AMP Display Inc. DWIN C Series LCM Quick Start Manual

AMP DISPLAY INC.
Thank you for choosing the DWIN UART LCD
Module. This quick start guide will show you how to
simply make a connection between a computer (PC) and
DWIN C series UART module. You can also refer to
Development Guide
our
further details.

Required Items

In order to successfully make a connection between a
computer and DWIN C series module, you will need the
following items:
1. Male to male USB cable
Because of the 5V power-up requirement of the C series module,
the display can connect directly to a PC via a USB cable.
2. 10 pin flat cable
3. HDL662 (FCC to USB connecting board)
4. Molex 10 pin connector
available for your MCU connection
5. 2GB DWIN SD Card
6. Optional: HDL661 or HDL663
Please note: this quick guide is only for the C series models. If you have a T series
model or an S series model, (For example T series: DMT80480
S
DMT80480 070_06WT) this quick start might not be suitable for you. Please contact
AMP Display if you have an S or T series and need help setting up your display.
Contact Us
QUICK START GUIDE
for DWIN C Series LCM
Software User Guide
and for
T
07_06WT, S series:
inf
What is DGUS?
DGUS, which stands for: DWIN
Graphical User Software, is intelligent
GUI design software applicable to a
wide range of applications from factory
automation to diagnostics and therapy,
process control and point-of-sale
systems. DGUS offers Original
Equipment Manufacturers (OEM)
design engineers that ability to develop
product prototypes using color TFT
LCD panels, greater flexibility, faster
development and easier upgrading
capability without the complexity of
TFT timing signals or core algorithms.
1
