Jegs 80040 Installation Instructions

Installation Instructions for 80040
Engine Stand
1000 lb. Capacity
Assembly
1. Install the 2 x 3-1/2" wheels (part 7) on the rear cross beam (part 4) and install 2 x 3" wheels (part 15) on the front
cross beam (part 16).
2. Attach the 4 mounting arms (part 19) to the turning plate (part 18) using the bolts and nuts provided (parts 6, 8, 20).
3. Assemble and fasten the front cross beam (part 16) and the middle beam (part 17) using the bolts and nuts provided
(parts 3, 13, 14).
4. Insert the middle beam (part 17) into the vertical column (part 1) using the bolt (part 10). Then attach the vertical
column (part 1) to the rear cross beam (part 4) using the bolts and nuts provided (part 3)
5. Put the turning plate (part 18) through the vertical column (part 1) and the handle (part 2) through the turning plate
hole and lock using the pin (part 9).
Product Specifications

Heavy duty steel channels

High strength steel construction

Engine stand capacity: 1000 lbs.

Rotation: 360°

Overall Size: 27.5" x 29.5" x 33"
Unpacking
When unpacking the tool:

Carefully remove the tool and accessories from the box.

Make sure that all items listed in the packing list are included.

Inspect the tool carefully to make sure no breakage or damage occurred during shipping.

Do not discard the packing material until you have carefully inspected and successfully operated the tool.
WARNING: When using the tool basic safety precautions should always be followed to reduce the risk of personal
injury and damage to equipment.
Instruction
This product has many features which make using it more pleasant and enjoyable. Safety, performance, and
dependability have been given top priority in the design of this product making it easy to maintain and operate.
WARNING:
Do not attempt to use this product until you thoroughly read and completely understand the operator's manual. Pay
close attention to the safety rules, including Dangers, Warnings, and Cautions. If you use your product properly and
only as intended, you will enjoy years of safe, reliable service.
WARNING:
The operation of any tool can result in foreign objects being thrown into your eyes, which can result in severe eye
damage. Before beginning operation, always wear safety goggles or safety glasses with side shields and a full face
shield when needed. We recommend Wide Vision Safety Mask for use over eyeglasses or standard safety glasses with
side shields. Always wear eye protection which is marked to comply with ANSI Z87.1.
General Safety Rules
WARNING: When using the tool basic safety precautions should always be followed to reduce the risk of personal
injury and damage to equipment!

Work area conditions. Cluttered areas invite Injuries.

Additional work area conditions. Do not use machines or power tools in damp or wet locations. Do not expose to
rain. Keep work area well lit.

Keep children away. Children must never be allowed the work area. Do not let them handle machines, tools or
extension cords.

Store idle equipment. When not in use tools must be stored in a dry location to inhibit rust. Always lock up tools
and keep them out of the reach of children.
1-800-345-4545 jegs.com
