QUICK REFERENCE GUIDE
1 2
3
4
ELECTRODES
(2 SETS)
LEAD WIRES
(2 SETS)
For more information about your Intensity™ 5000 Hybrid unit, visit us at currentsolutionsnow.com or call 1-800-871-7858.
The purpose of this guide is to assist you in correctly operating your Intensity™ 5000 Hybrid unit.
This device should only be used under the continued supervision of a licensed physician. This
guide is not intended to replace or substitute the Intensity™ 5000 Hybrid Instruction Manual.
PLEASE READ THE INSTRUCTION MANUAL COMPLETELY BEFORE USING THIS DEVICE. Read,
understand and practice the warnings, cautions and operating instructions. Always follow the
operating instructions prescribed by your healthcare provider.
15
Front
5
6
7
8
9
12
14
INTENSITY
5000 HYBRID
UNIT
CURRENT
Top
16
Back
17
10
11
13
18
1
Channel 1 Intensity output indicator
2
Channel 2 Intensity output indicator
3
Channel 1 intensity increase button
4
Channel 1 intensity decrease button
5
Channel 2 intensity increase button
6
Channel 2 intensity decrease button
7
Key-press cover
8
Therapy mode LED indicator
9
Therapy mode button
10
Therapy time button
TM
SOLUTIONS
A Roscoe Medical Company
PAGE 1
Side
19
11
Therapy time LED indicator
12
Pulse width button
13
Pulse rate button
14
On/Off button
15
Channel 1 output socket
16
Channel 2 output socket
17
Belt clip
18
Battery compartment cover
19
Adapter receptacle
