Teradek Case Quick Manual

C
POWER & CONNECT
Connect the included AC cable to the Case
1
Use the included light stand to raise Case to ~ 8 feet.
2
Connect the included AC adapter (or optional Cubit, sold separately) to the Cube.
3
or
AC adapter Cubit
Connect your video source to Cube and attach Cube's antennas.
4
HDMI
SDI
Antenna
A: Power Input
B: Power Switch
C: Airport Extreme
D: Mac Mini
A
B
D
(A) and turn on the power (B).
NETWORK CONNECTION
CONNECTING TO CASE:
2.1
Case includes a preconfigured Apple Airport Extreme
wireless Router. All Cubes included with Case associate
with the Router. To view your Cube(s) feed, simply
connect your laptop or tablet to the Router's wireless
network.
CONNECTING TO YOUR CUBE
2.2
Once connected to Case, your Cubes can be found on the network by using TeraCentral.
TeraCentral is available from the iTunes App store for iPad/iPhone and on the included
USB stick for Windows/Mac computers.
1
iPad
To log into your Cube, select Configure Settings
listing. When prompted, log in using Cube's default
password (admin).
NEED MORE HELP?
1. Training videos: http://www.teradek.com/pages/tutorials
2. Support forum: http://www.teradek.com/pages/downloads → information and the latest firmware & software updates.
TERADEK SUPPORT STAFF: support@teradek.com or call 888−941−2111 ext2 (Mon−Fri 9am to 6pm PST)
SSID:
2.4GHz: Teradek Case xxxxx
5GHz: Teradek Case xxxxx 5GHz
(xxxxx=Unique Case ID)
password: teradekcase
S :
( )
iPhone
next to your Cube's stream
CUBE'S WEB UI LOGIN
username (admin) and
username:
password:
2
admin
admin
