TeleSwivel 210 Owner's Manual

(C)
(F)
(F)
(D)
(G)
(B)
(A)
(B)
(E - standard)
A. Cassette
(H)
B. Clips
C. Stop Pins
D. Locking Pin Assembly
E. Probe Options
F. Bolt
G. Bushing
H. Lock Nut
Periodic cleaning and lubrication will enable you to enjoy your TeleSwivel
1. Remove the locking clips (ref A); the stop pins (ref B) will pull out from the top of the cassette.
(B)
2. Remove the probe (ref C) from the cassette.
3. Clean with soap and water, or a degreasing agent. You may find a pressure washer to be
helpful in cleaning out the inside of the cassette. Ensure probe and inside of cassette are dry.
4. Lubricate both sides of the probe with white lithium grease.
5. Place the probe back in the case. Replace the stop pins (insert them from the top of the case)
(A) and secure with locking clips.
6. Do not operate without stop pins securely in place.
NOTE for TS 210 AP and DH owners: You may re-insert the accessory probes
in the reverse position to provide an additional drop/rise capability.
(C)
If you need service or replacement parts, please contact us:
Web: teleswivel.com
E-mail: info@teleswivel.com
Phone: (919) 246-9249

Parts

(E - Accessory Plate)
(E - Drop Hitch)
(E - Drop Hitch ball mount)
Maintenance & Storage
for many years.
®
Service & Repair
Thank you for purchasing a
TeleSwivel 210 brand hitching system - the fastest, easiest, and safest
®
way to connect a trailer to a tow vehicle!
Your TeleSwivel is designed and built to the highest
®
standards to provide years of trouble-free towing.
TeleSwivel 210 TeleSwivel
® ®
Owner's Manual for
TeleSwivel
The TeleSwivel 210 units are all backed by a limited 2-year warranty. For full details about the
®
warranty please visit teleswivel.com or email info@teleswivel.com.
MAXIMUM GROSS TRAILER
WEIGHT: 10,000 LBS.
MAXIMUM TONGUE WEIGHT:
1,000 LBS.
DO NOT EXCEED THE CAPACITY OF THIS
HITCH OR THE VEHICLE TOW RATING AS
SPECIFIED IN YOUR VEHICLE OWNER'S
MANUAL
This tow-bar complies with the requirements of
the Federal Motor Carrier Safety Administration
Manufactured by TeleSwivel, LLC.
(919) 246-9249
210 DH TeleSwivel 210 AP
®
210 Series
®
FAILURE TO FOLLOW
OPERATING INSTRUCTIONS
COULD RESULT IN SERIOUS
INJURY OR DEATH
teleswivel.com
