Reporter
User manual
English
4K
Ultra HD
4k 15fps / 1080p 60fps
Wifi Function
Wide angle
Touchscreen
resolution: 14m
720p 120fps
Thank you for choosing a PNJ product. This manual describes how to prepare and use your product. It's also providing information about the utilization and safety
precautions, the regulations, compliance and technical specifications of the device. Please read completely, carefully and regularly before use, become familiar with
all the feature of the device and ensure safety use of your camera to enjoy fully with it. Keep this manual for future use. The manual is also available on our website
1
www.pnj.fr under the heading «User manuals».
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for PNJ Reporter
Summary of Contents for PNJ Reporter
- Page 1 720p 120fps Thank you for choosing a PNJ product. This manual describes how to prepare and use your product. It’s also providing information about the utilization and safety precautions, the regulations, compliance and technical specifications of the device. Please read completely, carefully and regularly before use, become familiar with all the feature of the device and ensure safety use of your camera to enjoy fully with it.
-
Page 2: Table Of Contents
CONTENTS 1 ATTENTION / WARNING / WAARSCHUWING ..................3 2.Battery ..............................4 3.Precaution of use ........................... 6 4.Warning ..............................7 5.Download the App ..........................8 6.Included in the pack ..........................9 7.Camera parts name ..........................10 8.Specifications ............................13 9.Remote control .............................14 Remplace the remote control's battery .................. - Page 3 11.Camera operation ..........................18 Turn on/ off the camera ........................18 General configuration ........................18 Effects configuration ........................20 Changing the modes of the camera ....................21 Record videos ..........................21 Video settings ..........................21 Take photos ............................23 Photo settings ..........................23 Playback ............................24 Using the external microphone (Optional) ..................24 Transferring camera's files on a PC ....................
-
Page 4: Attention / Warning / Waarschuwing
WARNING : Batteries are dangerous, please follow the instructions to avoid injuries or damages Lees de instructies in de bedieningshandleiding zorgvuldig door voordat u onze producten gebruikt De bedieningshandeleiding kunt u downloaden vanaf onze website: www.pnj.fr/en/user-manuals/ WAARSCHUWING : Baterijen zijn gevarlijk, het niet opvolgen van de gebruikshandekeiding kan... -
Page 5: Battery
2.BATTERY - By owning, charging or using the Li-battery, you assume all risks associated with the use of lithium batteries. - Always keep out of reach of children. - Never leave the battery unattended while charging. - Never leave the battery charged for more than 1 hour. - Use only the USB charger provided in the pack. - Page 6 - Improper use of the battery may cause fire, explosion or other hazards. - In case of fire caused by the battery, do not use water to extinguish the fire (sand is recommended). - Do not carry unwrapped batteries in your pocket or bag, as the shock of the batteries against each other could cause a short circuit.
-
Page 7: Precaution Of Use
- Avoid contact with sand, dust, water, liquid substances or heat, it could cause irreversible damage. - Not suitable for people with epilepsy. - Observe the safety instructions in this manual. - Use only the accessories supplied by PNJ. - Before each utilization, check that the batteries are fully charged. -
Page 8: Warning
PNJ assumes no responsibility in case of damage resulting directly or indirectly from the use of this device, any parts of this device or the manual. PNJ is not responsible for any accident, injury, death, loss or other claim of any kind related or resulting the use of this product. -
Page 9: Download The App
5.DOWNLOAD THE APP Scan the QR code below, to have the access to our website www.pnj.fr and download the application for free. You can also search ''Reporter App'' in Google Play Store or Apple Store to download the application for being able to control... -
Page 10: Included In The Pack
6.INCLUDED IN THE PACK Waterproof case Protective Clip Remote control Helmet Mount cover Quick release Lock bolt Spanner USb Cable mount... -
Page 11: Camera Parts Name
7.CAMERA PARTS NAME 1. Power/Navigatation 6. Internal Mic 2. Mode/Shutter 7. LCD Touch Screen 8. Speaker 3. Micro SD card Slot 4. Mini USB Port 5. HD Port 9. Li-ion Battery Power 10. 1/4" screw hole... - Page 12 Power/Navigation Mode/Shutter...
-
Page 14: Specifications
8.SPECIFICATIONS Video 4K 15fps / 2.5K 30fps / 1080P 60fps / 720P 120fps resolution Photo resolution LCD screen Touchscreen 2”TFT Battery Lithium-ion battery 1100mAh WI-FI Wifi connection up to20m Custom Android & iOS application Remote Wireless remote control 2.4 G RF controller SD card Up to 32GB... -
Page 15: Remote Control
Charging Fast Waterproof Up to 30m under water case 9.REMOTE CONTROL • Remplace the remote control's battery When the battery in the remote is close to being fully discharged the red LED indicator will flicker once per second indicating that you need to replace the button battery. 1. -
Page 16: Remote Controller
- Press any key of the remote, the camera and the remote will begin the pairing process automatically, the LED indicator will blink blue before being successfully paired. After pairing, the Reporter action camera will show: “Bluetooth Pair Succeed” and the LED indicator of the remote will light blue. -
Page 17: Camera Configuration
Waterproof camera - The Reporter can be use under water with it waterproof case. Please close it carefully to avoid any damage on the camera. Clean the case before each use, make sure there are no sand, dust, hair or... -
Page 18: Inserting The Memory Card
2. There is only one correct direction to insert the SD Card into the slot. Do not force the card into the card slot as it may damage both the SD Card and camera. 3. A new Micro SD Card should be formatted before using. 4. The Reporter can be mounted using the accessories provided. -
Page 19: Camera Operation
11.CAMERA OPERATION • Turn On/ Off the camera 1. Long press the Power button (A) for 3 seconds to power is on, indicator C turns blue. 2. Long press the Power button (A) for 3 seconds to power off, indicator C blinks and then turn off. •... - Page 20 SCREENSAVER This will determine if the LCD will turn off after 1 min, 3 min or 5 min. Press any key to turn the screen on. Select OFF to keep the screen always ON. AUTO POWER OFF The camera turns off when not in use after specified time.. TV OUT Setting the desired TV standard, PAL or NTSC.
-
Page 21: Effects Configuration
Note: You can easily access some settings such as Beep, Mic, Speaker, Invert and Wi-Fi with touch operation by swiping up. - Press the power/ navigation button, to start the recording. - The duration of the recording will be show on the LCD screen. -If a low speed SD card is being use, the video will be adjust in 720p automatically. -
Page 22: Changing The Modes Of The Camera
• Changing the modes of the camera 1. Mode changing (A) - When the camera is turn On, press on the button (A) to go in the differents modes: Video, Photo, Playback, Settings. Stop pressing the button (A) to select the desired mode. -It is also possible to access thoses modes via the touchscreen by swiping on the left. - Page 23 MODE To set the video mode, Manual, Looping, Auto Stop, Timelapse. RESOLUTION 4K 15fps / 2.5K 30fps / 1080P 60fps / 720P 120fps To set the lens wide angle, Super Wide, Wide, Medium, Narrow. VIDEO QUALITY To set the video quality. To set the digital image stabilization.
-
Page 24: Take Photos
• Take photos Press the Shutter button (B) once to shoot a single picture, LED D flashes green. • Photo settings Press Power Button (A) once to navigate, press Shutter Button (B) to Enter/Confirm selection. MODE To set the photo mode, Manual, Timelapse, Burst, Self Timer. MEGA PIXEL 14M / 12M / 8M / 5M To set the lens wide angle, Super Wide, Wide, Medium, Narrow. -
Page 25: Playback
- Short press Shutter button (B) to play. - Short press Shutter button (B) again to exit the play control panel. You can operate the Reporter Action camera more easily by tapping the screen. • Using the external microphone (Optional) - Insert the external MIC to Mini USB port, the camera will automatically switch to record the sound from the external MIC. -
Page 26: How To Use The App On A Smartphone
1. Turn the camera on. 2. Connect your mini HDMI to HDMI cable with the Reporter action camera and your TV. 3. Select the right source on the TV. • How to use the App on a smartphone - The Reporter allows full camera control, live previewing and playback of photos/videos on most Smart phones and Tablets. - Page 27 Open the app Connect successfully Enter the live interface...
- Page 28 SD Card Capacity Current Mode Battery Status Return Setup Picture/Video Shift Local Album Picture/Video Recording...
-
Page 29: Maintenance
It’s not recommended to change by yourself the lens for example, because its requires technical knowledge. - Use only the accessories specified by the manufacturer. - Find out all our products and accessories in our website www.pnj.fr... -
Page 30: Warranty
During the contractual warranty period, the defective product must be returned in its original packaging to the retailer’s service center or to the www.pnj.fr website, depending on the place of purchase. After inspection of the product, the after-sales service will repair or replace the defective part or product, to the exclusion of any other compensation, if the product has been used correctly. -
Page 31: Recycling
PNJ. - Defects caused by parts not supplied by PNJ, including a battery not approved by PNJ. All products found to be defective after analysis will be returned to the shipper at their expense. -
Page 32: Declaration Of Conformity
15.DECLARATION OF CONFORMITY SAS PNJ, 110, Esplanade du Général de Gaulle 92400 Courbevoie, France, declares under its sole responsibility that the product described in this manual complies with the requirements of the Directives R&TTE 1999/5/CE et RoHS 2011/65/EU. A copy of the Declaration of conformity is available in the following website: www.pnj.fr/certifications... -
Page 33: Trademarks
SAS PNJ cannot be held responsible directly or indirectly for any prejudice or loss of data resulting from an error or omission from this document. SAS PNJ reserves the right to modify the product and its operating instructions without any restriction or obligation to inform the user. Thus, the purchased product may differ somewhat from the one described in this document. - Page 34 NOTES _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _...
- Page 35 NOTES _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _...
