Summary of Contents for AnyTone Hera
- Page 1 Hera USER'S MANUAL KNOW ABOUT THIS RADIO Microphone connector AM/FM mode Scan key Function key Power On/Off Volume control RF Gain control Squelch control, SQ, ASQ switch key External speaker Jack Antenna Jack Downloaded from www.cbradio.nl...
-
Page 2: Volume Control
HOW TO USE THIS RADIO Power On/Off the radio Turn VOL switch clockwise to power on the radio, the LCD displays the Norms and then displays channel number. Turn VOL switch anti-clockwise, until hear Ka Ta, the radio is powered off. Volume control Turn clockwise to increase volume, anti-clockwise to decrease volume. -
Page 3: Scan Function
Keypad Lock Hold key for over 2 seconds to lock the keys, LCD displays " ". Hold key for over 2 seconds again to unlock the keys. Note：In lock Mode all keys except PTT is valid. Emergency Channel Choose wanted channel. Short press key again to return to last normal channel. -
Page 4: Menu Operations
Menu Operations Hold to enter menu list. Short press to choose RESETALL menu. Short press microphone to choose wanted setting. Press or wait 10 seconds to store exit setting. Display Function Setting details 1 ... - Page 5 SPECIFICATION GENERAL Modulation Mode AM/FM Frequency Range 26.965-27.405MHz Frequency Tolerance ±5.0ppm Input Voltage 13.2V 120x88x35mm Dimensions Weight 550g Ferquency Control PLL Synthesizer Operating Temperature -20℃ ~ +50℃ Range Transmit 2A MAX Current Drain Receive Squelched 0.3A VOL Max 0.8A Antenna Connector UHF,SO-239 TRANSMITTER Power Output...
