Instruction Manual Warming Drawer Model No. 8120-00-000 10700 Medallion Drive, Cincinnati, Ohio 45241-4807 USA © 2017 Gold Medal Products Co. Part No. 110125... -
Page 2: Safety Precautions
Read and understand operator’s manual and all other safety instructions before using this equipment. To order copies of the operator’s manual go to gmpopcorn.com or write to Gold Medal Products Co., 10700 Medallion Drive, Cincinnati, OH 45241 USA 1-(800)-543-0862 022_060215 gmpopcorn.com... - Page 3 007_010914 Note: Improvements are always being made to Gold Medal’s equipment. This information may not be the latest available for your purposes. It is critical that you call Gold Medal’s Technical Service Department at 1-800-543-0862 for any questions about your machine operations, replacement parts, or any service questions.
-
Page 4: Installation Instructions
To order copies of the operator’s manual go to gmpopcorn.com or write to Gold Medal Products Co., 10700 Medallion Drive, Cincinnati, OH 45241 USA 1-(800)-543-0862. Model Description 8120-00-000: Warming Drawer with Digital Heat Control. Items Included with this Unit • Power Cord •... -
Page 5: Electrical Requirements
4. DO NOT use a grounded to un-grounded receptacle adapter (where applicable). 5. Install the unit in a level position. CAUTION If the supply cord is damaged, it must be replaced by a special cord or assembly available from Gold Medal Products Co. or its service agent. 038_062714 gmpopcorn.com Page 5... -
Page 6: Controls And Their Functions
Warming Drawer Model No. 8120-00-000 OPERATING INSTRUCTIONS Controls and Their Functions POWER SWITCH Two position, lighted rocker switch – provides power to the fan and supplies power to the Digital Heat Control. The green light ON indicates there is power to the unit. -
Page 7: Adjusting The Set Temperature
Warming Drawer Model No. 8120-00-000 Adjusting the Set Temperature The Warming Drawer comes from the factory with the Digital Heat Control preset to 150°F (maximum setting is 170°F). Follow the steps below to adjust this preset temperature. 1. Press “SET” button on the Digital Heat Control, and “SP” will appear. Press “SET” again to display current set temperature. -
Page 8: Care And Cleaning
5. Wipe the stainless steel parts with a clean cloth and cleaner designed for stainless steel, such as Gold Medal Watchdog Stainless Cleaner (Item No. 2088). DO NOT use oven cleaners or abrasive materials as they will damage parts of the machine. -
Page 9: Troubleshooting
Warming Drawer Model No. 8120-00-000 Troubleshooting Issue Possible Cause Solution Unit Does Not Heat A. No power to unit A. Check that the unit is plugged into the wall outlet. See Electrical Requirements Section for electrical specifications. Make sure the main Power Switch is ON. -
Page 10: Maintenance Instructions
Warming Drawer Model No. 8120-00-000 MAINTENANCE INSTRUCTIONS DANGER Machine must be properly grounded to prevent electrical shock to personnel. Failure to do so could result in serious injury, or death. DO NOT immerse any part of this equipment in water. -
Page 11: Ordering Spare Parts
Warming Drawer Model No. 8120-00-000 ORDERING SPARE PARTS 1. Identify the needed part by checking it against the photos, illustrations, and/or parts list. (General images may be used in manual for reference only.) 2. Use only approved replacement parts when servicing this unit. -
Page 12: Cabinet Exterior
*CAUTION: If supply cord is damaged, it must be replaced by a special cord or Bottom Cover 10, 11, 12 assembly available from Gold Medal (not shown) Products Co. or its service agent. Part No. Item Part Description... - Page 13 Warming Drawer Model No. 8120-00-000 Cabinet Interior – Fan View 812 0- 00 -0 00 Part No. Item Part Description 8120-00-000 HEAT ELEMENT, 250W, 120V 38824 AXIAL FAN 40721 EXHST BLOWER PLUG & CORD 47199 .500 IN SNAP BUSHING 47236...
- Page 14 Warming Drawer Model No. 8120-00-000 Cabinet Interior (View with Drawer Removed) 812 0- 00 -0 00 4, 5 6, 7, 8 11, 12 Part No. Item Part Description 8120-00-000 PROBE BRACKET 111496 WIRE CLIP 76216 HEAT SENSOR 36103 8-32 X 3/8 PAN HD PH M/S 12389 8-32 HEX NUT, ESLOK, S.S.
- Page 15 Warming Drawer Model No. 8120-00-000 Drawer View 802 0- 00 -0 00 8, 9 Screws Included Part No. Item Part Description 8120-00-000 DRAWER SUB ASSEMBLY 111398 FULL STEAM PAN 111424 FALSE BOTTOM 111446 DRAWER RACK 111399 DRAWER FRONT 17582 PLASTIC DRAWER HANDLE (Includes 2 Screws)
-
Page 16: Safety Labels
Warming Drawer Model No. 8120-00-000 Safety Labels Unit Labels Power Cord Labels Part No. Item Part Description 8120-00-000 COOKER LABEL 111031 CORD SET CAUTION LABEL 102032 MAIN GROUND LABEL 42375 WARNING LABEL CORD 68720 POWER CORD TAG 76135 gmpopcorn.com Page 16... -
Page 17: Wiring Diagram
Warming Drawer Model No. 8120-00-000 Wiring Diagram Model No. 8120-00-000 gmpopcorn.com Page 17... - Page 18 © 2017 – The text, descriptions, graphics, layout, and other material in this publication are the exclusive property of Gold Medal Products Co. and shall not be used, copied, reproduced, or published in any fashion, including website display, without its express written consent.
