Summary of Contents for Spulen MK7
- Page 1 S P U L E N M K 7 / A 3 / S 3 T h r o t t l e P i p e 7716 Wiles Rd.Coral Springs, FL 33067 www.uspmotorsports.com...
- Page 2 Spulen MK7/A3/S3 Install instructions Throttle pipe 7716 Wiles Rd.Coral Springs, FL 33067 www.uspmotorsports.com...
- Page 3 Spulen MK7/A3/S3 Install instructions Throttle pipe Loosen the 7mm hose clamp at the throttle body. 7716 Wiles Rd.Coral Springs, FL 33067 www.uspmotorsports.com...
- Page 4 Spulen MK7/A3/S3 Install instructions Throttle pipe Remove the 8x T-25 screws securing the lower splash guard. 7716 Wiles Rd.Coral Springs, FL 33067 www.uspmotorsports.com...
- Page 5 Spulen MK7/A3/S3 Install instructions Throttle pipe Release the radiator hose from the factory throttle pipe (red arrow). Loosen the T-30 torx securing the pipe to the block (blue arrow). 7716 Wiles Rd.Coral Springs, FL 33067 www.uspmotorsports.com...
- Page 6 Spulen MK7/A3/S3 Install instructions Throttle pipe Remove the T-30 torx securing the factory pipe to the block (red arrow). Disconnect the MAP sensor (blue arrow). Loosen the 7mm hose clamp (green arrow). Remove the factory throttle pipe. 7716 Wiles Rd.Coral Springs, FL 33067...
- Page 7 Spulen MK7/A3/S3 Install instructions Throttle pipe Remove the 2x T-25 screws securing the MAP sensor. 7716 Wiles Rd.Coral Springs, FL 33067 www.uspmotorsports.com...
- Page 8 Spulen MK7/A3/S3 Install instructions Throttle pipe Install the MAP sensor into the new throttle pipe and secure with the included 5mm allen head bolts. Install the silicone coupler and loosely install the hose clamps on the pipe. 7716 Wiles Rd.Coral Springs, FL 33067...
- Page 9 Spulen MK7/A3/S3 Install instructions Throttle pipe Install the new throttle pipe onto the car. Insure proper clearance between radiator fans and tighten 8mm clamps at the throttle body. 7716 Wiles Rd.Coral Springs, FL 33067 www.uspmotorsports.com...
- Page 10 Spulen MK7/A3/S3 Install instructions Throttle pipe Reconnect the MAP sensor. Reconnect the intercooler hose that was disconnected in step 4. Reinstall the splash guard removed in step 2. 7716 Wiles Rd.Coral Springs, FL 33067 www.uspmotorsports.com...
