Instruction Manual
P/N 30-3431 & 30-3434 AEMnet Adapter Harness
Installation for Series 2 EMS 30-6040 & 30-6300
AEMnet
AEMnet is an open architecture software and hardware interface based on the CAN 2.0 specification,
which provides the ability for multiple AEMnet enabled devices to easily communicate with each other
through a single cable. The hardware connection is made through a Deutsch 4P DTM connector.
Devices connected to the AEMnet transmit data through this one connection. Once the AEMnet
adapter is installed, the Series 2 EMS will be able to send and receive data on the AEMnet.
Instructions for configuring the Series 2 EMS to output data are included in this manual. Instructions
on configuring the Series 2 EMS to receive data from other AEMnet enabled products are contained
in the individual product manuals. Upon completion of these instructions, the Series 2 EMS will be
configured to output data to an AQ1 Data Logger or other data receiving device.
The following AEM products are currently AEMnet enabled:
Series 2 Engine Management System
EMS-4 Universal Standalone Engine Management System
4-Channel Wideband UEGO Controller
AQ-1 Data Logger
Dyno Shaft On-Vehicle Dynamometer
AEM Performance Electronics
th
2205 W 126
Street Unit A, Hawthorne, CA 90250
Phone: (310) 484-2322 Fax: (310) 484-0152
http://www.aemelectronics.com/
Instruction Part Number: 10-3431 Rev 1
 2011 AEM Performance Electronics, Inc.
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 30-3431 and is the answer not in the manual?

Questions and answers

Summary of Contents for AEM Performance Electronics 30-3431

  • Page 1 Instruction Manual P/N 30-3431 & 30-3434 AEMnet Adapter Harness Installation for Series 2 EMS 30-6040 & 30-6300 AEMnet AEMnet is an open architecture software and hardware interface based on the CAN 2.0 specification, which provides the ability for multiple AEMnet enabled devices to easily communicate with each other through a single cable.
  • Page 2 AEMnet CONNECTORS The AEMnet has four wires, two are for communication (white pin 1 and green pin 2) and two are for powering (red pin 3 and black pin 4) certain AEMnet devices. Only the two communication wires (white pin 1 and green pin 2) are needed for the Series 2 EMS to send/receive data as the EMS is not powered by AEMnet.
  • Page 3 REMOVE EXISTING WIRES FROM ECU PLUG(S) 1. Locate a small screwdriver (a precision 1.5mm wide flathead screwdriver is recommended) and carefully pry white plastic retainer using both slots in the retainer so it disengages vertically about 1mm as shown in figures 2 and 3 (please note: some connectors may have a lock opposite to the wires in between the pins, these can be removed simply using a pair of needle nose pliers): Figure 2: Pry in these areas...
  • Page 4 2. Next remove the pin from the plastic connector by lightly prying on the plastic tabs that secure the pin in the plastic connector while gently pulling on the wire at the same time as shown in figures 4 and 5. Figure 4: Pry this tab up with the screwdriver or paper clip to release pin Figure 5: While prying tab, gently pull wire back Page 4...
  • Page 5 EMS. CAN1L (Green wire) CAN1H (White wire) Adapter p/n LOCATION LOCATION 30-3431 30-6040 30-3434 30-6300 Table 2: CAN1L and CAN1H pin locations Figures 7 and 8 below show the connectors for each Series 2 EMS. Figure 7: Wire-side view of pinout for 6040 EMS...
  • Page 6 5. To install the harness into the ECU plug, align the CANL and CANH pins into the receptacle of the plug and push in until it clicks as shown in figure 9: Figure 9: Pushing pin into ECU plug 6. Push the pin lock back into place until it is flush with the ECU plug as shown in figure 10: Figure 10: Ensure pin lock is relocked Page 6...
  • Page 7 CONFIGURING THE SERIES 2 EMS The AEMnet data stream is compatible with version AEM25 01v23 firmware and later. To activate the AEMnet data stream, open AEMTuner and go to Wizards > Setup Wizard and select the AEMnet Data Stream. See figure 11 below. Figure 11: Selecting the AEMnet Datastream With the AEMnet enabled, the Series 2 EMS broadcasts information as shown below in figure Figure 12: AEMnet Data...
  • Page 8 Electronics tech line at 1-800-423-0046 to discuss the problem. Most issues can be resolved over the phone. Under no circumstances should a system be returned or a RGA requested before the above process transpires. Need additional help? Contact the AEM Performance Electronics tech department at 1-800-423-0046 or tech@aempower.com, or visit the AEM Performance Electronics forum at http://forum.aempower.com/forum/...
