THE FEATURE ORIENTED PHONE SYSTEM

With exclusive Emergency Help System

you can Call-4-Help with a press of a button

before you decide to answer an incoming phone call*

Answer your phone and speak hands-free

even if you can't get to the phone**

USER MANUAL

Consumer Helpline

FOR EVERY HOME

Hear who is calling

CALL

REPEAT

BACK

VOICE

DELETE

GHI

PQRS

LOUD

LOW

HANDSET

LOUD

1-888-558-7420

ClearVoice 50 B™

ClearVoice 100 B™

ClearVoice 200 B™

CALL#

NEW

CLIP

SCROLL

ABC

DEF

CLIP

EXIT

JKL

MNO

FLASH

TUV

WXYZ

HOLD

REDIAL

SPEAKER

A Quality Of Life Product

Patents Pending

Table of Contents

Need help?

Do you have a question about the ClearVoice 50 B and is the answer not in the manual?

Questions and answers

Summary of Contents for Telemergency ClearVoice 50 B

Page 1 Hear who is calling before you decide to answer an incoming phone call* Answer your phone and speak hands-free even if you can’t get to the phone** USER MANUAL ClearVoice 50 B™ ClearVoice 100 B™ ClearVoice 200 B™ CALL CALL#...
Page 2: Table Of Contents
TABLE OF CONTENTS Important Safety Instructions ...........................2 Safety Instruction for Batteries ............................2 Installation Instructions ..............................2 Important Notes ................................3 FCC Wants You to Know............................3 Service ...................................4 General Information ..............................4 About Your Unit................................4 Location of Controls ..............................5 Installation …………………………………………………..……………………………………………….…… 6-7 Where to install this feature oriented telephone/ Installing batteries/ To replace the battery of the Remote . Pendant/ choose your location/Connecting the ClearVoice 50B,100B or 200B/ Wall mounting/ Special Highlight Features............……………………....
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following: 1. Do not use this product near water, for example, near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.
Page 4: Important Notes
IMPORTANT NOTES • The telephone portion of your dialer/message console has been tested and found to comply with all applicable UL and FCC standards. • This product is not a security system or an emergency service device. • The manufacturer makes no claim as to the suitability of this product to perform as a life-saving device.
Page 5: Service
….If in using the Speakerphone, user forgot to switch it off, after 30 minutes, the speakerphone will reset, allowing full use of your telephone. ….In an Emergency, if the telephone is off hook, when the Telemergency Emergency Help System is activated, the call will be terminated so that the Emergency System can proceed.
Page 6: Location Of Controls
*For use with the System 2 Pro total telephone system..This telephone allows for expansion which can allow you hands-free communication throughout your home as well as for Emergency Help System. For more information, call Telemergency™ customer service Tel. # 1-888-558-7420.
Page 7: Installation
INSTALLATION Where to install this feature-oriented telephone When installing this feature-oriented telephone, consider that the unit should be placed in an area of common use during the day and night time. ClearVoice 50B, 100B and 200B™ users should locate the phone within 10-15 feet line of sight from where user spends a lot of time.
Page 8 Choose your location Your ClearVoice 50B, 100B or 200B must be placed on a hard surface and connected to both the telephone wall jack and an 115V AC power source. Do not plug into a 115V AC power source that is controlled by a switch.
Page 9: Special Highlight Features
SPECIAL HIGHLIGHT FEATURES The Phone that will automatically hang up if accidently left in Speakerphone mode for a period of time. The Phone that will automatically advise you with a loud beeping alarm if accidently left OFF Hook The Phone that will activate the Emergency Help System if pendant is activated The Phone that can tell you who is calling The Phone that can answer a call remotely The Phone that can get you emergency help with a press of a button on accessory CV114 pendant...
Page 10: Using Features Of Your Telephone That Do Not Need Programming
USING FEATURES OF YOUR TELEPHONE THAT DO NOT NEED PROGRAMMING Notes: To program names and #s for the featured Phone Book and Emergency Help System as well as add’l programmed features proceed to section: SETTING UP TO USE THE PROGRAMMABLE FEATURES OF YOUR UNIT Before proceeding, move speaker phone control on side of unit to mid-position.
Page 11: Setting Up To Use The Programmable Features Of Your Telephone
Speaker Volume Control You can adjust the speaker volume for a more comfortable listening level by sliding the switch. This will also adjust the volume of the voice driven features as well as speakerphone levels when speaker button activated. It is suggested to maintain the volume at medium level Redial Note: To redial the last number called.
Page 12 # you wish to include in your phone book or a phone # or phone #s you would also want to call in an Emergency (for detailed information see section on Telemergency Emergency Help...
Page 13: The Phone Book
Storing up to 30 telephone numbers in the phone book including emergency nos. to be called in a n emergency. E ntering Emergency telephone numbers and names: (for Emergency Help System) Note: If you have a telephone system where it is may be required to put a pause (P) before dialing a particular digit press the REDIAL button and a 3.6 second pause will be created.
Page 14: The Phone Book
General Telephone nos. to be entered Name: Telephone# * Name: Telephone# ____________________ ________________ ____________________ _______________ ____________________ ________________ ____________________ _______________ ____________________ ________________ ____________________ _______________ ____________________ ________________ ____________________ _______________ ____________________ ________________ ____________________ _______________ ____________________ ________________ ____________________ _______________ ____________________ ________________ ____________________ _______________ ____________________ ________________ ____________________ _______________ ____________________ ________________ ____________________ _______________...
Page 15: The Phone Book
If you have already recorded a name associated with a phone #, press MENU button to go to next step or press Exit button. To change or record a voice name to a telephone # in the Phone Book.. 1. Press and release the Menu button until the Name Recording is shown on LCD display 2.
Page 16: The Phone Book
This telephone is able to write on the LCD and to give you a voice guide in two different languages. By selecting the language the user will automatically select both the voice and the written LCD language. 1. Press and release the MENU button until LANGUAGE is shown. 2.
Page 17: Using The Emergency Features
To Delete the Phone Book Memory (All telephone #s including Emergency #s and their location) 1. Press and release (Exit) button, icon is shown. CLIP 2. Select the required location from the phone book by scrolling buttons. 3. To delete single memory, press DELETE button once. The display will show the DELETE?. Press DELETE button for 2 seconds.
Page 18: The Phone Book
The phone book allows you to enter, display, record the persons name and specify if this a telephone no. that is to be called in the units Telemergency Emergency Help system. It is important to note that any telephone # entered that is less than 6 digits (including pauses area codes or any other digits will only be called 1 time if the emergency help system is activated.
Page 19 speakerphone button or if using the dual pendant . Press the red button on pendant for more than 8 seconds. LED will stop flashing and remain on for approximately 5 seconds. 5. If a called party presses 0 on their tone dialing telephone after hearing the emergency message, the emergency speakerphone feature will be activated allowing the called party to speak to the caller, and the caller can respond (if near or able) for up to 1 minute if near speakerphone of the ClearVoice 200B.
Page 20: The Caller Id
The telephone dials out the first of the entered emergency numbers (stored in the phone book emergency location1) in speakerphone mode, and then begins playing the emergency message. If during the period the emergency message is played (if available to the called party), called party can acknowledge the call by pressing 0, the telephone will be put in speakerphone operation for 1 minute.
Page 21 Receiving a Call (the telephone can store up to 64 calls) • If only the caller’s phone number is received, the display shows the caller’s phone number with the time and date it was received. The NEW icon turns on and NEW CALL LED turns on. Notes: 1.
Page 22: Important Revie / In Case Of Difficulty
Note: If the Caller ID number is 10 digits, press OK button once, the unit will insert “1” before the Caller ID number automatically. You can press button to select insert “1” or not. Press OK again, the speakerphone will turn on automatically and dial the display number. Copy from the Caller ID to the Phone Book You can copy Caller ID information to the phone book while you are reviewing the Caller ID information.
Page 23: Limited Ninety-Day Warranty
In the event of a product defect during the warranty period, contact Telemergency, Ltd. For a Returned Merchandise Authorization. Telemergency, Ltd. will, at its option, unless otherwise provided by law: (a) correct the defect by product repair without charge for parts and labor;...

This manual is also suitable for:

Clearvoice 100 b Clearvoice 200 b
