ONKYO RS232 CONTROL SYSTEM
For DTR-5.2
Version 1.00
Updated Jun.30, 2000

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RS232 CONTROL SYSTEM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Onkyo RS232 CONTROL SYSTEM

  • Page 1 ONKYO RS232 CONTROL SYSTEM For DTR-5.2 Version 1.00 Updated Jun.30, 2000...

  • Page 2: Table Of Contents

    CONTROL INTERFACE OVERVIEW ........3 1.1.Hardware Overview...........3 1.2.Message Overview..........3 Receive Message Format ........3 Send Message Format ...........3 Special Character ..........3 2.1.Command Communication........4 2.2.Question Communication........4 2.3.Event Notice Communication........4 3.COMMAND DESCRIPTIONS ...........5 3.1.System Power Command "PWR"........5 3.2.Audio Muting Command "AMT"........5 3.3.Speaker A/B Command "SPA"/’’SPB’’ ......5 3.4.Master Volume Command "MVL".........5 3.5.Input Selector Command "SLI"........6 3.6.Listening Mode Command "LMD"........7...

  • Page 3: Control Interface Overview

    1. CONTROL INTERFACE OVERVIEW The manual for the DTR-5.2 should also be used with this document to understand how this protocol can be used the DTR-5.2. 1.1.Hardware Overview ･ 3 wire RS-232C protocol ･ 9 pin female D type connector pin 2 = transmit, pin 3 = receive, pin 5 = signal ground ･...

  • Page 4: Command Communication

    2.COMMUNICATION FLOW DESCRIPTION The DTR-5.2 uses Question, Command and Notification messages to have to communicate with a given HOST. This protocol is designed for point to point communication between a HOST and the DTR-5.2. 2.1.Command Communication Send a "Command Message" to the DTR-5.2 from the HOST to change the system status. The DTR-5.2 will respond with a status message within 50msec.

  • Page 5: Command Descriptions

    3.COMMAND DESCRIPTIONS 3.1.System Power Command "PWR" Commands to set or get the system-power status. Parameter List (Characters/Means) : "00" sets System Standby "01" sets System On "QSTN" gets the System Power State 3.2.Audio Muting Command "AMT" Commands to set or get the audio-muting status. Parameter List (Characters/Means) : "00"...

  • Page 6: Input Selector Command "Sli

    3.5.Input Selector Command "SLI" Commands to set or get the Input selector status. Parameter List (Characters/Means) : "00" sets VIDEO1 "01" sets VIDEO2 "02" sets VIDEO3 "10" sets DVD "20" sets TAPE1 "22" sets PHONO "23" sets CD "24" sets FM "25"...

  • Page 7: Listening Mode Command "Lmd

    3.6.Listening Mode Command "LMD" Commands to set or get the listening mode status. Parameter List (Characters/Means) : "00" sets STEREO "01" sets DIRECT "02" sets SURROUND "08" sets ORCHESTRA "09" sets UNPLUGGED "0A" sets STUDIO-MIX "0B" sets TV LOGIC "0C" sets ALL CH STEREO "UP"...

  • Page 8: Tuning Command "Tun

    3.9.Tuning Command "TUN" Commands to set or get the tuner frequency status. Parameter List (Characters/Means) : "nnnnn" sets Directly Tuning Frequency (FM nnn.nn MHz / AM nnnnn kHz) "UP" sets Tuning Frequency Wrap-Around Up "DOWN" sets Tuning Frequency Wrap-Around Down "QSTN"...

  • Page 9: Display Mode Command "Dif

    3.11.Display Mode Command "DIF" Commands to set the display mode. Parameter List (Characters/Means) : "00" sets Selector + Volume Display Mode "01" sets Selector + Listening Mode Display Mode "UP" sets Display Mode Wrap-Around Up "QSTN" gets The Display Mode 3.12.Dimmer Level Command "DIM"...

  • Page 10: Cd Player Operation Command "Ccd

    3.14.CD Player Operation Command “CCD” Commands to operate ONKYO CD players via the ONKYO RI System. Parameter List (Characters/Means) : "POWER" POWER ON/OFF "TRACK" TRACK+ "PLAY" PLAY "STOP" STOP "PAUSE" PAUSE "SKIP.F" >>I "SKIP.R" I<< "MEMORY" MEMORY "CLEAR" CLEAR "REPEAT"...

  • Page 11: Tape1(A) Operation Command "Ct1

    "DISC4" DISC4 "DISC5" DISC5 "DISC6" DISC6 3.15.TAPE1(A) Operation Command "CT1" Commands to operate ONKYO TAPE decks via the ONKYO RI System. Parameter List (Characters/Means) : "PLAY.F" PLAY > "PLAY.R" PLAY < "STOP" STOP "RC/PAU" REC/PAUSE "FF" FF >> "REW" REW <<...

  • Page 12: Dat Recorder Operation Command "Cdt

    3.18.DAT Recorder Operation Command "CDT" Commands to operate ONKYO DAT recorders via the ONKYO RI System. Parameter List (Characters/Means) : "PLAY" PLAY "RC/PAU" REC/PAUSE "STOP" STOP "SKIP.F" >>I "SKIP.R" I<< "FF" FF >> "REW" REW << 3.19.DVD Player Operation Command "CDV"...
  • Page 13 "ENTER" ENTER "RETURN" RETURN "DISC.F" DISC + "DISC.R" DISC - "AUDIO" AUDIO "RANDOM" RANDOM "OP/CL" OPEN/CLOSE "ANGLE" ANGLE "1" "2" "3" "4" "5" "6" "7" "8" "9" "10" "0" "SEARCH" SEARCH "DISP" DISPLAY "REPEAT" REPEAT "MEMORY" MEMORY "CLEAR" CLEAR...

  • Page 14: Md Recorder Operation Command "Cmd

    3.20.MD Recorder Operation Command "CMD" Commands to operate ONKYO MD recorders via the ONKYO RI System. Parameter List (Characters/Means) : "POWER" POWER ON/OFF "PLAY" PLAY "STOP" STOP "FF" FF >> "REW" REW << "P.MODE" PLAY MODE "SKIP.F" >>I "SKIP.R" I<<...

  • Page 15: Cd-R Recorder Operation Command "Ccr

    3.21.CD-R Recorder Operation Command "CCR" Commands to operate ONKYO CD-R recorders via the ONKYO RI System. Parameter List (Characters/Means) : "POWER" POWER ON/OFF "P.MODE" PLAY MODE "PLAY" PLAY "STOP" STOP "SKIP.F" >>I "SKIP.R" I<< "PAUSE" PAUSE "REC" "CLEAR" CLEAR "REPEAT"...
