e.w.s BMC User Manual

The new Bass Mid Control is the active mid-controller for bass players.
A small but powerful pedal that provides frequency control adjustments between 120Hz ~
3kHz. When using 2-band EQ or passive bass, the Frequency control provides excellent
manipulation of the mid frequencies, while the Boost/Cut gives you boosting or cutting
capabilities of up to + / - 12dB. This compact pedal can also be powered by a 9V battery or
for additional headroom use an 18V power adapter. This pedal will provide you the flexibility
to play any musical style.
Boost/Cut
You can adjust the amount of
boost/cut of mid frequency
+/-12dB
The Boost/Cut knob may turn
slightly when the Frequency knob
is turned quickly.
This does not mean the product is
defective.
Frequency
You can set the range of the mid
frequency EQ
Range is between 120Hz~3KHz
7 o'clock : 120Hz
9 o'clock : 160Hz
11 o'clock : 500Hz
12 o'clock : 630Hz
1 o'clock : 800Hz
3 o'clock : 2KHz
3KHz
5 o'clock :
Spec
Size(W/D/H) 90mm /50mm / 70mm
Weight 320g
True Bypass Switching
9VDC/3.3mA
Power
Consumption
(*18VDC- only with DC adapter jack.
18VDC/6.6mA)
Batter Type 9VDC(006P)x1
9 ∼ 18VDC, Negative Tips
AC Adapter
(Optional)
(Regulated recommended such as
Dunlop ECB04 Power Supply)
www.ews-us.com
distributed by Prosound Communications Inc.
www.prosoundcommunications.com
Recommended Settings
Frequency at 10 o'clock and
Boost/Cut at 4 o'clock for
fretless virtuoso sound.
Frequency at 1 o'clock,
Boost/Cut at 9 o'clock and
internal Trimmer slightly
boosted for great slap sound.
Internal Trimmer
- +
Output Level: Factory setting is
no volume difference compared to
Bypass. You can adjust this with
the internal Trimmer depending
on the equipment you use.
