport ..............................32 Storage ..............................33 10. Disposal ..............................33 11. Manufacturer ............................. 34 Page iii User`s Manual LS-300...

  • Page 4: Preliminery Note

    1. Preliminery note Thank you for purchasing a LS-300 multifunction wheelchair. The LS-300 can be optimally adapted to your physical needs. All settings can be adjusted electronically, steplessly via the joystick. You can adjust seat height, seat angle, backrest angle, knee angle, armrest position, footplate position and leg length.

  • Page 5: Important Safety Instructions

    Only charge the battery in ventilated areas. Be sure to keep your arms and hands on the armrest during electrical adjustment of the wheelchair. Third parties should not touch the marked areas with their hands or fingers. Entrapment! Page 3 User`s Manual LS-300...

  • Page 6: Notes On Emc Interference

    • with severe limitations of cognitive abilities • with inability to sit Declaration of conformity NHD, as the manufacturer, declares on its sole responsibility that the LS-300 electric wheelchair complies with the requirements of Medical Directive 93/42 / EEC. Page 4...

  • Page 7: Product Overview

    Control device Charger Check the delivery Your LS-300 wheelchair is delivered ready for use, no further assembly is necessary. Please check if all listed elements are present. Identification label The identification label is located behind the right drive wheel, see Fig. Page 6.

  • Page 8: Overview

    This belt does not serve as a safety belt during car rides. To close, push the two belt parts into each other until they click into place. Open the clasp by pressing on "Press". Page 6 User`s Manual LS-300...

  • Page 9: Use Of The Wheelchair

    With a right or left movement of the joystick you can switch between the areas to be set. If you move the joystick forwards or backwards in this mode, you change the position of the illuminated areas. Page 7 User`s Manual LS-300...
  • Page 10 The following ranges can be infinitely adjusted via the control: - Backrest at an angle - seat angle - Length of legrests - Angle of legrests - Seat height Angle of legrest Lengths of legrest Seat angle Backrest Seat height Page 8 User`s Manual LS-300...
  • Page 11 Display of the areas to be set e.) Mode key to change the areas to be set f.) Display of the max. speed too adjustment of the driving profiles g.) Option key for determining the Speed in the driving profiles Page 9 User`s Manual LS-300...
  • Page 12 The power wheelchair can be set in a manual sliding mode. This function may only be set by a companion. The following step is necessary for this: Loosen the center handles on the brake release handles. ("Unlock" and "lock") Attention: The wheelchair has no braking function in sliding mode. Page 10 User`s Manual LS-300...
  • Page 13 Fold up the armrest and footplate. Now slip sideways onto the seat of the LS-300, making sure that you are as far back as possible in the seat. Now fold down the footrest and the armrest again.

  • Page 14: Guideline For Transportation In A Vehicle

    They realize. To unlock the wheelchair, follow the same procedure. Guideline for transportation in a vehicle The LS-300 complies with the requirements specified in ISO 7176-19:2008. It has been designed and tested according to the ISO 7176-19:2008, for transportation in a occupied position, forward facing in a vehicle.
  • Page 15 For more information, tie down kits for vehicles and or further information about tie-down belt and occupant 3-point safety belt, please visit the website of Dahl engineering at; WTORS.com Page 13 User`s Manual LS-300...
  • Page 16 (see picture below). Also the side angle should stay between the vertical plane to maximum of 15° angle with the vertical plane. (see picture below). Optimal angles for a safety belt used by the wheelchair user Page 14 User`s Manual LS-300...
  • Page 17 - belt restraints should be adjusted as tightly as possible, consistent with user comfort. - belt webbing should not be twisted when in use. Picture of improper belt fit Picture of proper belt fit Page 15 User`s Manual LS-300...
  • Page 18 The legrest should be in a knee angle close to 90 degrees. The headrest needs to be adjusted well so it will catch the head of the wheelchair user during the rebound of an impact, this to reduce the risk of a whiplash. Page 16 User`s Manual LS-300...
  • Page 19 Recommended position of the backrest, legrest and headrest Transportation using Dahl Docking station LS-300 has been crash tested using a Dahl docking station tie down system according to 7176-19:2008 and 10542-1:2012, where the wheelchair is facing forward in driving direction (driving direction like the driver seat).
  • Page 20 Dahl Engineering in Denmark for further details. You can find Dahl at; WTORS.com The Dahl Docking station Dahl Docking station Dahl docking station mounted on the floor Docking station and docking plate on chassis Page 18 User`s Manual LS-300...
  • Page 21 After that time, the bolt will lift up again and lock the Docking station. Make sure you drive your wheelchair out of the Docking station in this time window of the unlocked position. If not, you have to push the release button one more time. Page 19 User`s Manual LS-300...

  • Page 22: Mounting Of The Dahl Docking Adapter On The Wheelchair

    Dahl at; WTORS.com Mounting of the Dahl docking adapter on the wheelchair LS-300 chassis is equipped with a Dahl docking plate underneath the battery box frame of the chassis. LS-300 shassis with Dahl Docking plate mounted Page 20...
  • Page 23 For detailed information about the Dahl Docking system. please visit the homepage; WTORS.com To fit the Dahl docking plate, Dahl has created a special kit for LS-300 wich included the special Dahl nut plates and spacers for battery box of LS-300 to level the batteries. This kit is available under Dahl part no: 503341.
  • Page 24 6. Place the batteries back into the chassis and connect them tot he electronics. Now the LS-300 chassis is ready tob e docked into the Dahl Docking station. The mounting of the Dahl Docking station into your vehicle shall only be executed by a authorized car adaption company.

  • Page 25: Technical Specifications

    350 mm the seat measured: Length of the armrest: 420 mm Horizontal position of the rear axle 250 mm measured from the backrest: Weights Max. User load: 136 kg Total weight: 168 kg Headrest: 1,5 kg Page 23 User`s Manual LS-300...
  • Page 26 1150 mm Operating forces Joystick: ca. 1 N Button ca. 1 N Coupling and decoupling of the drives: 60 N Tires Tire pressure: 250 kPA Rear tires: 205 Ø mm Tires in front: 345 Ø mm Page 24 User`s Manual LS-300...
  • Page 27 If the wheelchair is not used for a long time, the charger should be connected every 6-8 weeks. A complete discharge of the batteries should be avoided. Charging should be done in a ventilated room, Avoid open fire while charging. During the charging process, the wheelchair can not be used. Page 25 User`s Manual LS-300...

  • Page 28: Charging

    Important: The charger may only be operated on permanently installed charging sockets. The charging plug may only be mounted and replaced by authorized specialist personnel. Important: The charger should only be used to charge batteries installed in wheelchairs. Page 26 User`s Manual LS-300...
  • Page 29 An overcharge of the battery can not occur. The charging time is as short as possible. The "CHARGING", "COMPLETED" and "ERROR" lamps on the front of the charger indicate the charging status. Page 27 User`s Manual LS-300...

  • Page 30: Examination Of The Wheelchair

    Unscrew the plastic caps, attach the connector of the pneumatic tool to the valve, and fill the tire until the prescribed air pressure (here 250 kPa) is reached. If the tires are damaged, the hoses can be repaired or replaced, please contact the authorized dealer. Page 28 User`s Manual LS-300...

  • Page 31: Cleaning And Disinfecting

    Re-use of the wheelchair The wheelchair is suitable for re-use. When passing on, care must be taken that the wheelchair is serviced by the specialized trade and is treated hygienically. (see section on cleaning and disinfection) Page 29 User`s Manual LS-300...

  • Page 32: Maintenance

    The battery is located under the seat. The seat must be raised until it stops by itself. The fabric cover can now be removed. First loosen the safety Velcro fasteners, then the power connections. Now the battery can be removed. Page 30 User`s Manual LS-300...

  • Page 33: Repair / Maintenance Plan

    Have your wheelchair checked and repaired by the dealer if necessary. The expected life of your wheelchair is 8 years. However, this depends on the frequency of use, care and the environment in which your wheelchair is used and stored. Page 31 User`s Manual LS-300...

  • Page 34: Transport

    If you want to transport the wheelchair empty, you can easily remove the headrest to save space. Loosen the lever screw and then pull the headrest out of the holder. To replace them, reverse the procedure and tighten the lever again. Page 32 User`s Manual LS-300...

  • Page 35: Storage

    If the electric wheelchair is to be disposed of, please contact your dealer. If you want to dispose of the wheelchair yourself, contact the responsible waste disposal companies and act according to the relevant regulations. Page 33 User`s Manual LS-300...

  • Page 36: Manufacturer

    11. Manufacturer NHD AS Gigstads vei 22, 3511 Honefoss, Norway www.nhd.as Mail: post@nhd.as Telefon: +47 99316100 At the manufacturer's address you will find information on product safety, new features, or product recalls. For questions about your wheelchair, the authorized dealer is at your disposal.
