- Page 1 USER’S MANUAL DIGIOHMpro V 1.2-EN...
-
Page 2: Table Of Contents
DIGIOHMpro 1. INTRODUCTION................2 1.1. Safety ..................2 1.2. General description of the instrument .......... 3 1.3. Standards applied ............... 4 1.4. Ecology ..................4 2. DESCRIPTION OF THE INSTRUMENT ......... 5 2.1. Instrument’s case ................ 5 2.2. Control panel and OLED display ..........6 2.3. -
Page 3: Introduction
DIGIOHMpro 1. INTRODUCTION 1.1. Safety Read this User’s Manual carefully and completely and follow all instructions contained therein. Otherwise using of the instrument may be dangerous for operator, for installation under test under test or for the instrument! Explanation of the symbols on the instruments: Protection class (double insulation). -
Page 4: General Description Of The Instrument
1.2. General description of the instrument The DIGIOHMpro is a compact instrument with patent-protected storage system of the test tips in the transport position – sharp tips are safely hidden. High contrast bright multicolour graphic OLED display ensures excellent legibility. -
Page 5: Standards Applied
DIGIOHMpro 1.3. Standards applied Measurements: EMC: Safety: EN 61557-4 EN 55022, class B EN 61010-1 EN 61326-1 EN 61010-2-031 EN 61000-4-2,3,4,5,6 1.4. Ecology Shipping case It is made of cardboard and is recyclable. Please hand it to a collection point of secondary raw materials in accordance with local regulations. -
Page 6: Description Of The Instrument
DIGIOHMpro 2. DESCRIPTION OF THE INSTRUMENT 2.1. Instrument’s case test tip on instrument’s case OLED display control panel instrument’s case sliding protective cover • Use original accessories only! • Max allowed voltage between test tip and ground is 300V! • Max allowed... -
Page 7: Control Panel And Oled Display
DIGIOHMpro screws securing the batteries / fuse information label the batteries / fuse compartment cover compartment cover Fig. 2.2. Detail of bottom side 2.2. Control panel and OLED display Graphical OLED display The START key. Hold it until the instrument is switched on. -
Page 8: Included In The Set
DIGIOHMpro 2.3. Included in the set DIGIOHMpro Twisted test lead with measuring tip Pouch User’s Manual Calibration Certificate Cardboard shipping case 2.4. Optional accessories P 5050 – adapter for charging accumulators P 5060 – set of 4 NiMH AAA accumulators P 2011 –... -
Page 9: Measurements
DIGIOHMpro 3. MEASUREMENTS 3.1. Turning the instrument on and off, standby, auto power off Hold the START key pressed until the device turns on. The instrument is turned off after two short pressing/releasing the START key. The instrument enters standby mode (reduced display brightness) after short time of inactivity (no key pressed, no voltage applied on the test tips). -
Page 10: Function R
DIGIOHMpro 3.3.2. Function R The “R“ function is for continuity (low resistance) measurement. Measurement: • Check that there is no external voltage applied on measured resistance (see chapter 3.3.1. - function U). • Press and release the U/R/●› key to select R function. Measured resistance value is displayed or "---- "... -
Page 11: Function "●›)" - Beeper
DIGIOHMpro Manual range selection • After entering the R function measuring range is chosen automatically. • If necessary, you can press and release the RANGE key to select a certain range, thus disable and eventually re-enable auto-ranging. Important notices for resistance measurement - Do not connect test tips to external voltage in the R function. -
Page 12: Phase Sequence Test
DIGIOHMpro Important notices for proper indication of phase - This function can only be used in TT and TN systems! - Hold the instrument in your hand (palm) in a standard way. - For correct function of phase indication it is necessary that the test tip is connected to the phase voltage for at least 2! - The voltage must be ≥... -
Page 13: Other Functions Of The Instrument
DIGIOHMpro • Connect one test tip to the designated common conductor. Then touch with the second test tip a conductor, then another conductor etc. DIGIOHMpro always displays the number of conductor corresponding to the numbered terminal of the DIGIsort on the opposite end. -
Page 14: Maintenance
DIGIOHMpro 4. MAINTENANCE 4.1. Batteries and fuse replacement Dangerous voltage in batteries / fuse compartment! Disconnect both test tips from tested object and turn off the instrument before removing the batteries / fuse compartment cover or before connecting jack to the socket for accumulator... -
Page 15: Charging Of Accumulators
DIGIOHMpro 4.1.2. Charging of accumulators For charging of accumulators use only adapter supplied as optional accessories! Accumulators are charged as soon as the adapter is connected to mains and to socket for accumulators charger (see Fig. 2.1). If accumulators are fully discharged, the charging takes about 6 hours (applies to batteries with a capacity of 800 mAh). -
Page 16: Cleaning
DIGIOHMpro For replacing the fuse unscrew two screws and remove the batteries / fuse compartment cover, see Fig. 2.2. Then remove blown fuse from the fuse holder (see Fig. 4.1) with a suitable tool (e.g. a small screwdriver) and put in its place the new fuse. -
Page 17: Technical Specification
DIGIOHMpro 5. TECHNICAL SPECIFICATION 5.1. Functions Continuity Operating range of use according to EN 61557-4: 0,028 ÷ 200 . Test current ≥ 200 mA at R ≤ 2 . Measuring Resolution ( ) Reference error Operating error range ( ) 0,000 ÷... -
Page 18: General Data
Firmware can also be updated during calibration and repair of the instrument. Updating the firmware can cause changes and / or additions to the device functions so we recommend checking the validity of the manual on www.illko.cz in relation to the firmware version.
