- Page 1 OPERATING MANUAL Mini Floor Crane MFC/K MFC/Ks Release: 1.4 14.Nov.2017...
-
Page 2: Table Of Contents
Contents Basic procedures General description MFC Series typ overview COMPONENTS MFC/Ks MFC/K SAFETY Safety instructions Pre-operation inspection Working area inspection Function tests Operating instructions INSTALLATIONS MFC/Ks MFC/K OPERATION Telescope and Hydraulic Cylinder Lateral outrigger Loading Transportation Technical data Declaration of conformity MFC Mini Floor Crane... -
Page 3: Basic Procedures
Basic Procedures Please read and comply with: The manufacturer‘s instructions and safety regulations. The operating and safety instructions for this crane. The inscriptions, labels and warning signs on this crane. The safety instructions and operating instructions at the job site. The current, local and legal safety regulations. -
Page 4: General Description
General Description Wienold Mini Floor Crane The MFC Installation is done as following: Der Mini Floor Crane consists of a chassis with crane construction and extendable Telescope. The height of the MFC/K: Chassis with 2 long outrigger aligned rearwarded, Telescope is determined by pumping on the hydraulic cylinder. -
Page 5: Mfc Series Typ Overview
2 long outrigger (aligned rearwarded) 2 Weight boxes with 14 weights each Option: 2 lateral outrigger With lateral outrigger: Standard: MFC750/K Outdoor Long version with outdoor wheels 2 long outrigger (aligned rearwarded) 2 Weight boxes with 14 weights each Option: 2 lateral outrigger... - Page 6 MFC Mini Floor Crane Operating Manual Components MFC750/Ks (Shorty) Standard: Without Lateral Outrigger 1) Carry handle 8) Hydraulic cylinder 16) Fixation / Drillings for long outrigger 2) Locking screw telescope 9) Additional Hydraulic cylinder 17) Counterweights and Boxes 3) Adapter hydraulic cylinder 10) Adapter main arm 18) Steering bracket 4) Telescope arm...
- Page 7 Components MFC750/Ks (Shorty) With Optional Lateral Outrigger 1) Carry handle 8) Hydraulic cylinder 16) Fixation / Drillings for long outrigger 2) Locking screw telescope 9) Additional Hydraulic cylinder 17) Counterweights and Boxes 3) Adapter hydraulic cylinder 10) Adapter Main arm 18) Steering bracket 4) Telescope arm 11) Transport drillings...
-
Page 8: Mfc/K
MFC Mini Floor Crane Operating Manual Components MFC750/K Standard: Without Lateral Outrigger 1) Carry handle 8) Hydraulic cylinder 16) Fixation / Drillings for long outrigger 2) Locking screw telescope 9) Additional Hydraulic cylinder 17) Counterweights and Boxes 10) Adapter Main arm... - Page 9 MFC Mini Floor Crane Operating Manual Components MFC750/K With Outdoor Wheels And Lateral Outrigger 1) Carry handle 8) Hydraulic cylinder 16) Fixation / Drillings for long outrigger 2) Locking screw telescope 9) Additional Hydraulic cylinder 17) Counterweights and Boxes 10) Adapter Main arm...
-
Page 10: Safety Instructions
MFC Mini Floor Crane Operating Manual Safety Instructions Non compliance with the instructions and safety rules in this operating manual may result in serious injury or accidents including death! Do Not Operate Unless: The personnel have been trained on this type of unit and are deemed competent. - Page 11 MFC Mini Floor Crane Operating Manual Safety Instructions Wear Appropriate Personal Protective Equipment (PPE) Prior to use, check the working area for steep slopes and Always wear PPE before operating the unit including: drop-offs, holes and debris. Also check for instable, slippery or icy surfaces and other possible sources of danger.
- Page 12 MFC Mini Floor Crane Operating Manual Safety Instructions Electrocution Hazards - Danger to Life The MFC is not electrically insulated and will not provide Do not lean any ladders or scaffolding against the crane or protection from contact with or proximity to electrical the load.
- Page 13 MFC Mini Floor Crane Operating Manual Safety Instructions Collision Hazards Crushing Hazards Check the working area for overhead obstructions or other Do not raise if the load is not potential sources of danger. 1. fixed 2. centred 2. secured. Never stand under the load as it is being raised or lowered or suspended.
- Page 14 MFC Mini Floor Crane Operating Manual Safety Instructions Damaged Crane Hazards Legend - Warning Signs Wienold lifts, appliances & machines use symbols, Do not operate a damaged or malfunctioning lift. colour codes and signal words to identify the following: Do not use the MFC with a worn, leaking, oil-lubricated or bent cylinder.
-
Page 15: Pre-Operation Inspection
MFC Mini Floor Crane Operating Manual Pre-operation Inspection Non compliance with the instructions and safety rules in this operating manual may result in serious injury or accidents including death! Do Not Operate Unless: Fundamentals: The personnel have been trained on this type of The pre-operation inspection is a visual inspection which unit and are deemed competent. - Page 16 MFC Mini Floor Crane Operating Manual Pre-operation Inspection Please ensure Check the entire lift and loading that the operating manual is complete, legible and placed devices for: in the storage container, installed on the unit. Bents and damage Please ensure Corrosion and rust that all warning signs and labels are both legible and Cracks in welds and structural components...
-
Page 17: Working Area Inspection
MFC Mini Floor Crane Operating Manual Working Area Inspection Non compliance with the instructions and safety rules in this operating manual may result in serious injury or accidents including death! Do Not Operate Unless: Fundamentals The personnel have been trained on this type of unit The working area inspection helps the operator to determine and are deemed competent. -
Page 18: Function Tests
MFC Mini Floor Crane Operating Manual Function Tests Non compliance with the instructions and safety rules in this operating manual may result in serious injury or accidents including death! Do Not Operate Unless: Fundamentals The personnel have been trained on this type of unit The function tests are designed to identify malfunctions and are deemed competent. - Page 19 MFC Mini Floor Crane Operating Manual Function Tests Hydraulic Cylinder 4. In the unlikely event of a leak in the hydraulic system, the 1. Remove the pump lever for the hydraulic cylinder safety locking pin must be installed at any time when the from the bracket on the Main arm a).
-
Page 20: Operating Instructions
MFC Mini Floor Crane Operating Manual Operating Instructions Fundamentals Do Not Operate Unless: Using the MFC for anything other than lifting loads is The personnel have been trained on this type of unit unsafe. and are deemed competent. All operators should read the operating manual carefully. -
Page 21: Mfc/Ks
MFC Mini Floor Crane Operating Manual Installation MFC750/Ks Setup Set up the MFC on firm and level ground only. Ensure that all safety brakes on the chassis are engaged during set up. 1. Locking the Brakes: 2. Installation of the first Box: 3. -
Page 22: Mfc/K
MFC Mini Floor Crane Operating Manual Installation MFC750/K Outrigger Set Up Set up the MFC on firm and level ground only. Ensure that all safety brakes on the chassis are engaged during set up. 3. Securing the Outrigger: 1. Locking the Brakes: 2. - Page 23 MFC Mini Floor Crane Operating Manual Installation MFC750/K Setup Set up the MFC on firm and level ground only. Ensure that all safety brakes on the chassis are engaged during set up. 3. Mounting the Steering Bracket: 1. Locking the Brakes: 2.
-
Page 24: Telescope And Hydraulic Cylinder
MFC Mini Floor Crane Operating Manual Operating MFC750 All Types Using Pump Lever. Adjusting Telescope Extension. Set up the MFC on firm and level ground only. Ensure that all safety brakes on the chassis are engaged during set up. 3. Adjusting Telescope: 1. - Page 25 MFC Mini Floor Crane Operating Manual Operation MFC750 All Types Loading. Lowering. Raising. Set up the MFC on firm and level ground only. Ensure that all safety brakes on the chassis are engaged during set up. 1. Loading: 3. Raising Telescope: ATTENTION: Make sure that the spring hook of the crane hook is completely closed after the...
-
Page 26: Lateral Outrigger
MFC Mini Floor Crane Operating Manual MFC750 with lateral Outrigger Installing lateral Outrigger. Set up the MFC on firm and level ground only. Ensure that all safety brakes on the chassis are engaged during set up. 1. Lateral Outrigger in transport position: 2. -
Page 27: Loading
MFC Mini Floor Crane Operating Manual Load Positioning and aligning Casters. Note: More Telescope expansion is reducing the Loading capacity. Only load the MFC when brakes are locked. Align the loaded Crane Position the load correctly on the loading device being used. Ensure that the load is adequately secured! Incorrectly positioned and/or incorrectly secured loads may lead to accidents that result Moving the crane with raised load is restricted to the positioning... -
Page 28: Transportation
MFC Mini Floor Crane Operating Manual Loading And Transportation Basic Procedures.. Before loading, familiarise yourself with the requirements for the loading methods as well as for the vehicles/trailers for lift transportation. Read and obey the respective conditions. Lifting Equipment: Transport Vehicle/Trailer: ATTENTION: 1. - Page 29 MFC Mini Floor Crane Operating Manual Loading And Transportation Basic Procedures.. Before loading, familiarise yourself with the requirements for the loading methods as well as for the vehicles/trailers for lift transportation. Read and obey the respective conditions. Transport Vehicle/Trailer: 2. Crane: Unload: 1.
-
Page 30: Technical Data
MFC Mini Floor Crane Operating Manual Technical Data Mini Floor Crane MFC/K MFC/K RT* MFC/Ks MFC/Ks RT* 2,90 m Lifting Height: 2,90 m 2,90 m 2,90 m Tansport Position: Height: 1,00 m 1,00 m 1,00 m 1,00 m Length : 1,26 m 1,20 m 1,26 m... -
Page 31: Declaration Of Conformity
EC Declaration Of Conformity MFC Mini Floor Crane... - Page 32 Norbert Wienold GmbH Industriegebiet Waldstr. 35a 48488 Emsbüren Germany Tel. +49 59 03 - 93 94 0 Fax +49 59 03 - 93 94 50 www.wienold-lifte.de e-mail: info@wienold-lifte.de Service Stations: München, Frankfurt, Leverkusen, Walsrode, Brandenburg, Emsbüren...
