1.XX48.05 DIVERTOR / MIXER
INSTALLATION GUIDE
When installing the mixer,
ensure that it is positioned
correctly, with the mixer on the
top side and the diverter on
the bottom side.
Hot water is connected to
the left, and the cold water is
connected to the right, when
hot
viewed from the operating
position.
When the diverter handle is
rotated fully clockwise, water
diverter
is diverted to the bottom port.
handle
Anti-clockwise rotation of the
handle diverts water to the
top port.
FURTHER INFORMATION
For any further information regarding installation, cleaning
or replacement components, please do not hesitate to call
our customer service on (02) 9421 8200.
ICNMIX | BR3367 | 0816
BASIN AND WALL MIXER
INSTALLATION INSTRUCTIONS
top port
cold
holes
bottom port
Brodware Industries
2 St James Place
Seven Hills NSW 2147
Australia
+61 2 9421 8200
brodware.com
