PORTABLE SOLAR GENERATOR
Universal Instruction manual
ATTENTION: This product user manual is universal for portable solar generator AC output range
between 100V~240V/50Hz~60Hz. Actual product specification, actual AC outlets will be different
according to different countries, areas or customers. Please refer to the actual
product before you use the product.
Advertisement
Table of Contents
Summary of Contents for HuaYao S650
- Page 1 PORTABLE SOLAR GENERATOR Universal Instruction manual ATTENTION: This product user manual is universal for portable solar generator AC output range between 100V~240V/50Hz~60Hz. Actual product specification, actual AC outlets will be different according to different countries, areas or customers. Please refer to the actual product before you use the product.
-
Page 2: About The Unit
ABOUT THE UNIT Thank you for applying our multi-function portable solar generator. In case of power failure or you need to charge on a travel, you can temporarily charge your electrical or digital devices with this unit. This unit can provide USB, DC and AC output. - Page 3 【 I 】PRODUCT PARAMETERS Capacity 360Wh/97200mAh,3.7V 444Wh/120000mAh,3.7V Dimensions(LWH) 307x134x184mm Weight about 4.8Kg about 5Kg Built-in Battery High Quality Lithium Polymer Batteries Input Recharging 13~22V, Up to 6.2A Max input charge Fully Charged Time DC 15V/6A: about 6 hours DC 15V/6A: about 7 hours 3xUSB 5V-2.1A(Max);...
-
Page 4: Product Description
【 II 】PRODUCT DESCRIPTION 【Front】 Handle Battery Capacity Check USB Output AC Power ON/OFF 【Right】 Universal Outlets US AC Outlets 5.5mm 5.5mm DC Output DC Output USB Output USB Output 5.5mm DC Input 5.5mm DC Input Charging port Charging port 【Left 】... -
Page 5: Product Instruction
【III】PRODUCT INSTRUCTION 1) How to provide power for DC12V appliances(such as head lamp, fan) with this product? The 5.5mm 12V DC output is plug and play. Plug your appliances to the DC output port to gain power. Notices: Please confirm whether your DC12V appliance support charging with 5.5mm DC header interface (The diameter of the DC Port of the Product is: 5.5mm),otherwise it is unable to connect with the DC output, you can consult the electrical manufacturer, buy the corresponding adapter and connect with it. - Page 6 ※Note: The 12V DC output voltage is range between 9V~12.6V, maximum output current is 15A. DC output voltage drops while battery capacity drops due to chemical characteristics of the battery. If your appliance is not built-in input voltage stabilizing function, it may shutdown when input voltage is too low, please unplug your device from the unit in time.
- Page 7 3) How to provide power for USB digital appliances with this product? Connect the standard USB cable of digital appliance to the USB output of the unit to gain power. USB output is plug and play. But if the unit fail to supply power to the USB appliances automatically, press the “Batt.Check /USB Out”...
- Page 8 1. Place your solar panel where it will get as much direct sunlight as possible. 2. Plug the output of the solar panel into the input of the unit to start charging. You will know the unit is charging when the blue LED Battery Indicator lights up and blinks. The unit is fully charged when all battery indicators stop blinking and remain solid.
- Page 9 【 Front 】 The Battery indicators indicate the charge level of the unit. There are 5 indicators to the battery, approximating 20% - 40% - 60% - 80%-100% capacity. As you use the unit, indicators will be on, indicating the remaining capacity. When charging the unit you will notice a battery indicator blinking at about 1 second interval.
-
Page 10: Battery Information
k) Disconnect the unit when fully charged. l) Use the unit properly to avoid electronic shock. m) Please deal with scrap products in accordance with the regulations, do not treat the built-in battery as a household garbage, so as not to cause the explosion and pollution. n) The product is only used for emergency situations, it cannot replace the standard DC or AC power of household appliances or digital products. - Page 11 The battery can be charged and discharged over 500 times, but it will eventually wear out. Statement All rights reserved. Reproduction in whole or in part without written permission is prohibited. All other trademarks are trademarks of their respective owners. Features and specifications are subject to change without notice.
